TP-ZSBHM2-100 Single Board History Module (Industrial-Grade Data Archival Solution)

The TP-ZSBHM2-100 represents Honeywell's next-generation approach to industrial data historization, purpose-built for facilities upgrading from legacy TDC 3000 history architectures to modern Single Board History Module (SBHM) platforms. This upgrade kit eliminates the complexity of multi-board configurations while delivering superior data integrity through dual logical drive redundancy—critical for process industries where historical records drive compliance audits, operational optimization, and root cause analysis.

Designed for plant engineers managing aging TDC 3000 infrastructures, this module addresses the growing challenge of maintaining reliable data collection as legacy components reach end-of-life. Whether you're operating continuous chemical processes, refinery units, or pharmaceutical batch systems, the TP-ZSBHM2-100 ensures uninterrupted trend data capture during system migrations without requiring full DCS replacement.

Key advantages include plug-and-play compatibility with existing Experion TPS networks, reduced rack space consumption compared to predecessor modules, and enhanced query performance that accelerates troubleshooting workflows. The solid-state architecture minimizes mechanical failure points while maintaining full backward compatibility with your current TDC 3000 operator interfaces and engineering tools.

Core Features & Business Value

✓ Dual Logical Drive Architecture: Automatic data mirroring across independent storage volumes ensures zero data loss during drive failures, eliminating costly gaps in regulatory compliance records and production analytics.

✓ Seamless TDC 3000 Integration: Direct compatibility with legacy Local Control Networks (LCN) and Universal Stations preserves your existing infrastructure investment while modernizing data retention capabilities—no forklift upgrades required.

✓ Single-Board Consolidation: Replaces multi-card history module assemblies with one compact unit, freeing valuable rack space for future I/O expansion or redundancy improvements in space-constrained control rooms.

✓ Enhanced Retrieval Performance: Optimized database indexing delivers 40% faster trend queries compared to legacy modules, reducing mean time to diagnose process upsets and accelerating engineering analysis cycles.

✓ Hot-Swappable Upgrade Path: Supports parallel operation with existing history modules during phased migrations, enabling risk-free transitions without production interruptions or data continuity breaks.

Typical Application Scenarios

→ Refinery Process Units: Continuous crude distillation and catalytic cracking operations require 24/7 data logging for yield optimization and safety system validation. The TP-ZSBHM2-100's redundant storage prevents audit trail gaps during turnarounds, while extended retention capacity supports multi-year trend comparisons for feedstock quality analysis.

→ Chemical Manufacturing Plants: Batch reactor control systems demand precise historical records for FDA 21 CFR Part 11 compliance and batch genealogy tracking. This module's deterministic write performance ensures every process variable change is captured, even during high-speed batch transitions or alarm floods.

→ Power Generation Facilities: Combined-cycle plants and boiler systems rely on long-term performance trending to optimize heat rates and predict maintenance intervals. The SBHM architecture handles high-density data collection from turbine control systems while maintaining query responsiveness for real-time efficiency calculations.

→ Pharmaceutical Production: GMP-regulated environments require tamper-proof electronic batch records with complete audit trails. Dual-drive redundancy provides the data integrity assurance needed for regulatory inspections, while backward compatibility preserves validated system states during upgrades.

Technical Parameters & Selection Guide

Selection Criteria: Choose the TP-ZSBHM2-100 when upgrading TDC 3000 systems with legacy multi-board history modules (e.g., HM, AM configurations) or when adding redundant data collection to single-drive installations. Verify your current LCN firmware revision supports SBHM communication protocols—consult Honeywell documentation or contact our technical team for compatibility confirmation. For greenfield Experion deployments, consider native Experion historians; this module optimizes brownfield TDC 3000 modernization projects.

Extended Functions

OPC Connectivity: Built-in OPC DA/HDA server interfaces enable third-party MES, LIMS, and business intelligence platforms to access historical data without custom middleware development, accelerating digital transformation initiatives.

Remote Diagnostics: Integrated health monitoring exposes drive status, write queue depth, and storage utilization metrics via standard TDC 3000 diagnostic displays, enabling predictive maintenance strategies and proactive capacity planning.

Custom Retention Policies: Configurable data compression and archival rules allow tailored retention strategies—maintain high-resolution data for recent periods while automatically downsampling older records to optimize storage efficiency without manual intervention.

Delivery & Service Assurance

Lead Time: Standard configurations ship within 3-5 business days for in-stock units. Custom-configured modules with specific firmware revisions or extended testing require 10-15 business days. Expedited processing available for critical outage scenarios.

Warranty Coverage: Comprehensive 12-month warranty covers all manufacturing defects, component failures, and performance deviations from published specifications. Warranty includes firmware updates and technical support access.

Technical Support: Direct access to Honeywell-certified engineers for installation guidance, configuration assistance, and troubleshooting support. Phone and email support available during business hours (GMT+8), with emergency hotline for critical production issues.

Documentation Package: Each unit includes installation manual, configuration quick-start guide, wiring diagrams, and compatibility matrices. Firmware release notes and migration checklists provided for upgrade projects.

Frequently Asked Questions

How does the TP-ZSBHM2-100 integrate with existing TDC 3000 operator stations?
The module operates transparently within your current TDC 3000 architecture—existing trend displays, alarm historians, and engineering tools require no modifications. Historical data appears seamlessly alongside real-time process values using your established HMI configurations.

What data migration tools are included for transferring legacy history archives?
Honeywell provides migration utilities that export data from older history modules and import into the SBHM database structure. The process preserves timestamps, data quality flags, and annotation records. Our technical team offers migration planning services to minimize downtime during transitions.

Can this module support high-speed data collection from fast control loops?
Yes, the SBHM architecture handles collection rates up to 1-second intervals across hundreds of process tags simultaneously. The dual-drive design ensures write performance remains consistent even during peak logging periods or concurrent query operations.

What cybersecurity features protect historical data integrity?
The module supports TDC 3000 network segmentation best practices and includes write-once audit logging to detect unauthorized data modifications. For enhanced security, the unit integrates with Honeywell's Secure Media Exchange (SMX) protocols when deployed in Experion hybrid environments.

How much rack space does installation require compared to legacy modules?
The single-board design occupies one standard TDC 3000 card slot versus the 2-3 slots required by older HM/AM combinations—a 50-66% reduction in footprint. This consolidation frees space for additional I/O cards or redundant controller installations.

What happens if one logical drive fails during operation?
The system continues normal data collection using the healthy drive while generating diagnostic alarms to notify operators. Hot-swap capability allows drive replacement without halting data logging or requiring system restarts, ensuring continuous compliance record integrity.

Ready to Modernize Your TDC 3000 Data Infrastructure?

Contact our industrial automation specialists to discuss your specific TDC 3000 configuration and receive a tailored upgrade proposal. We provide compatibility assessments, migration planning support, and post-installation validation services to ensure seamless transitions. Request a technical datasheet or schedule a consultation to explore how the TP-ZSBHM2-100 can enhance your facility's data reliability and operational intelligence capabilities.
