BACHMANN MPC293 CPU Module – Industrial-Grade Process Controller

The BACHMANN MPC293 represents a proven solution for industrial automation environments demanding reliable computational performance under extreme conditions. Built on Intel Celeron or Pentium III architecture with 128MB DRAM and 8MB internal FLASH, this CPU module delivers consistent processing power for distributed control systems, SCADA networks, and safety-critical manufacturing operations.

Designed for system integrators and plant engineers managing complex process automation, the MPC293 addresses the challenge of maintaining uptime in harsh industrial settings where temperature extremes, electrical noise, and vibration threaten conventional computing hardware. Its DIN-rail mounting and M1 system compatibility enable rapid deployment within existing BACHMANN automation infrastructures.

Whether you're upgrading legacy control systems or building new automation architectures, the MPC293 combines field-proven reliability with flexible communication interfaces—delivering the processing foundation your critical operations require.

Core Capabilities & Business Value

→ Extended Temperature Operation (-40°C to +70°C)
Deploy in outdoor enclosures, unheated facilities, or high-temperature process areas without thermal management concerns—reducing infrastructure costs while expanding installation flexibility.

✓ Dual Processor Architecture Options
Select between Intel Celeron or Pentium III configurations to match processing requirements with budget constraints, optimizing total cost of ownership across diverse application profiles.

✓ 128MB DRAM + 8MB FLASH Memory
Execute complex control algorithms, store historical data locally, and maintain program integrity during power interruptions—minimizing dependency on external storage systems.

→ Multi-Protocol Communication Support
Integrate seamlessly with Ethernet, serial, Modbus TCP/IP, PROFINET, and EtherNet/IP networks, eliminating protocol conversion overhead and accelerating system commissioning timelines.

✓ 24V DC Industrial Power Supply
Operate directly from standard industrial power rails without AC conversion, simplifying electrical design and improving system-level fault tolerance.

Application Scenarios Across Industries

Oil & Gas Refinery Process Control
Manage distillation column sequencing, pipeline pressure regulation, and emergency shutdown systems where the MPC293's temperature tolerance and deterministic performance ensure safe operation across seasonal temperature variations and hazardous area classifications.

Chemical Manufacturing Batch Processing
Orchestrate recipe management, ingredient dosing, and reaction monitoring in pharmaceutical and specialty chemical plants requiring validated control systems with audit trail capabilities and 21 CFR Part 11 compliance support.

Water Treatment SCADA Networks
Coordinate pump stations, filtration systems, and chemical feed controls across distributed municipal infrastructure where the MPC293's communication flexibility enables cost-effective remote monitoring and centralized operational oversight.

Power Generation Auxiliary Systems
Control boiler feedwater systems, cooling tower operations, and emissions monitoring equipment in coal, gas, and renewable energy facilities demanding high-availability automation with minimal maintenance intervention.

Food & Beverage Production Lines
Drive conveyor systems, packaging equipment, and quality inspection stations in temperature-controlled environments where the MPC293's robust design withstands washdown procedures and sanitation protocols.

Technical Parameters & Selection Guide

Selection Criteria: Choose the MPC293 when your application requires proven processor technology with extensive field history, moderate computational demands (≤500 I/O points), and compatibility with existing BACHMANN M1 backplane infrastructure. For applications exceeding 1000 I/O points or requiring advanced motion control, evaluate higher-performance MX-series processors.

Extended Functionality & Integration Options

IoT Connectivity & Remote Access
Enable secure VPN tunneling, OPC UA server functionality, and cloud data forwarding through Ethernet interface configuration—transforming legacy automation islands into Industry 4.0-ready connected systems without hardware replacement.

Redundancy & High-Availability Configurations
Implement hot-standby CPU redundancy using dual MPC293 modules with automatic failover logic, achieving 99.9%+ system availability for critical process applications where unplanned downtime carries significant financial or safety consequences.

Custom Application Development
Leverage BACHMANN SolutionCenter IDE to develop proprietary control algorithms, custom HMI interfaces, and specialized communication drivers—differentiating your automation solutions while maintaining long-term supportability.

Delivery Timeline & Service Commitments

Standard Delivery: 5-7 business days for in-stock units via express courier with tracking
Custom Configuration: 10-15 business days for pre-programmed modules or special firmware versions
Warranty Coverage: 12-month comprehensive warranty covering manufacturing defects and component failures
Technical Support: Lifetime email/phone support for installation guidance, programming assistance, and troubleshooting
Documentation Package: User manual, wiring diagrams, sample code libraries, and certification documents included

Frequently Asked Questions

What backplane modules are compatible with the MPC293 CPU?
The MPC293 integrates with all BACHMANN M1-series backplanes including BS209 (9-slot), BS210 (10-slot), and BS212 (12-slot) configurations. Verify power budget calculations when populating backplanes with high-current I/O modules.

Can I upgrade memory capacity on the MPC293 module?
The 128MB DRAM and 8MB FLASH are fixed specifications. For applications requiring expanded memory, consider the MPC240 series offering up to 256MB DRAM, or utilize external PC card storage via PCC201 PCMCIA interfaces.

How does the MPC293 perform in vibration-prone environments?
The module meets IEC 60068-2-6 vibration resistance standards (10-150 Hz, 1g acceleration), making it suitable for mobile equipment, conveyor-mounted installations, and high-vibration industrial settings when properly secured to DIN rail.

What programming software is required for MPC293 development?
BACHMANN SolutionCenter (version 3.x or higher) provides the complete development environment supporting IEC 61131-3 languages, online debugging, and firmware updates. Educational licenses and trial versions are available for evaluation purposes.

Is the MPC293 suitable for safety-rated control applications?
The standard MPC293 is designed for non-safety control functions. For SIL-rated safety applications, integrate with BACHMANN safety I/O modules and implement safety logic using certified safety programming tools per IEC 61508 requirements.

What is the typical power consumption of the MPC293 module?
Typical consumption ranges from 8-12W depending on processor variant and computational load. Budget 15W per module when sizing backplane power supplies to ensure adequate margin for peak operating conditions.

Start Your Automation Project Today

Contact our technical sales team for application-specific guidance, system architecture recommendations, and volume pricing. We provide comprehensive pre-sales support including compatibility verification, I/O mapping assistance, and migration planning from legacy control platforms.

Request a quote now or speak with an automation specialist to discuss your process control requirements.
