UR6SH Digital I/O Expansion Module (Industrial-Grade Relay Interface)

The UR6SH Digital I/O Expansion Module extends signal processing capabilities for GE Multilin UR Series protection relays, delivering 32 configurable channels for comprehensive substation automation and industrial control applications. Designed for power utilities, manufacturing facilities, and critical infrastructure, this module enables advanced monitoring, remote switching, and fault detection across motor protection, feeder management, and transformer control systems.

Whether you're upgrading legacy protection schemes or deploying new IEC 61850-compliant substations, the UR6SH provides the flexible I/O architecture required for modern power system integration. Its wide voltage tolerance and industrial temperature rating ensure reliable operation in the harshest electrical environments.

Seamlessly integrate with existing UR relay platforms to unlock enhanced diagnostics, SCADA connectivity, and real-time status monitoring—all while maintaining compliance with international safety and performance standards.

Core Features & Benefits

→ Dual-Channel Architecture: 16 programmable digital inputs paired with 16 relay outputs deliver comprehensive signal interfacing for complex protection logic and control sequences.

→ Universal Voltage Compatibility: Accepts 24-250V DC/AC input signals, eliminating the need for external signal conditioning and simplifying field wiring across diverse voltage systems.

→ Extreme Environment Performance: Operates reliably from -40°C to +85°C, meeting the demands of outdoor substations, industrial plants, and remote installations without climate control.

→ Plug-and-Play Integration: Direct chassis mounting with automatic recognition by UR Series CPUs—no complex configuration required for basic I/O expansion.

→ High-Current Output Contacts: 5A @ 250V AC/DC relay outputs handle direct control of circuit breakers, motor starters, and auxiliary equipment without intermediate relays.

→ Protocol-Agnostic Communication: Inherits Modbus RTU, DNP3.0, and IEC 61850 capabilities from host relay CPU for seamless SCADA and DCS integration.

Typical Application Scenarios

Medium-Voltage Motor Protection
Expand I/O capacity for comprehensive motor management systems monitoring thermal overload sensors, bearing RTDs, vibration switches, and auxiliary starter contacts. The UR6SH enables simultaneous tracking of up to 16 discrete motor status points while controlling cooling fans, space heaters, and alarm annunciators through dedicated output channels.

Distribution Feeder Automation
Implement advanced bay control schemes with remote circuit breaker operation, disconnector position monitoring, and fault passage indication. Integrate with recloser controllers and sectionalizers to create self-healing distribution networks that minimize outage duration and improve power quality.

Transformer Monitoring & Control
Interface with tap changer position indicators, oil temperature sensors, Buchholz relay contacts, and cooling system status inputs. Output channels control forced-air cooling fans, oil pumps, and alarm circuits while providing remote trip capability for catastrophic fault conditions.

Substation Gateway Applications
Serve as the I/O interface layer for centralized substation controllers, aggregating status points from multiple protection devices and providing coordinated control outputs for bus transfer schemes, synchronization systems, and load shedding programs.

Renewable Energy Integration
Monitor inverter status, grid synchronization signals, and islanding detection contacts in solar and wind installations. Control outputs manage generator breakers, power factor correction capacitors, and reactive power compensation equipment.

Technical Parameters & Selection Guide

Selection Criteria: Choose the UR6SH when your application requires balanced input/output expansion with high-current switching capability. For input-only applications, consider the UR6NH variant. For applications requiring analog signal processing, pair with the UR8AH CT/VT module. Maximum system capacity supports up to 6 expansion modules per UR relay chassis, limited by power supply capacity and CPU model.

Extended Functions

Advanced Diagnostics: Built-in self-test routines continuously monitor contact integrity, input circuit continuity, and power supply health. Diagnostic alarms integrate with relay event logs for predictive maintenance and troubleshooting.

Programmable Logic Integration: I/O points map directly to UR relay FlexLogic™ equations, enabling custom protection schemes, interlocking sequences, and automated control routines without external PLCs.

Cybersecurity Features: When paired with UR CPUs running firmware v7.0+, the module supports role-based access control and encrypted communication channels for compliance with NERC CIP standards.

Hot-Swap Capability: Select UR relay models support online module replacement with automatic configuration restoration, minimizing downtime during maintenance activities (consult CPU model specifications).

Delivery & Service Assurance

Lead Time: Standard stock items ship within 1-3 business days. Custom-configured modules or bulk orders may require 2-4 weeks—contact our team for expedited options.

Warranty Coverage: 12-month manufacturer warranty against defects in materials and workmanship. Extended warranty programs available for critical infrastructure applications.

Technical Support: Lifetime access to application engineering assistance, including relay programming support, system integration guidance, and troubleshooting consultation via phone, email, or remote desktop.

Documentation Package: Each module ships with installation manual, wiring diagrams, dimensional drawings, and EnerVista UR Setup software compatibility guide. IEC 61850 ICD files and Modbus register maps available for download.

Frequently Asked Questions

What is the maximum I/O expansion capacity for UR Series relays?
Most UR relay CPUs support up to 6 expansion modules in any combination of I/O, CT/VT, and communication cards. Total capacity depends on chassis size and power supply rating—verify compatibility with your specific CPU model before ordering.

Can the UR6SH interface with third-party protection devices?
Yes, the module's universal voltage inputs accept signals from any manufacturer's relays, PLCs, or RTUs. Output contacts can control external devices regardless of brand, making it ideal for multi-vendor substation environments.

How does the UR6SH compare to the UR6NH module?
The UR6SH provides 16 inputs + 16 outputs, while the UR6NH offers 32 inputs only. Choose UR6SH for applications requiring control outputs; select UR6NH for monitoring-intensive applications where output channels aren't needed.

Is special configuration software required for I/O mapping?
No additional software is needed—GE's EnerVista UR Setup (free download) handles all configuration. I/O points appear automatically in the software interface once the module is physically installed and recognized by the CPU.

What are the power consumption requirements?
The UR6SH draws approximately 5W from the relay's internal power supply. Ensure your UR1HH or URRHH power supply module has sufficient capacity for all installed expansion modules—consult the power budget calculator in EnerVista UR Setup.

Does the module support IEC 61850 GOOSE messaging?
GOOSE functionality is CPU-dependent. When installed in UR relays with IEC 61850 capability, I/O points can be mapped to GOOSE datasets for peer-to-peer communication with other IEDs on the substation LAN.

Ready to Expand Your Protection System?

Enhance your GE Multilin UR relay platform with proven I/O expansion technology trusted by utilities and industrial operators worldwide. Our technical team is ready to assist with module selection, system design, and integration planning.

Contact us today for: Application-specific recommendations • Volume pricing • Custom configuration services • Technical training resources
