ABB RED670 Line Distance Protection Relay – Industrial-Grade Transmission Network Protection System

The ABB RED670 (1MRK002810-AB) is a high-performance line distance protection relay engineered for transmission networks, substations, and critical power distribution systems. Leveraging advanced IEC 61850 communication protocols and multi-zone distance protection (ANSI 21), this relay delivers precise fault detection, directional overcurrent protection (ANSI 67), and comprehensive disturbance recording capabilities to safeguard high-voltage transmission lines.

Designed for utility operators, substation integrators, power plant engineers, and EPC contractors, the RED670 addresses critical challenges including: delayed fault isolation, communication protocol incompatibility, insufficient backup protection, and limited diagnostic visibility during grid disturbances. Its modular architecture supports seamless integration with SCADA systems, RTUs, and modern digital substations.

Through standardized configuration tools and customizable protection schemes, this relay offers rapid commissioning, adaptive protection logic, and long-term reliability. Suitable for design institutes, system integrators, utility companies, and industrial facilities requiring mission-critical power protection. Contact our protection relay specialists for application-specific configuration guidance and technical quotations.

Core Functions & Technical Advantages

• Multi-Zone Distance Protection (ANSI 21)
  Implements up to six independent protection zones with polygonal or quadrilateral characteristics, enabling selective fault clearance and minimizing outage scope across transmission corridors.
• IEC 61850 Native Communication
  Fully compliant with IEC 61850 Ed.2 standards, supporting GOOSE messaging for peer-to-peer interlocking, MMS for SCADA integration, and sampled values (SV) for process bus applications, reducing copper wiring by up to 70%.
• Directional Overcurrent & Earth Fault Protection
  Integrated ANSI 67/67N functions with voltage-polarized or negative-sequence directional elements, providing reliable backup protection during CT saturation or weak infeed conditions.
• High-Resolution Disturbance Recording
  Captures waveform data at 4–8 kHz sampling rates with pre-fault and post-fault buffers, facilitating root-cause analysis, relay coordination verification, and compliance with grid code requirements.
• Comprehensive Self-Monitoring & Diagnostics
  Continuous supervision of CT/VT circuits, trip coil integrity, and internal hardware modules with timestamped event logs and remote alarm notification, reducing unplanned downtime and maintenance costs.
• Intuitive Configuration & Commissioning Tools
  Compatible with ABB PCM600 protection and control manager software, offering graphical single-line diagrams, automated setting calculations, and IEC 61850 system configuration (SCD/ICD file management).

Typical Application Scenarios

The ABB RED670 relay is engineered for demanding protection applications where fault clearance speed, selectivity, and communication interoperability are paramount:

• High-Voltage Transmission Lines (110 kV – 500 kV)
  Protects overhead lines and underground cables against phase-to-phase, phase-to-ground, and evolving faults, with adaptive reach settings to accommodate varying system impedances and load transfer scenarios.
• Digital Substations & Smart Grid Projects
  Serves as a cornerstone IED (Intelligent Electronic Device) in IEC 61850-based substations, enabling horizontal communication with bay controllers, vertical integration with substation automation systems, and process bus connectivity with non-conventional instrument transformers (NCITs).
• Industrial Power Distribution & Cogeneration Plants
  Ensures continuity of critical manufacturing processes in petrochemical, mining, steel, and pulp & paper facilities by isolating faulted feeders while maintaining supply to healthy sections through bus-tie interlocking and load-shedding schemes.
• Renewable Energy Integration (Wind Farms, Solar Parks)
  Manages bidirectional power flows and low short-circuit levels inherent to inverter-based resources, with configurable protection characteristics to prevent nuisance tripping during voltage sags or frequency excursions.

Technical Parameters & Selection Guide

To facilitate engineering design and procurement, we provide standardized electrical ratings and functional modules. Custom configurations are available to match project-specific protection philosophies and site conditions.

Selection Recommendations: When specifying the RED670, consider the following project parameters: transmission line voltage level and length, fault current magnitude, existing substation automation architecture (legacy RTU vs. IEC 61850), required redundancy (single vs. dual relay schemes), and environmental conditions (indoor switchgear vs. outdoor kiosk). For assistance, provide system single-line diagrams, protection coordination studies, and site electrical specifications—our application engineers will recommend optimal hardware configurations and setting files.

Advanced Features & Customization Options

• Adaptive Protection Schemes: Dynamic zone reach adjustment based on real-time system topology changes (breaker status, bus-tie position) to maintain selectivity during switching operations.
• Cybersecurity Hardening: Role-based access control (RBAC), encrypted communication channels (TLS), and audit trail logging compliant with IEC 62351 and NERC CIP standards.
• Redundancy & Hot-Standby: Dual-relay configurations with automatic switchover, shared I/O modules, and synchronized settings to achieve >99.99% protection availability.
• Third-Party Integration: Pre-tested interoperability with Siemens SICAM, GE MiCOM, SEL relays, and major SCADA platforms (ABB 800xA, Schneider ClearSCADA, OSIsoft PI).

Delivery, Service & Quality Assurance

Lead Time: Standard catalog units ship within 4–6 weeks; custom-configured relays with extended I/O or special firmware require 8–10 weeks. Expedited delivery available for critical outage replacements.

Warranty & Support: Backed by a 3-year manufacturer warranty covering hardware defects and firmware updates. Technical support includes remote commissioning assistance, on-site startup services (region-dependent), and access to ABB's global service network.

Documentation Package: Each relay ships with complete electrical schematics, terminal wiring diagrams, protection setting calculation worksheets, IEC 61850 ICD files, and multilingual operation manuals (English, Chinese, Spanish, Russian) to streamline installation and regulatory compliance.

Certifications: Factory acceptance testing (FAT) reports, type test certificates per IEC 60255-27 (EMC), seismic qualification (IEEE 693), and arc flash incident energy calculations available upon request.

Frequently Asked Questions (FAQ)

Q: How does the ABB RED670 distance protection relay integrate with existing substation SCADA systems?
A: The RED670 supports multiple legacy and modern protocols including DNP3 (serial/Ethernet), Modbus RTU/TCP, IEC 60870-5-103, and native IEC 61850 MMS. Integration typically involves configuring IP addresses, GOOSE subscriptions, and data mapping via ABB PCM600 software. For brownfield upgrades, protocol gateways can bridge legacy RTUs to IEC 61850 networks.

Q: What is the maximum number of protection zones supported by the RED670 relay?
A: The relay implements up to six independent distance protection zones (Z1–Z6) with configurable reach, time delays, and directional characteristics. Zones can be shaped as mho, quadrilateral, or polygonal impedance characteristics to match transmission line parameters and coordination requirements.

Q: What energy savings or operational benefits can be achieved with IEC 61850 communication?
A: IEC 61850 reduces copper wiring by 60–80% through digital communication, lowers commissioning time by 30–40% via auto-discovery and virtual terminal blocks, and enables condition-based maintenance by streaming real-time diagnostics to asset management systems—collectively reducing lifecycle costs by 20–35% compared to conventional hardwired schemes.

Q: What are the environmental and installation requirements for the RED670 relay?
A: The relay operates reliably in -40°C to +70°C ambient temperatures with IP54 front-panel protection (suitable for indoor switchgear). For outdoor substations or high-humidity environments, specify IP65-rated enclosures and conformal-coated PCBs. Mounting requires standard 19-inch relay panels with adequate ventilation (convection-cooled, no fans required).

Q: Can the RED670 relay support remote monitoring, firmware updates, and cybersecurity compliance?
A: Yes. The relay features secure web-based HMI access, SFTP-based firmware upgrades, and syslog event forwarding. Cybersecurity features include user authentication (LDAP/RADIUS), encrypted protocols (TLS 1.2+), and compliance with IEC 62351 and NERC CIP standards. Remote access can be configured via VPN tunnels or dedicated substation firewalls.

Q: Is technical training or commissioning support available for the ABB RED670 relay?
A: ABB offers comprehensive training programs including online courses, hands-on workshops at regional training centers, and customized on-site commissioning support. Training covers protection principles, PCM600 software operation, IEC 61850 configuration, and troubleshooting methodologies. Contact our technical team to schedule training aligned with your project timeline.

Request Technical Consultation & Quotation

To receive a tailored protection scheme design, relay configuration proposal, or commercial quotation, please provide the following project details: substation name and voltage level, transmission line length and conductor type, fault current levels (3-phase and ground), existing protection philosophy, communication protocol requirements, and delivery timeline. Our protection engineering team will respond within 24–48 hours with a comprehensive technical and commercial proposal.
