PM573-ETH Industrial Processor Module (AC500 Platform Architecture)

The ABB PM573-ETH represents a next-generation programmable logic controller engineered for mission-critical automation environments. Featuring dual-core processing architecture with 512KB flash program storage and 512KB RAM data retention, this AC500 series controller delivers deterministic scan performance for time-sensitive industrial protocols. Ethernet 10/100 connectivity combined with RS232/RS485 serial interfaces enables seamless integration across legacy and modern automation ecosystems.

Manufacturing engineers, system integrators, and automation specialists rely on this processor for applications demanding high-speed I/O processing, multi-protocol communication, and IEC 61131-3 programming flexibility. Whether orchestrating production line sequencing, coordinating building automation systems, or managing distributed control networks, the PM573-ETH provides the computational horsepower and connectivity options required for complex industrial workflows.

Key differentiators include hot-swappable SD card support for rapid program deployment, fieldbus port (FBP) for protocol expansion, and -25°C to +60°C extended temperature operation. The module's DIN rail mounting and 24V DC backplane power simplify installation while maintaining industrial-grade reliability standards.

Engineering Advantages & Performance Characteristics

→ Multi-Protocol Communication Hub
Native Modbus TCP/RTU support eliminates gateway requirements when interfacing with third-party devices. The dedicated Ethernet port handles supervisory SCADA connections while dual serial ports simultaneously manage HMI panels and field instrumentation—reducing hardware costs and wiring complexity.

→ Scalable I/O Architecture
Expand from standalone machine control to plant-wide automation by adding up to 12 AC500 I/O modules per processor. Network multiple CPUs via Ethernet for distributed control systems managing hundreds of I/O points across production zones.

→ IEC 61131-3 Programming Ecosystem
Develop control logic using Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), or Sequential Function Chart (SFC). ABB Automation Builder software includes pre-validated function libraries for motion control, PID loops, and communication protocols.

✓ Deterministic Scan Performance
Optimized instruction execution ensures consistent cycle times critical for motion control, high-speed counting, and synchronized multi-axis applications. Real-time clock and battery-backed RAM preserve program integrity during power interruptions.

✓ Industrial EMC Compliance
EN 61000 series certification guarantees reliable operation in electrically noisy environments with variable frequency drives, welding equipment, and high-power switching devices.

✓ Hot-Standby Redundancy Ready
Deploy paired PM5xx processors in redundant configurations with automatic failover for critical infrastructure applications requiring 99.9%+ uptime guarantees.

Industry Application Scenarios

Manufacturing & Assembly Lines
Coordinate conveyor systems, robotic work cells, and quality inspection stations with synchronized I/O control. The processor's fast scan rates support high-speed packaging equipment while Ethernet connectivity enables real-time production monitoring and OEE tracking.

Water & Wastewater Treatment
Manage pump stations, chemical dosing systems, and filtration processes with analog control loops and discrete I/O. Modbus TCP integration connects flow meters, level transmitters, and SCADA systems for centralized facility management.

Building Automation & HVAC
Control chiller plants, air handling units, and lighting systems through BACnet or Modbus protocols. Schedule-based programming optimizes energy consumption while maintaining occupant comfort across commercial facilities.

Energy Distribution & Substations
Monitor circuit breakers, transformer loads, and power quality meters via IEC 61850 or DNP3 protocols. The processor's extended temperature rating suits outdoor enclosure installations in utility applications.

Material Handling & Logistics
Orchestrate automated storage/retrieval systems (AS/RS), sortation conveyors, and warehouse management interfaces. Ethernet/IP compatibility (via add-on modules) integrates with barcode scanners and RFID readers for inventory tracking.

Technical Specifications & Selection Criteria

Selection Guidelines: Choose PM573-ETH when your application requires Ethernet-based SCADA integration, Modbus TCP communication, or IEC 61131-3 programming flexibility. For applications needing only serial communication, consider the PM572 variant. For higher I/O density or redundancy requirements, evaluate PM5xx-R models with dual-processor architecture.

Advanced Integration Capabilities

IoT & Cloud Connectivity
Implement MQTT or OPC UA protocols through custom function blocks for Industry 4.0 initiatives. Connect to cloud analytics platforms for predictive maintenance, remote diagnostics, and production optimization.

Motion Control Integration
Coordinate servo drives and stepper motors via CANopen or EtherCAT (using communication modules). Synchronize multi-axis positioning with sub-millisecond precision for packaging, printing, and assembly applications.

Custom Protocol Development
Utilize Structured Text programming to implement proprietary communication protocols or interface with specialized instrumentation not supporting standard industrial protocols.

Delivery Timeline & Support Services

Standard Lead Time: 3-5 business days for in-stock units (express shipping available)
Custom Configuration: 7-10 business days for pre-programmed or tested assemblies
Warranty Period: 12 months from delivery date covering manufacturing defects
Technical Support: Email/phone assistance for programming, troubleshooting, and system design
Documentation Included: Installation manual, programming guide, communication protocol specifications, CAD drawings

Frequently Asked Questions

How do I connect the PM573-ETH to my existing Modbus RTU network?
Use the RS485 serial port configured as Modbus RTU master or slave. The processor supports up to 247 Modbus devices on a single RS485 segment with automatic baud rate detection (9600-115200 bps). Configure communication parameters through ABB Automation Builder software.

What is the maximum I/O capacity supported by this processor?
The PM573-ETH supports up to 12 local I/O modules on the AC500 backplane, providing approximately 192 digital I/O points or 96 analog channels (depending on module selection). Expand further using remote I/O via Ethernet or fieldbus networks.

Can this controller reduce energy consumption in HVAC applications?
Yes. Implement demand-based control algorithms, occupancy scheduling, and optimal start/stop routines to reduce HVAC energy usage by 15-30%. The processor's real-time clock enables time-of-day programming for utility demand response programs.

What are the physical installation requirements?
Mount on standard 35mm DIN rail with minimum 50mm clearance above/below for ventilation. Ambient temperature must remain within -25°C to +60°C range. Provide 24V DC power supply (minimum 2A capacity recommended for processor plus I/O modules).

Does the processor support remote monitoring and diagnostics?
Absolutely. Access the processor via Ethernet using ABB Automation Builder for real-time variable monitoring, program uploads/downloads, and diagnostic troubleshooting. Configure VPN access for secure remote support from off-site locations.

Is training available for the AC500 programming environment?
We provide technical documentation and sample programs with purchase. ABB offers official training courses covering IEC 61131-3 programming, communication setup, and advanced troubleshooting techniques. Online resources include video tutorials and application notes.
