9905-708 Woodward DSLC Controller (Industrial-Grade Synchronization System)

The Woodward 9905-708 DSLC (Digital Synchronizer and Load Control) is a microprocessor-based controller engineered for automatic synchronization and proportional load distribution across paralleled three-phase AC generators. Designed for continuous-duty applications in power generation facilities, this module eliminates manual intervention while maintaining grid stability and equipment longevity through precision phase-angle matching and real-time load balancing algorithms.

Industrial operators rely on the 9905-708 to coordinate multiple generator sets in mission-critical environments where power interruption translates to production losses, safety hazards, or regulatory non-compliance. The controller's adaptive synchronization logic accommodates voltage fluctuations, frequency drift, and transient loads without compromising system integrity.

Key differentiators include ±2% load-sharing accuracy, wide operating temperature range (-40°C to +70°C), and Modbus RTU communication for SCADA integration. Whether managing diesel gensets in remote mining operations or coordinating backup power in healthcare facilities, the 9905-708 delivers deterministic control with field-proven reliability.

Core Capabilities & Technical Advantages

→ Automatic Synchronization Logic
Continuously monitors voltage magnitude, phase angle, and frequency differential between incoming generator and live bus. Executes breaker closure only when parameters converge within adjustable tolerances (±5° to ±30° phase window), preventing mechanical shock and electrical stress during paralleling operations.

✓ Proportional Load Distribution
Distributes active (kW) and reactive (kVAR) power across paralleled units based on droop or isochronous control modes. Real-time compensation adjusts for fuel quality variations, ambient temperature effects, and component aging to maintain balanced operation within ±2% of setpoint.

→ Multi-Voltage Compatibility
Supports 100-690 VAC three-phase systems with auto-sensing 50/60 Hz operation. Dual power supply options (18-32 VDC or 88-132 VAC) enable flexible installation in diverse electrical architectures without external converters.

✓ Industrial Communication Protocol
RS-485 Modbus RTU interface enables remote monitoring, parameter adjustment, and alarm retrieval through SCADA systems or Woodward GAP configuration software. Supports multi-drop networks for centralized control of distributed generation assets.

→ Fail-Safe Operation Mode
Retains last known load setpoints during communication loss, allowing autonomous operation until network restoration. Built-in diagnostics detect sensor faults, wiring errors, and out-of-range conditions with configurable alarm outputs.

✓ Harsh Environment Durability
Conformal-coated PCB and ruggedized enclosure withstand vibration, humidity, and temperature extremes common in marine, offshore, and industrial installations. Extended temperature rating (-40°C to +70°C) eliminates need for climate-controlled enclosures.

Industrial Application Scenarios

Scenario 1: Peak-Shaving in Manufacturing Plants
A metal fabrication facility operates three 1.5 MW diesel generators to supplement grid power during high-demand shifts. The 9905-708 synchronizes each genset with the utility feed and distributes load proportionally, reducing demand charges by 23% while maintaining power quality for CNC machines and robotic welders. Automatic load transfer prevents production downtime during utility voltage sags.

Scenario 2: Island-Mode Microgrids
A remote mining operation relies on four 2 MW generators for continuous power. The DSLC controller manages generator start sequencing, load addition/shedding, and reverse power protection. When ore processing equipment creates sudden 800 kW load steps, the controller redistributes power within 200 milliseconds, preventing frequency excursions that would trip protective relays.

Scenario 3: Data Center N+1 Redundancy
A Tier III data center deploys five 2.5 MW gensets in parallel configuration with utility grid connection. The 9905-708 executes seamless transfer between utility and generator power during grid disturbances, maintaining IT load continuity. Load sharing ensures no single generator exceeds 80% capacity, preserving reserve margin for cooling system transients.

Scenario 4: Marine Propulsion Systems
A commercial vessel uses three 1.8 MW generators for propulsion drives and hotel loads. The controller balances electrical load across gensets while accommodating dynamic propulsion demands during maneuvering. Automatic synchronization enables online maintenance—operators can isolate one generator for service while remaining units carry full load.

Scenario 5: Hospital Emergency Power
A 400-bed hospital maintains three 1 MW backup generators for life-safety systems. The 9905-708 performs weekly automatic test cycles, synchronizing generators with utility power to verify readiness without disrupting clinical operations. During actual outages, the controller sequences generator starts and transfers critical loads within 10 seconds per NFPA 110 requirements.

Technical Parameters & Selection Guide

Selection Criteria: Choose the 9905-708 when your application requires synchronization of 2-8 generators in parallel configuration with standard I/O requirements. For systems exceeding 8 generators or requiring expanded analog/digital I/O, consider the 9905-973 variant. Verify that your generator governor supports droop or isochronous control modes—older mechanical governors may require retrofit with electronic actuators for optimal load sharing performance.

Extended Integration Capabilities

SCADA System Connectivity: The Modbus RTU interface exposes 150+ data points including real-time voltage, current, power factor, frequency, and alarm status. Third-party HMI systems (Wonderware, Ignition, FactoryTalk) can poll the controller at 100ms intervals for supervisory control and historical trending.

Hybrid Power System Coordination: When integrated with solar inverters or battery energy storage systems, the 9905-708 manages generator dispatch based on renewable availability and load demand. Custom logic programming enables peak-shaving strategies that minimize diesel runtime while maintaining spinning reserve requirements.

Customization Options: Factory configuration services include pre-programmed synchronization parameters, custom alarm setpoints, and application-specific I/O mapping. Field reprogramming via GAP software allows operators to adjust control strategies without hardware modifications.

Delivery Timeline & Service Commitment

Standard Lead Time: 3-5 business days for in-stock units with factory-sealed packaging. Express shipping available for critical outage situations.

Custom Configuration: 7-10 business days for units requiring pre-commissioning, parameter programming, or integration testing with customer-supplied equipment.

Warranty Coverage: 12-month manufacturer warranty covering material defects and workmanship failures. Warranty includes advance replacement service—receive a functional unit before returning the defective module to minimize downtime.

Technical Support: Lifetime access to application engineers for installation guidance, troubleshooting assistance, and control optimization. Support includes wiring diagram review, Modbus register mapping, and remote commissioning via TeamViewer or similar platforms.

Documentation Package: Each unit ships with installation manual, quick-start guide, Modbus register map, and CAD drawings (DXF/PDF formats). Firmware update procedures and GAP software license included at no additional cost.

Frequently Asked Questions

Q: Can the 9905-708 synchronize generators with different power ratings?
A: Yes, the controller supports mixed-capacity generator sets ranging from 50 kW to 5 MW per unit. Load sharing is proportional to each generator's rated output—a 1 MW unit will carry twice the load of a 500 kW unit when paralleled. Configure individual droop settings to account for governor response differences between dissimilar engines.

Q: What happens if Modbus communication fails during parallel operation?
A: The 9905-708 includes autonomous fail-safe logic that maintains the last valid load setpoint and continues regulating synchronization. Local control via front-panel keypad remains functional, allowing operators to manually adjust load distribution or initiate controlled shutdown sequences. Communication loss triggers a configurable alarm output for SCADA notification.

Q: How does the controller handle sudden large load steps?
A: The DSLC's load-sharing algorithm responds to load transients within 200 milliseconds, redistributing power across paralleled generators before frequency deviation exceeds ±0.5 Hz. For applications with frequent impact loads (motor starts, welders), enable the "fast response" mode which increases control loop update rate from 50ms to 20ms at the cost of slightly higher electrical noise sensitivity.

Q: Is the 9905-708 compatible with renewable energy sources?
A: The controller can coordinate with grid-tied solar inverters and wind turbines when configured as the master synchronization reference. Renewable sources must include anti-islanding protection and comply with IEEE 1547 interconnection standards. For off-grid hybrid systems, pair the 9905-708 with battery inverters that support droop control or frequency-watt response curves.

Q: What training is required for commissioning and maintenance?
A: Basic electrical knowledge and familiarity with three-phase power systems are prerequisites. Woodward offers online training modules covering installation, parameter configuration, and troubleshooting procedures. For complex applications (>4 generators, hybrid systems), on-site commissioning support is recommended to optimize control parameters and validate protection schemes.

Q: Can I retrofit the 9905-708 into an existing manual synchronization system?
A: Yes, the controller integrates with legacy switchgear using standard voltage and current transformers (VTs/CTs). Existing synchroscopes and manual controls can remain in place as backup systems. Typical retrofit requires adding the DSLC module, connecting sensing inputs, and interfacing breaker control outputs—most installations complete within 8-12 hours per generator.
