Bently Nevada 81672-01 Relay Output Module | 3300 Rack SPDT 5A Industrial Vibration Monitor

Bently Nevada 81672-01 Relay Output Module (Industrial-Grade Vibration Monitoring Solution)

The Bently Nevada 81672-01 is a professional relay output module engineered for 3300 series monitoring racks, delivering reliable alarm and trip signal conversion through precision SPDT relay contacts. By integrating seamlessly with vibration monitoring systems, this module transforms electronic monitor outputs into isolated relay actions, enabling direct control of shutdown systems, alarm panels, and distributed control systems (DCS) in critical rotating machinery applications.

Designed for high-stakes industrial environments including power generation turbines, gas compressors, petrochemical pumps, and steel mill drive systems, the 81672-01 addresses common challenges such as electrical noise interference, ground loop issues, signal isolation requirements, and the need for fail-safe alarm outputs. It ensures that vibration anomalies trigger immediate protective actions while maintaining complete electrical isolation between monitoring circuits and control systems.

Through API 670 compliant design and field-proven reliability, this relay module delivers galvanic isolation up to 2000VAC, contact ratings of 5A @ 250VAC/30VDC, and compatibility with both normally energized and de-energized logic configurations. Ideal for instrumentation engineers, plant maintenance teams, OEM machinery builders, and system integrators requiring dependable machine protection interfaces. Contact our application engineers for rack configuration assistance, wiring diagrams, and project-specific technical support.

Core Functions & Advantages

• High-Isolation Signal Conversion
  Provides 2000VAC isolation between monitor electronics and external control circuits, eliminating ground loops and protecting sensitive monitoring equipment from voltage transients and electrical noise common in industrial power distribution systems.
• Versatile Contact Configuration
  SPDT (Form C) relay contacts support both normally open and normally closed wiring schemes, accommodating fail-safe logic, redundant alarm paths, and compatibility with legacy DCS/PLC input modules across multiple control system architectures.
• Robust Contact Ratings
  Rated for 5A resistive load at 250VAC or 30VDC, capable of directly driving panel indicators, solenoid valves, motor contactors, and annunciator systems without requiring intermediate signal conditioning or amplification stages.
• API 670 Compliance
  Meets American Petroleum Institute Standard 670 requirements for machinery protection systems, ensuring suitability for critical turbomachinery applications in oil & gas, power generation, and petrochemical facilities where regulatory compliance is mandatory.
• Plug-In Modular Design
  Hot-swappable installation into 3300 series racks with keyed connectors prevents mis-insertion, reduces mean time to repair (MTTR) during maintenance, and allows pre-configuration and testing before field deployment.
• Comprehensive Diagnostic Features
  Front-panel LED indicators provide real-time relay status visualization, simplifying commissioning, troubleshooting, and routine operational checks without requiring external test equipment or circuit interruption.

Typical Application Scenarios

This relay output module excels in environments demanding high reliability, electrical isolation, and seamless integration with existing machinery protection infrastructure, particularly in:

• Steam & Gas Turbine Protection Systems
  Interfaces vibration monitors with turbine emergency shutdown (ESD) systems, converting bearing vibration, shaft position, and eccentricity alarms into isolated relay signals that trigger trip valves, preventing catastrophic failures in power plants and cogeneration facilities.
• Centrifugal Compressor Monitoring
  Provides alarm relay outputs for anti-surge control systems, lube oil pump interlocks, and process shutdown sequences in natural gas compression stations, refineries, and chemical plants where unplanned downtime costs exceed $100K per hour.
• Industrial Fan & Blower Applications
  Enables integration of vibration monitoring with variable frequency drives (VFDs), building management systems (BMS), and SCADA networks in HVAC systems, cement kilns, and material handling operations requiring continuous operation assurance.
• Pump & Motor Condition Monitoring
  Connects proximity probe monitors to distributed I/O systems, allowing real-time vibration data to trigger maintenance work orders, adjust operating parameters, or initiate automatic standby equipment switchover in water treatment, mining, and manufacturing facilities.
• OEM Machinery Integration
  Serves as the standard interface for equipment manufacturers building packaged turbomachinery skids, compressor packages, and test stands requiring factory-acceptance-test (FAT) compliant protection logic and customer-specified control system compatibility.

Technical Parameters & Selection Guide

To facilitate engineering design and procurement, we provide standardized electrical, mechanical, and environmental specifications. Custom configurations available for special voltage ratings, contact materials, or extended temperature ranges.

Selection Recommendations: When specifying, consider the number of alarm/trip points required per monitor channel, control system input voltage compatibility (AC vs. DC), fail-safe logic requirements (energized vs. de-energized), and available rack slot capacity. For systems requiring multiple relay outputs, redundant contacts, or special certifications (ATEX, IECEx), consult with our application engineers who can provide rack layout drawings, load compatibility analysis, and compliance documentation.

Extended Capabilities

• Multi-Channel Rack Integration: Combine with 3300 XL proximity transducers, accelerometers, and monitor modules to build complete 4-20 channel vibration monitoring systems with centralized relay outputs for plant-wide alarm distribution.
• Retrofit Compatibility: Direct replacement for legacy relay modules in existing 3300 racks, maintaining backward compatibility with original wiring harnesses and control system interfaces, minimizing upgrade costs and commissioning time.
• Redundant Architecture Support: Deploy in 2oo3 (two-out-of-three) voting configurations for SIL-rated safety instrumented systems (SIS), meeting IEC 61508 requirements for machinery protection in high-consequence applications.
• Remote Monitoring Integration: Relay status can be paralleled to SCADA RTUs, IoT gateways, or cloud-based condition monitoring platforms, enabling predictive maintenance analytics and remote diagnostics without compromising local control integrity.

Delivery, Service & Quality Assurance

Lead Time: Stock items ship within 1-3 business days; custom-configured modules typically 7-14 days depending on specification complexity and current production schedule.

Warranty: All modules carry a minimum 12-month manufacturer's warranty covering defects in materials and workmanship, with extended warranty options available for critical spares programs.

Technical Support: Comprehensive pre-sales application engineering assistance, post-sales commissioning guidance via phone/email, and on-site startup support available in select regions (subject to project scope and location).

Documentation Package: Each module ships with installation instructions, terminal wiring diagrams, electrical schematics, dimensional drawings, and compliance certificates. CAD models and relay characteristic curves available upon request for system integrators.

Quality Certifications: Manufactured under ISO 9001 quality management systems, with traceability documentation, factory acceptance testing (FAT) reports, and calibration certificates available for projects requiring full material traceability.

Frequently Asked Questions (FAQ)

Q: How does the Bently Nevada 81672-01 relay output module interface with existing 3300 monitoring racks?
A: The module uses a plug-in design with keyed backplane connectors that automatically establish power and signal connections when inserted into any available 3300 rack slot. No external wiring is required between the module and monitor channels—relay activation is controlled by the monitor's internal alarm logic. External wiring connects only to the front-panel terminal blocks for routing relay contacts to your control system or alarm panel.

Q: What is the maximum number of relay modules that can be installed in a single 3300 rack?
A: This depends on your specific 3300 rack model and power supply capacity. Standard 8-slot and 16-slot racks can typically accommodate 4-12 relay modules alongside monitor modules, but exact capacity should be verified using Bently Nevada's rack configuration tools or by consulting the rack power budget specifications. Our engineers can perform a load analysis based on your complete system configuration.

Q: What energy savings or efficiency improvements can be expected with relay output modules?
A: While relay modules themselves don't directly reduce energy consumption, they enable automated machinery protection that prevents catastrophic failures, unplanned shutdowns, and secondary equipment damage—events that often result in 20-40% efficiency losses during restart and recovery. By facilitating early-warning shutdowns and condition-based maintenance, properly configured relay outputs contribute to overall plant availability improvements of 2-5% in continuous process industries.

Q: What are the environmental and installation requirements for the 81672-01 module?
A: The module operates reliably in industrial environments from -30°C to +65°C with up to 95% non-condensing humidity. It should be installed in a 3300 rack mounted in a clean, vibration-controlled cabinet or control room—avoid direct exposure to corrosive atmospheres, conductive dust, or condensing moisture. The rack enclosure should provide IP54 or better protection, with adequate ventilation to maintain internal temperatures below 55°C for optimal relay contact life.

Q: Can the relay outputs be monitored remotely, and what communication protocols are supported?
A: The relay module itself provides hardwired contact outputs without native digital communication. However, relay status can be integrated into remote monitoring systems by connecting contacts to PLC/DCS digital inputs, which then communicate via Modbus TCP, OPC UA, HART, or proprietary protocols to SCADA and cloud platforms. For direct digital integration, consider pairing with Bently Nevada 3500 series monitors that offer Modbus and Ethernet/IP connectivity alongside traditional relay outputs.

Q: Is the 81672-01 suitable for Safety Instrumented System (SIS) applications requiring SIL certification?
A: The 81672-01 is designed for machinery protection and alarm applications compliant with API 670, but it is not individually SIL-certified. For SIL-rated applications, the module can be used as part of a certified system architecture (such as TMR or 2oo3 voting) when combined with SIL-certified monitors and logic solvers, with appropriate failure mode analysis and proof testing intervals documented in your Safety Requirements Specification (SRS).

Request Technical Support & Custom Solutions

To receive detailed application engineering support, configuration drawings, or project quotations, please provide the following information: project name and industry sector, specific monitoring application (turbine/compressor/pump model), number of monitoring points and required relay outputs, control system interface requirements (voltage, contact configuration), environmental conditions, and any special certifications needed. Our engineering team will respond within 24 hours with tailored recommendations, rack layout proposals, and pricing.
