ABB REG670 Generator Protection Relay (Industrial-Grade IEC 61850 Control System)

The ABB REG670 is a comprehensive generator protection and control relay designed for critical power generation applications. Through advanced differential protection algorithms, multi-protocol communication capabilities, and integrated monitoring functions, it delivers reliable safeguarding for generators, motors, and transformers in power plants, industrial facilities, and renewable energy installations.

Engineered for high-voltage generator sets, combined heat and power (CHP) systems, hydroelectric stations, thermal power plants, and distributed energy resources, the REG670 addresses challenges including generator faults, stator ground faults, rotor earth faults, loss of excitation, reverse power conditions, and inadequate real-time diagnostics. Its modular architecture ensures adaptability across diverse operational requirements.

Leveraging field-proven protection logic, seamless SCADA integration, and user-configurable settings, this relay provides superior fault detection accuracy, reduced downtime risk, simplified commissioning workflows, and comprehensive event recording. Ideal for consulting engineers, EPC contractors, system integrators, and plant operators seeking dependable protection solutions. Contact our application engineers for tailored configuration guidance and technical specifications.

Core Functions & Technical Advantages

• Multi-Function Differential Protection
  Employs high-speed differential algorithms with harmonic restraint and CT saturation detection, ensuring precise discrimination between internal faults and external disturbances while minimizing nuisance tripping during magnetizing inrush or through-fault conditions.
• Comprehensive Generator Protection Suite
  Integrates stator earth fault (95%), rotor earth fault (64R), loss of excitation (40), reverse power (32), overvoltage (59), undervoltage (27), overfrequency/underfrequency (81O/U), and thermal overload (49) protection—reducing relay count and panel footprint by up to 40%.
• IEC 61850 & Multi-Protocol Communication
  Native support for IEC 61850 Edition 2, Modbus TCP/RTU, DNP3, and PROFIBUS DP enables seamless integration with modern substation automation systems, legacy DCS platforms, and cloud-based asset management solutions.
• Advanced Monitoring & Diagnostics
  Real-time waveform capture, sequence-of-events recording with 1 ms resolution, disturbance recording, and self-supervision diagnostics facilitate rapid fault analysis, predictive maintenance planning, and compliance with grid code requirements.
• Rugged Industrial Design
  Meets IEC 60255, IEEE C37.90, and IEC 61850-3 environmental standards with operating temperature range of -40°C to +70°C, EMC immunity to IEC 61000-4 Level 4, and conformal coating options for harsh industrial and marine environments.
• Intuitive Configuration & HMI
  PCM600 engineering tool streamlines parameter setting, logic customization, and firmware updates; optional local HMI with backlit LCD provides on-site access to measurements, alarms, and control functions without external tools.

Typical Application Scenarios

The ABB REG670 is optimized for installations demanding high reliability, regulatory compliance, and operational flexibility, including:

• Thermal & Combined-Cycle Power Plants
  Protects steam turbine generators and gas turbine-driven units against electrical and mechanical faults, supports automatic synchronization, and interfaces with turbine control systems for coordinated trip logic and black-start sequences.
• Hydroelectric & Pumped-Storage Facilities
  Handles variable-speed generator protection, accommodates wide frequency excursions during startup/shutdown, and integrates with governor controls to prevent motoring and ensure grid stability during islanding events.
• Industrial Cogeneration & Captive Power
  Safeguards reciprocating engine generators, microturbines, and synchronous motors in chemical plants, refineries, steel mills, and manufacturing facilities, reducing unplanned outages and enhancing process continuity.
• Renewable Energy Integration
  Deployed in wind farm collector substations, solar PV inverter stations, and biomass plants to provide generator-transformer unit protection, fault ride-through capability, and compliance with grid connection codes (e.g., IEEE 1547, VDE-AR-N 4120).
• Marine & Offshore Platforms
  Protects shipboard generators, offshore drilling rig power systems, and floating production storage offloading (FPSO) units under extreme vibration, humidity, and salt-fog conditions with DNV-GL and ABS type approvals.

Technical Parameters & Selection Guide

To facilitate engineering design and procurement, we offer standard configurations and project-specific customization across the following specifications:

Selection Recommendations: When specifying the REG670, consider generator MVA rating, voltage class, CT/VT ratios, required protection functions, communication protocol requirements, redundancy needs, and environmental conditions. For complex applications—such as multi-winding transformers, unit-connected schemes, or black-start capability—consult our protection engineers with single-line diagrams, generator data sheets, and project specifications for optimized relay configuration and settings coordination.

Extended Capabilities & Integration Options

• Synchrocheck & Auto-Synchronization (ANSI 25): Programmable voltage, frequency, and phase-angle matching logic for safe paralleling with grid or other generators
• Breaker Failure Protection (ANSI 50BF): Configurable retrip schemes with local and remote backup coordination
• Voltage & Reactive Power Control: Interfaces with automatic voltage regulators (AVR) for closed-loop excitation control and power factor correction
• Cybersecurity Features: Role-based access control (RBAC), encrypted communication (TLS 1.2), audit logging, and IEC 62351 compliance for critical infrastructure protection
• Condition Monitoring: Partial discharge detection inputs, bearing RTD monitoring, and vibration sensor integration for predictive maintenance analytics

Delivery, Service & Quality Assurance

Lead Time: Standard catalog models ship within 3–5 business days from regional stock; custom-configured units with extended I/O, communication modules, or factory acceptance testing (FAT) require 4–6 weeks.

Warranty & Support: All REG670 relays include a minimum 3-year manufacturer warranty covering materials and workmanship. Extended warranty plans, on-site commissioning assistance, protection coordination studies, and 24/7 technical hotline support are available based on project scope and geographic location.

Documentation Package: Each relay ships with IEC 61850 ICD/CID files, Modbus register maps, CAD drawings (DWG/DXF), wiring diagrams, operation manuals (multi-language), commissioning checklists, and PCM600 configuration templates—ensuring streamlined installation, testing, and long-term maintainability.

Certifications: Factory-tested per IEC 60255-27 (product safety), IEC 61000-4 (EMC), and IEEE C37.90 (surge withstand); type-test reports and third-party certifications (UL, CE, CCC, GOST) available upon request for regulatory compliance verification.

Frequently Asked Questions (FAQ)

Q: How does the ABB REG670 generator protection relay integrate with existing DCS or SCADA systems?
A: The REG670 supports IEC 61850 MMS, GOOSE, and sampled values for native substation automation integration, plus Modbus TCP/RTU and DNP3 Serial/IP for legacy DCS compatibility. Configuration is performed via the PCM600 tool, which auto-generates communication mapping files and supports OPC UA gateways for enterprise-level data historians.

Q: What is the maximum number of generators or motors a single REG670 unit can protect?
A: A single REG670 relay is designed for one generator or motor unit protection. For multi-unit installations (e.g., multiple generators on a common bus), deploy one relay per machine with coordinated settings and inter-relay communication via GOOSE or hardwired interlocking to achieve selective tripping and backup protection schemes.

Q: What energy savings or efficiency improvements can be expected with the REG670?
A: While the relay itself does not directly reduce energy consumption, its fast fault-clearing capability (typical 20–30 ms for differential faults) minimizes equipment damage, reduces repair costs by up to 50%, and shortens outage duration—indirectly improving plant availability and revenue generation. Integrated monitoring also enables optimized generator loading and predictive maintenance, contributing to overall operational efficiency.

Q: What are the environmental and installation requirements for the REG670?
A: The relay operates reliably in ambient temperatures from -40°C to +70°C (extended range to +85°C available), altitude up to 2000 m without derating, and relative humidity up to 95% non-condensing. Panel-mount versions require IP20 rear protection; for outdoor or high-contamination environments, specify IP65-rated wall-mount enclosures with heaters and thermostats. Ensure adequate ventilation and avoid direct sunlight exposure.

Q: Can the REG670 support remote monitoring, data logging, and cybersecurity compliance?
A: Yes. The relay features built-in web server for remote HMI access, SNMP traps for alarm notification, and syslog export for centralized event management. Cybersecurity is addressed through user authentication (LDAP/RADIUS), encrypted protocols (HTTPS, SSH, TLS), and compliance with IEC 62351 and NERC CIP standards. Firmware updates and configuration changes are audit-logged with timestamp and user ID for forensic traceability.

Q: What communication protocols and industrial standards does the REG670 support?
A: The relay natively supports IEC 61850 Edition 2 (MMS, GOOSE, SV), Modbus TCP/RTU, DNP3 Serial/IP, and PROFIBUS DP. Optional modules enable IEC 60870-5-103, SPA, and proprietary SCADA protocols. All implementations conform to relevant IEEE, IEC, and UL standards, ensuring interoperability with multi-vendor substation equipment and future-proof scalability.

Request Technical Support & Custom Solutions

To obtain detailed application notes, protection coordination studies, pricing quotations, or engineering assistance, please provide the following project information: facility type and location, generator nameplate data (MVA, kV, RPM, connection type), CT/VT ratios, required protection functions (per ANSI/IEC codes), communication protocol preferences, environmental conditions, and any specific regulatory or utility interconnection requirements. Our certified protection engineers will deliver tailored relay selection, settings calculations, and one-on-one technical consultation within 24–48 hours.
