5m Extension Cable for Bently Nevada 3300 XL Proximity System | 21504-00-48-05-02

5m Extension Cable for Bently Nevada 3300 XL Proximity System (Industrial-Grade Signal Transmission)

The Bently Nevada 21504-00-48-05-02 is a factory-calibrated 5-meter extension cable designed specifically for 3300 XL proximity transducer systems. Through precision coaxial construction and low-capacitance design, it maintains signal integrity and measurement accuracy across extended distances, enabling reliable vibration and position monitoring in critical rotating machinery applications.

Ideal for turbomachinery installations, power generation facilities, oil & gas compressor stations, and industrial process equipment where sensor-to-monitor distances exceed standard cable lengths. This extension cable solves challenges including signal degradation over distance, electromagnetic interference in high-noise environments, installation flexibility constraints, and the need for field-proven reliability in continuous operation scenarios.

Featuring factory calibration, rugged construction, and compatibility with the complete 3300 XL ecosystem, this cable delivers consistent performance, simplified installation procedures, and long-term measurement stability. Suitable for OEMs, plant maintenance teams, instrumentation contractors, and condition monitoring specialists. Contact our application engineers for cable routing recommendations and system integration support.

Core Features & Technical Advantages

Factory-Calibrated Performance
Each cable is calibrated as part of the complete proximity system, ensuring accurate gap voltage output and eliminating field calibration requirements. This reduces commissioning time and maintains measurement traceability.

Low-Noise Coaxial Design
Precision coaxial construction with controlled impedance minimizes signal attenuation and electromagnetic interference pickup, preserving the integrity of low-level proximity sensor signals even in electrically noisy industrial environments.

Extended Reach Capability
The 5-meter length provides installation flexibility for applications where monitors must be located away from the measurement point, such as panel-mounted systems or distributed monitoring architectures.

Robust Industrial Construction
Built with durable jacket materials and strain relief features to withstand vibration, temperature cycling, and mechanical stress typical of turbomachinery installations, reducing maintenance frequency and replacement costs.

Seamless System Integration
Standard BNC connectors ensure plug-and-play compatibility with 3300 XL proximity probes and Proximitor sensors, simplifying installation and enabling quick sensor replacement without system reconfiguration.

Proven Reliability
Manufactured to Bently Nevada quality standards with materials selected for long-term stability, this cable supports continuous operation in mission-critical monitoring applications where downtime is not an option.

Typical Application Scenarios

This extension cable is engineered for installations requiring stable signal transmission over extended distances, particularly in:

Steam & Gas Turbine Monitoring
Connects proximity sensors on turbine casings to control room monitoring systems, enabling real-time shaft position and vibration measurement while maintaining safe distances from high-temperature zones.

Centrifugal Compressor Protection
Facilitates distributed sensor placement on multi-stage compressors in oil & gas and petrochemical facilities, supporting API 670 machinery protection system requirements with reliable signal integrity.

Large Motor & Generator Surveillance
Extends sensor reach in power generation and heavy industrial applications where monitors are panel-mounted away from rotating equipment, ensuring continuous bearing and rotor position monitoring.

Pump & Fan Condition Monitoring
Enables flexible sensor installation on process pumps, cooling tower fans, and HVAC equipment where space constraints or environmental conditions require remote monitor placement.

Retrofit & Upgrade Projects
Provides the additional cable length needed when upgrading legacy monitoring systems or relocating monitors during plant modernization without requiring complete sensor system replacement.

Technical Specifications & Selection Guide

To ensure optimal system performance, please verify compatibility with your existing 3300 XL proximity system configuration:

Cable Length: 5 meters (16.4 feet)
Cable Type: Low-noise coaxial, factory-calibrated
Connector Type: BNC male to BNC female
Compatible Systems: Bently Nevada 3300 XL Proximity Transducer System
Operating Temperature: -40°C to +85°C (-40°F to +185°F)
Jacket Material: Industrial-grade polymer, oil and chemical resistant
Impedance: Matched to 3300 XL system requirements
Bend Radius: Minimum 10x cable diameter
Weight: Approximately 0.2 kg

Selection Considerations:
When specifying extension cables, consider total system cable length (probe cable + extension cable), environmental conditions (temperature, chemical exposure, mechanical stress), routing path and bend radius requirements, and electromagnetic interference sources. For applications requiring cable lengths beyond 5 meters or custom configurations, consult with our application engineers who can recommend optimal solutions based on your specific installation parameters.

System Integration & Compatibility

This extension cable is designed for seamless integration within the Bently Nevada 3300 XL proximity monitoring ecosystem:

Compatible Proximity Probes: 3300 XL 5mm, 8mm, and 11mm proximity probes (all cable lengths)
Compatible Proximitor Sensors: 3300 XL Proximitor sensors and extension Proximitor sensors
Monitor Compatibility: 3300 XL proximity monitors and rack-mounted monitoring systems
System Standards: Meets API 670 machinery protection system requirements when used as part of certified 3300 XL configurations

Installation Notes:
Maintain proper cable routing practices to avoid sharp bends and mechanical stress points. Secure cables away from high-voltage power lines and variable frequency drives to minimize EMI. Use cable ties or clamps at regular intervals to prevent vibration-induced fatigue. Verify connector tightness after installation and during routine maintenance inspections.

Delivery, Support & Quality Assurance

Lead Time: Standard catalog items typically ship within 3-5 business days; custom cable assemblies require 2-3 weeks
Warranty: 12-month manufacturer warranty covering materials and workmanship defects
Technical Support: Application engineering assistance available for system design, cable routing optimization, and troubleshooting
Documentation: Each cable ships with calibration certificate, dimensional drawings, and installation guidelines

Our team provides remote technical consultation for installation planning and on-site commissioning support for large-scale projects (availability varies by region). Complete system documentation including wiring diagrams, connector pinouts, and maintenance procedures is available upon request to facilitate seamless integration and long-term serviceability.
