ABB SS832 Power Voting Unit – Industrial-Grade Redundant Power Controller

The ABB SS832 represents a critical infrastructure component for mission-critical automation systems demanding uninterrupted 24VDC power delivery. Engineered for process control environments where milliseconds of downtime translate to production losses or safety risks, this intelligent voting unit accepts dual redundant power inputs and executes seamless automatic failover in under 1 millisecond. Designed specifically for ABB 800xA distributed control systems, AC800M programmable controllers, and S800 I/O networks, the SS832 eliminates single points of failure in your power architecture while delivering 20A combined output capacity from a compact DIN rail form factor.

Whether you're protecting pharmaceutical batch processes, maintaining uptime in offshore oil platforms, or ensuring regulatory compliance in power generation facilities, the SS832 provides the redundancy backbone that keeps your control systems operational through power supply maintenance, electrical faults, or component failures.

Core Capabilities & Technical Advantages

→ Sub-Millisecond Failover Technology
Proprietary voting logic continuously monitors both 24VDC input sources and executes switchover in less than 1ms when the active supply degrades. This response time prevents controller resets, I/O communication losses, and process interruptions that plague slower redundancy schemes.

→ High-Density Power Distribution
Dual 10A outputs (20A total) support multiple AC800M controllers, communication modules, and I/O racks from a single voting unit, reducing cabinet space and wiring complexity compared to parallel redundancy approaches.

✓ Intelligent Source Selection
Advanced voltage monitoring automatically selects the healthier input when both supplies are operational, balancing load and extending power supply service life through optimized utilization patterns.

✓ Comprehensive Fault Protection
Integrated overvoltage, overcurrent, and short-circuit protection safeguards downstream controllers and I/O modules from electrical faults, while LED diagnostics provide instant visibility into power source health and active input status.

✓ Extended Environmental Range
-25°C to +70°C operating temperature qualification enables deployment in unheated control buildings, outdoor enclosures, and harsh industrial environments without derating or auxiliary cooling.

✓ Universal DIN Rail Integration
Standard 35mm rail mounting with snap-lock retention integrates seamlessly into existing ABB control cabinets and third-party enclosures, supporting both horizontal and vertical rail orientations.

Industrial Application Scenarios

Chemical & Petrochemical Processing
Continuous process plants utilize SS832 voting units to maintain DCS controller operation during scheduled power supply maintenance or unexpected failures. The instantaneous switchover prevents batch losses, maintains reactor temperature control, and ensures safety instrumented system availability for emergency shutdown functions. Typical installations protect distributed I/O networks spanning multiple process units where a single power failure could cascade across production areas.

Power Generation & Utilities
Thermal, combined-cycle, and nuclear power stations deploy SS832 units in turbine control systems, boiler management networks, and balance-of-plant automation where controller downtime directly impacts grid stability and regulatory compliance. The unit's IEC 61508 certification supports integration into safety-rated systems protecting critical equipment and personnel.

Oil & Gas Production Facilities
Offshore platforms and remote wellhead installations face unique power reliability challenges from generator load variations, electrical storms, and limited maintenance access. SS832 redundancy ensures production control systems remain operational during generator switchovers, while the -25°C to +70°C rating accommodates unheated equipment shelters in Arctic and desert climates.

Water & Wastewater Treatment
Municipal treatment facilities require 24/7 SCADA system availability to prevent service interruptions, environmental permit violations, and public health risks. SS832 voting units protect pump control systems, chemical dosing controllers, and telemetry networks from power supply aging and lightning-induced failures common in outdoor installations.

Manufacturing & Assembly Automation
Automotive assembly lines, semiconductor fabrication tools, and packaging machinery depend on SS832 redundancy to prevent costly production stoppages from power supply failures. The 20A capacity supports motion controllers, vision systems, and distributed I/O networks in a single compact package, reducing panel space and installation labor.

Technical Parameters & Selection Criteria

Sizing Guidelines: Calculate total current draw of all connected controllers, communication modules, and I/O racks. Add 20% safety margin and verify result is below 20A. For loads exceeding 20A, deploy multiple SS832 units with segregated power distribution or specify higher-capacity voting units.

Input Supply Selection: Pair with ABB SD-series power supplies (SD821, SD822, SD823, SD831, SD832) rated for combined output exceeding your load requirement. Install supplies on separate AC circuits or UPS systems to eliminate common-mode failures.

Advanced Integration & IoT Connectivity

While the SS832 operates as a standalone hardware voting unit without network connectivity, it integrates seamlessly into broader system monitoring strategies:

Power Supply Monitoring: Connect ABB SD-series power supplies with diagnostic outputs to your DCS or SCADA system to receive advance warning of supply degradation before failover occurs. This predictive approach enables scheduled maintenance rather than reactive troubleshooting.

Cabinet Environmental Monitoring: Combine SS832 redundancy with temperature sensors and ventilation controls to prevent thermal-induced power supply failures in high-ambient installations.

Energy Management Integration: Track power consumption patterns across redundant supplies to optimize load balancing and identify efficiency improvement opportunities in large distributed control installations.

Customization Options: For OEM applications or specialized requirements, ABB offers custom firmware configurations, extended temperature ratings, and conformal coating upgrades through their engineering services program.

Delivery Timeline & Service Commitments

Standard Lead Time: Stock items ship within 3-5 business days via express courier with full tracking and insurance. Rush processing available for critical outage situations.

Custom Configurations: Modified units with special firmware or environmental ratings typically require 4-6 weeks for engineering review and production scheduling.

Warranty Coverage: 24-month manufacturer warranty from shipment date covers defects in materials and workmanship. Extended warranty programs available for critical infrastructure applications.

Technical Support: Lifetime access to application engineering support for installation guidance, troubleshooting assistance, and system integration questions via email and phone.

Documentation Package: Each unit ships with installation manual, wiring diagrams, dimensional drawings, and certification documents. CAD models and 3D STEP files available for download.

Frequently Asked Questions

Q: How does the SS832 power voting unit interface with ABB 800xA DCS controllers?
A: The SS832 connects electrically to the 24VDC power input terminals of AC800M controllers, communication modules, and S800 I/O modules. It requires no software configuration or network connection – the voting logic operates autonomously in hardware. Simply wire both redundant power supplies to the SS832 inputs and connect the output to your controller power bus.

Q: What output current capacity do I need for a typical AC800M controller system?
A: A single AC800M controller (PM860-PM866 series) typically draws 1.5-3A depending on installed communication modules. Add 0.5-1A per S800 I/O cluster. For example, one controller with three I/O clusters would require approximately 5-6A, well within the SS832's 20A capacity. Always verify actual current draw from product datasheets and add 20% margin.

Q: Can the SS832 improve energy efficiency in redundant power systems?
A: Yes – the intelligent voting logic automatically selects the input with optimal voltage characteristics, which can reduce losses in downstream DC-DC converters and improve overall system efficiency by 2-5% compared to diode-OR redundancy schemes that always impose forward voltage drop.

Q: What DIN rail mounting requirements does the SS832 have?
A: The unit mounts on standard 35mm DIN rail per EN 50022 specification. It requires approximately 100mm of horizontal rail space and should be positioned with adequate ventilation clearance (minimum 25mm above and below) for convection cooling. The snap-lock mechanism allows tool-free installation and removal.

Q: Does the SS832 support remote monitoring or diagnostic communication?
A: The SS832 provides local LED status indication for both inputs and output. For remote monitoring, connect ABB SD-series power supplies with diagnostic relay outputs to your DCS or SCADA system to receive advance warning of supply degradation before the SS832 executes failover.

Q: How do I verify proper SS832 installation and failover operation?
A: After wiring both inputs and the output, power up both supplies and verify green LEDs illuminate on Input A, Input B, and Output. To test failover, disconnect one input supply – the corresponding input LED should extinguish while the output LED remains green, confirming seamless transfer. Reconnect and repeat for the other input. Total system downtime during testing should be zero.
