3A98658H07 Power Supply Module (Industrial-Grade 24VDC Converter)

The Emerson 3A98658H07 represents a critical infrastructure component for distributed control architectures requiring uninterrupted, precision-regulated DC power. Engineered specifically for Ovation platform ecosystems, this module converts universal AC mains into stable 24-volt direct current, supporting controller racks, I/O chassis, and communication backplanes across process industries where millisecond-level reliability defines operational success.

Designed for environments where power anomalies translate directly to production losses—refineries, chemical plants, utility substations—the 3A98658H07 addresses voltage sag, transient spikes, and harmonic distortion through active filtering and thermal management. Target users include instrumentation engineers managing legacy Ovation migrations, maintenance teams requiring zero-downtime replacements, and system integrators specifying redundant power topologies for SIL-rated safety systems.

Key differentiators include field-proven hot-swap mechanics eliminating scheduled outages, universal input acceptance reducing spare parts inventory, and diagnostic telemetry enabling predictive maintenance strategies. When paired with redundant configurations, this module achieves five-nines availability in mission-critical control loops.

Core Capabilities & Business Value

→ Universal Input Compatibility (100-240VAC Auto-Sensing)
Eliminates voltage-specific SKUs across global facilities, reducing procurement complexity and emergency stock requirements by 60%. Single part number serves North American 120V, European 230V, and industrial 208V three-phase systems.

✓ Hot-Swap Architecture with Live Insertion
Replace failed units during full production without controller resets or process interruptions. Maintenance windows shrink from hours to minutes, directly improving OEE in continuous manufacturing environments.

✓ 10-Ampere Continuous Output with 15% Overload Reserve
Supports fully-populated controller chassis plus expansion I/O without derating. Headroom accommodates inrush currents during module initialization, preventing nuisance trips in high-density cabinets.

→ Multi-Layer Protection Suite (OVP/OCP/SCP/OTP)
Integrated overvoltage, overcurrent, short-circuit, and thermal shutdown safeguards protect downstream logic and field devices. Fault isolation prevents cascade failures across shared DC buses.

✓ 85%+ Conversion Efficiency Under Typical Loads
Reduces heat dissipation by 40% versus linear supplies, lowering HVAC costs in control rooms and extending component lifespan through cooler operating temperatures.

→ Front-Panel LED Diagnostics (Input/Output/Fault Indicators)
Technicians diagnose power issues in seconds without multimeters. Color-coded status lights accelerate troubleshooting during emergency callouts, cutting MTTR by an average of 25 minutes.

Industry Application Scenarios

Fossil & Nuclear Power Generation
In combined-cycle plants and reactor control systems, the 3A98658H07 energizes turbine sequencing controllers, feedwater regulation loops, and emissions monitoring networks. Utilities leverage its redundancy-ready design to meet NERC CIP compliance for critical cyber assets, while hot-swap capability supports outage-free quarterly inspections.

Upstream Oil & Gas Production
Offshore platforms and remote wellhead sites deploy this module in SCADA cabinets controlling separator pressure, pipeline flow computers, and flare management systems. Wide operating temperature range (-20°C to +60°C with derating) withstands unheated enclosures in Arctic and desert climates.

Chemical Processing & Refining
Distillation columns, reactor batch controllers, and safety instrumented systems (SIS) in petrochemical complexes require the 3A98658H07's deterministic power delivery. Its UL/CE/RoHS certifications streamline hazardous location approvals, while DIN-rail mounting integrates with existing Ovation and third-party marshalling systems.

Water & Wastewater Treatment
Municipal treatment plants use this supply to power chlorination dosing controllers, UV disinfection sequencers, and SCADA gateways. Resistance to humidity and corrosive atmospheres (conformal-coated PCBs) extends service life in pump stations and clarifier control houses.

Pharmaceutical & Food Manufacturing
Clean-room environments and CIP (clean-in-place) systems benefit from the module's sealed construction preventing particulate ingress. Batch recipe controllers and temperature profiling systems maintain validation compliance through stable voltage regulation (±1% line/load).

Technical Parameters & Selection Criteria

Sizing Guidance: Calculate total DC load by summing controller base current (typically 2-3A), I/O module consumption (0.1-0.5A per card), and communication modules (0.3-0.8A). For N+1 redundancy, each supply must handle 100% of load independently. In 2N configurations, size each unit for 60% of total load to allow maintenance flexibility.

Advanced Integration Features

Redundancy Topologies: Supports parallel operation with current-sharing diodes (ORing modules) for load balancing. Compatible with Emerson's redundant power distribution panels, enabling automatic failover without voltage dips. Ideal for SIL 2/3 safety systems requiring proven-in-use power architectures.

Remote Monitoring Readiness: While the base module provides local LED status, it interfaces with Ovation's power monitoring cards for SCADA-level alarming. Integrate with Emerson AMS Suite for predictive analytics on output ripple, temperature trends, and remaining useful life calculations.

Retrofit Compatibility: Direct replacement for legacy 1X00416H01 and 1X00024H01 supplies in older Ovation systems. Maintains identical footprint and terminal assignments, allowing upgrades without rewiring or controller reconfiguration.

Delivery Timeline & Service Commitments

Standard Lead Time: 3-5 business days for in-stock units; expedited same-day shipping available for critical outages (additional fees apply).

Warranty Coverage: 24-month manufacturer defect warranty from ship date. Covers component failures under normal operating conditions; excludes damage from overvoltage events or environmental extremes beyond ratings.

Technical Support: Access to application engineers for load calculations, redundancy design reviews, and integration troubleshooting. Email/phone support during business hours; emergency hotline for production-down scenarios.

Documentation Package: Includes installation manual with wiring diagrams, dimensional drawings (DXF/PDF), compliance certificates (UL508, CE EMC Directive), and RoHS/REACH declarations. Editable CAD symbols available for panel layout software.

Frequently Asked Questions

Q: Can the 3A98658H07 interface directly with Allen-Bradley or Siemens controllers?
A: Yes, the 24VDC output is industry-standard and compatible with any control system accepting 18-32VDC input. Verify current requirements do not exceed 10A continuous rating.

Q: What's the maximum cable distance between power supply and controller rack?
A: For 10A loads, use minimum 14 AWG (2.5mm²) wire to limit voltage drop below 0.5V over 50 feet (15 meters). Longer runs require heavier gauge or local power distribution.

Q: Does this module require forced-air cooling or heat sinking?
A: Natural convection cooling is sufficient up to 50°C ambient. Above 50°C, derate output by 2.5% per degree or add cabinet ventilation fans to maintain airflow.

Q: How do I configure N+1 redundancy with existing Ovation systems?
A: Install redundant supplies on shared DC bus using diode ORing modules (Emerson part 1X00024H02). Each supply operates independently; failure of one unit transfers load seamlessly to backup.

Q: Are firmware updates required for this power supply?
A: No, the 3A98658H07 is a hardware-only device with no programmable logic. Once installed, it requires no software maintenance or version management.

Q: What's the typical energy savings versus older linear power supplies?
A: Switching topology reduces power consumption by 40-50% compared to linear designs. A fully-loaded 10A system saves approximately 120 watts continuously, translating to $100-150 annual electricity cost reduction per unit.

Secure Your Critical Infrastructure Power

Ensure uninterrupted control system operation with the proven reliability of Emerson's 3A98658H07. Whether upgrading aging infrastructure or designing new installations, this module delivers the performance and longevity your processes demand. Contact our technical team today for application-specific sizing, redundancy architecture consultation, or volume pricing for multi-site deployments.

Ready to specify? Request a detailed datasheet, compliance certificates, or schedule a technical review call with our automation specialists.
