8440-2028 Digital I/O Extension Module (Industrial-Grade Control Expansion)

The 8440-2028 represents a field-proven solution for expanding digital control points in generator management and industrial automation systems. Built around robust 24 VDC architecture with dual 8-channel configurations, this extension module addresses capacity constraints in easYgen-3000 series and GCP-31/32 platforms through standardized CAN Bus connectivity.

Designed for system integrators and facility engineers managing distributed power generation assets, the module eliminates the need for controller replacement when I/O requirements exceed baseline capacity. Its DIN-rail mounting and auto-discovery protocol reduce commissioning time while maintaining deterministic communication across extended networks.

Key differentiators include wide-temperature operation (-40°C to +70°C), solid-state output reliability rated at 0.5A per channel, and seamless integration with Woodward's configuration ecosystem—delivering scalable control architecture without proprietary software dependencies.

Core Features & Benefits

✓ Dual 8-Channel Architecture
Provides 8 configurable digital inputs and 8 digital outputs operating at 24 VDC nominal voltage. Enables monitoring of discrete sensors (temperature switches, pressure contacts, emergency stops) while controlling pilot relays, indicator lamps, and auxiliary contactors—all within a single compact module.

✓ CAN Bus Network Integration
Utilizes industry-standard CAN 2.0B protocol for deterministic communication up to 1 Mbit/s over 40-meter distances. Supports daisy-chaining up to 8 modules per controller, creating distributed I/O topologies that reduce wiring complexity in large genset installations and multi-unit power plants.

✓ Extended Environmental Rating
Operates reliably across -40°C to +70°C ambient temperature range with IP20 ingress protection. Suitable for engine rooms, outdoor enclosures with climate control, and industrial environments where temperature fluctuations challenge standard control equipment.

✓ Auto-Discovery Configuration
Module automatically registers within easYgen or GCP controller networks upon power-up, eliminating manual addressing procedures. Configuration performed through native controller interface using Woodward ToolKit software—no separate programming environment required.

✓ Solid-State Output Design
Employs semiconductor switching technology rated for 500mA continuous per channel, delivering faster response times and longer service life compared to electromechanical relays. Ideal for high-cycle applications like valve sequencing and alarm annunciation systems.

→ Industrial Compliance Standards
Meets CE marking requirements and UL recognition for industrial control equipment. Designed to withstand electrical noise environments typical of generator facilities through isolated input/output circuits and EMC-compliant construction.

Application Scenarios

Prime Power Generation Facilities
Data centers and hospitals requiring N+1 redundancy deploy the 8440-2028 to monitor auxiliary systems—fuel level sensors, coolant temperature switches, battery charger status—while controlling transfer switch interlocks and remote alarm panels. The module's network architecture allows centralized monitoring of distributed gensets without dedicated I/O wiring to each unit.

Emergency Standby Systems
Critical infrastructure installations use the module to implement safety interlocks mandating pre-start checks (oil pressure confirmation, coolant level verification) and post-shutdown sequences (cooldown timers, fuel valve closure). Additional I/O capacity enables integration with building management systems for coordinated emergency response.

Industrial Cogeneration Plants
Combined heat and power facilities leverage the 8440-2028 for heat recovery system control—monitoring steam pressure transducers, controlling diverter valves, and interfacing with thermal storage systems. Distributed I/O placement near process equipment minimizes signal degradation in electrically noisy environments.

Marine & Offshore Platforms
Vessel propulsion and platform power systems utilize the module's wide-temperature rating and vibration-resistant DIN-rail mounting for engine room installations. Additional I/O supports bilge pump control, fire suppression system integration, and navigation light monitoring required by maritime regulations.

Rental Power & Temporary Installations
Mobile genset providers configure the 8440-2028 for rapid deployment scenarios requiring temporary load management—construction sites, outdoor events, disaster recovery operations. Modular design allows pre-configured assemblies to be swapped between rental units, reducing setup time and standardizing control interfaces.

Technical Parameters & Selection Guide

Selection Criteria: Choose the 8440-2028 when your easYgen-3000 or GCP-31/32 controller requires additional discrete I/O beyond built-in capacity. Verify total I/O count requirements including future expansion—each module adds 16 points (8 in + 8 out). For applications demanding analog signal processing, consider pairing with Woodward 5466-332 Analog I/O Module. Installations exceeding 8 extension modules require controller upgrade or network segmentation.

Extended Functions

IoT Integration Capabilities
When paired with easYgen-3500XT controllers featuring Ethernet connectivity, the 8440-2028's I/O points become accessible via Modbus TCP protocol for SCADA integration. This enables remote monitoring dashboards, predictive maintenance analytics, and cloud-based fleet management without additional gateway hardware.

Advanced Sequencing Logic
Utilize the module's I/O for implementing complex start/stop sequences—staggered generator paralleling, load-dependent auxiliary equipment activation, and time-delayed safety interlocks. Configuration through Woodward's ladder logic interface allows custom control strategies without external PLC investment.

Customization Options
While the 8440-2028 ships as a standard catalog item, system integrators can request factory pre-configuration with specific I/O assignments and network addresses for large-scale deployments. Contact technical sales for volume orders requiring custom labeling or extended environmental testing documentation.

Delivery & Service Assurance

Lead Time: Standard stock items ship within 3-5 business days from order confirmation. Custom-configured modules or bulk orders (10+ units) require 2-3 weeks for preparation and testing. Expedited shipping available for critical outage situations—contact our support team for emergency procurement options.

Warranty Coverage: Each 8440-2028 module includes a comprehensive 12-month manufacturer warranty covering defects in materials and workmanship. Warranty terms align with Woodward's global service policy, providing repair or replacement at our discretion. Extended warranty programs available for mission-critical installations.

Technical Support: Our application engineers provide pre-sales consultation for system design, configuration assistance during commissioning, and troubleshooting support throughout the product lifecycle. Support includes CAN Bus network diagnostics, I/O wiring verification, and integration guidance with third-party equipment.

Documentation Package: Every module ships with installation quick-start guide, dimensional drawings for panel layout, and wiring diagrams. Complete technical manuals, configuration software, and CAD files available for download from our technical library. Multilingual documentation supports global deployment teams.

Frequently Asked Questions

How many 8440-2028 modules can I connect to a single easYgen-3000 controller?
The CAN Bus architecture supports up to 8 extension modules per controller, providing a maximum of 128 additional I/O points (64 inputs + 64 outputs). Exceeding this limit requires network segmentation or controller upgrade to higher-capacity models.

What cable specifications are required for CAN Bus connections between modules?
Use twisted-pair cable with 120-ohm characteristic impedance (DeviceNet or CANopen certified cable recommended). Maximum segment length is 40 meters at 1 Mbit/s; longer distances require reduced baud rates (500 kbit/s for 100m, 250 kbit/s for 250m) or CAN repeaters for extended networks.

Can the digital outputs drive inductive loads like solenoid valves directly?
The solid-state outputs are rated for 0.5A continuous at 24 VDC, suitable for small pilot relays and indicator lamps. For inductive loads exceeding 12W (solenoid coils, contactors), use external interposing relays with flyback diode protection to prevent voltage spikes that may damage output circuits.

Does the module require separate configuration software beyond the controller interface?
No additional software is needed—all configuration is performed through the easYgen or GCP controller's native interface using Woodward ToolKit (free download). The module auto-discovers upon network connection, and I/O points are assigned through the controller's configuration menus.

What happens if CAN Bus communication fails during operation?
The controller detects communication loss within 100ms and triggers a configurable alarm. I/O states can be programmed to fail-safe (all outputs de-energize) or hold-last-state depending on application safety requirements. Redundant CAN networks are not supported; critical applications should implement controller-level redundancy.

Is the 8440-2028 compatible with older easYgen-2000 series controllers?
No, the module requires easYgen-3000 series (3100/3200/3300/3400/3500) or GCP-31/32 controllers with CAN Bus support. Older easYgen-2000 and easYgen-1000 systems use different expansion protocols and are not compatible. Controller firmware must be version 1.3 or higher for full functionality.
