ABB NCAN-02C CANopen Adapter | Industrial Drive Communication Module for ACS600/ACS800

CANopen Adapter Module NCAN-02C (Industrial-Grade Fieldbus Communication Solution)

The ABB NCAN-02C is a professional CANopen adapter module designed for seamless integration with ACS600 and ACS800 series variable frequency drives. Through CANopen fieldbus protocol, it enables real-time data exchange, precise motion control, and intelligent monitoring across distributed automation systems.

Ideal for manufacturing plants, process automation, material handling systems, and industrial machinery requiring synchronized multi-axis control. This module addresses challenges such as communication delays, protocol incompatibility, complex wiring, and limited diagnostic capabilities in legacy control systems.

With standardized design and flexible configuration options, the NCAN-02C delivers high-speed communication, robust EMC performance, easy maintenance, and broad compatibility—making it the preferred choice for system integrators, automation engineers, OEM manufacturers, and plant maintenance teams. Contact our engineers for application-specific configuration and technical documentation.

Core Features & Advantages

CANopen Protocol Compliance
Fully compliant with CiA DS-301 and DS-402 standards, ensuring interoperability with mainstream PLCs, motion controllers, and HMI systems. Supports PDO, SDO, and NMT services for flexible data mapping.

Real-Time Performance
Achieves cycle times as low as 1ms with deterministic communication, critical for synchronized multi-drive applications such as packaging lines, printing presses, and CNC machining centers.

Plug-and-Play Integration
Pre-configured EDS (Electronic Data Sheet) files and comprehensive parameter libraries reduce commissioning time by up to 60%, minimizing engineering costs and project delays.

Comprehensive Diagnostics
Built-in LED indicators and detailed error logging provide instant visibility into network status, node health, and communication faults—reducing troubleshooting time and unplanned downtime.

Industrial-Grade Reliability
Designed for harsh environments with wide operating temperature range (-25°C to +70°C), enhanced EMC immunity (EN 61800-3 Category C3), and conformal coating protection against dust and moisture.

Scalable Network Architecture
Supports up to 127 nodes on a single CANopen network with flexible topology (line, star, tree), enabling cost-effective expansion as production requirements grow.

Typical Application Scenarios

This module is engineered for applications demanding high reliability, precise synchronization, and seamless integration with existing automation infrastructure:

Automated Production Lines & Assembly Systems
Coordinates multiple conveyor drives, robotic arms, and indexing tables in automotive, electronics, and food & beverage manufacturing. Ensures synchronized motion with sub-millisecond accuracy.

Material Handling & Logistics Automation
Integrates with warehouse management systems (WMS) to control sortation conveyors, automated storage/retrieval systems (AS/RS), and AGV fleets—optimizing throughput and reducing manual intervention.

Process Industry & Continuous Manufacturing
Connects variable speed drives in chemical processing, pulp & paper, mining, and water treatment plants. Enables centralized monitoring and coordinated control of pumps, fans, and compressors.

Machine Tool & Metalworking Equipment
Provides high-speed communication for CNC lathes, milling machines, and grinding systems requiring precise spindle speed control and coordinated axis motion.

Building Automation & HVAC Systems
Facilitates integration of chiller drives, air handling units, and pump stations into BMS (Building Management Systems) for energy-efficient operation and predictive maintenance.

Technical Parameters & Selection Guide

To facilitate engineering design and product selection, we provide standardized specifications. Custom configurations are available based on project-specific requirements.

Key Specifications:

• Protocol: CANopen (CiA DS-301, DS-402)
• Baud Rate: 10 kbps to 1 Mbps (auto-detection supported)
• Compatible Drives: ABB ACS600, ACS800 series (all power ratings)
• Network Topology: Line, star, tree (max 127 nodes)
• Communication Interface: 9-pin D-sub connector (CAN_H, CAN_L, GND)
• Power Supply: 24 VDC ±20% (isolated, supplied via drive backplane)
• Operating Temperature: -25°C to +70°C
• Protection Rating: IP20 (suitable for control cabinet mounting)
• EMC Compliance: EN 61800-3 Category C3, CE marked
• Dimensions: Compact DIN-rail mountable module (approx. 45mm width)
• Diagnostic Features: Dual-color LED (network status, error indication), event logging

Selection Recommendations:
When selecting the NCAN-02C module, consider the following factors: required network baud rate, number of connected drives, maximum cable length (up to 1000m at 50 kbps), existing PLC/controller compatibility, and environmental conditions (temperature, vibration, EMI). For assistance, please provide your system architecture, drive models, and communication requirements—our engineers will recommend the optimal configuration.

Extended Functionality & Integration Options

Multi-Protocol Gateway Capability
Can be combined with ABB's FPBA-01 or FENA-21 modules to bridge CANopen networks with PROFIBUS DP, Modbus RTU, or Ethernet/IP—enabling hybrid automation architectures.

Advanced Motion Control
Supports velocity mode, torque mode, and position mode operation via standardized CANopen profiles, simplifying integration with third-party motion controllers.

Remote Monitoring & Predictive Maintenance
When integrated with SCADA or cloud-based IoT platforms, enables real-time performance tracking, vibration analysis, and predictive fault detection—reducing maintenance costs by up to 25%.

Delivery, Service & Quality Assurance

Lead Time: Standard modules ship within 3-5 business days; custom-configured units require 7-10 days.
Warranty: 24-month manufacturer warranty covering defects in materials and workmanship.
Technical Support: Comprehensive commissioning assistance including remote guidance and on-site service (region-dependent).
Documentation Package: Complete electrical schematics, wiring diagrams, EDS files, parameter lists, and user manuals provided with each module—ensuring smooth installation and maintenance.

All products are factory-tested and certified to international standards (CE, UL, cUL where applicable). Quality control includes 100% functional testing, network communication verification, and environmental stress screening.

Frequently Asked Questions (FAQ)

Q: How do I integrate the NCAN-02C CANopen adapter with my existing ACS600 or ACS800 drive?
A: The module installs directly into the drive's fieldbus slot. After physical installation, configure the CANopen node ID and baud rate via the drive's control panel or DriveWindow software. Import the provided EDS file into your PLC/controller configuration tool to map process data objects (PDOs). Detailed step-by-step instructions are included in the installation manual.

Q: What is the maximum number of drives that can be connected on a single CANopen network?
A: The CANopen protocol supports up to 127 nodes per network segment. Practical limitations depend on network load, cycle time requirements, and cable length. For applications requiring more than 30-40 drives, consult our engineers for network segmentation strategies.

Q: What energy savings can be achieved by using CANopen communication for drive control?
A: While the adapter itself does not directly reduce energy consumption, it enables advanced control strategies such as load sharing, coordinated speed control, and demand-based operation—which can reduce overall system energy use by 15-30% compared to standalone drive operation. Actual savings depend on application type and control algorithm optimization.

Q: What are the environmental requirements for installing the NCAN-02C module?
A: The module is rated IP20 and designed for installation inside control cabinets. Operating temperature range is -25°C to +70°C with 5-95% relative humidity (non-condensing). For harsh environments with excessive dust, moisture, or corrosive gases, ensure adequate cabinet sealing and ventilation.

Q: Does the NCAN-02C support remote monitoring and data acquisition?
A: Yes. When connected to a CANopen master with gateway functionality (e.g., PLC with Ethernet interface or dedicated IoT gateway), drive parameters, status information, and diagnostic data can be transmitted to SCADA systems, cloud platforms, or mobile applications via Modbus TCP, OPC UA, or MQTT protocols.

Q: Is the module compatible with non-ABB CANopen devices?
A: Yes. The NCAN-02C adheres to standard CANopen specifications (CiA DS-301 and DS-402), ensuring interoperability with CANopen-compliant PLCs, I/O modules, sensors, and HMIs from manufacturers such as Siemens, Schneider Electric, Beckhoff, and others.

Request a Quote or Technical Consultation

To receive a detailed selection guide, pricing quotation, or technical support, please provide the following information: project name, application scenario, number of drives, required communication speed, existing PLC/controller model, power supply specifications, and environmental conditions. Our application engineers will respond within 24 hours with a customized solution and implementation roadmap.
