Siemens SCALANCE X102-1 Industrial Ethernet Media Converter | Copper to Fiber Optic | 6GK5102-1GS00-2AC2

SCALANCE X102-1 Industrial Ethernet Media Converter (Copper-to-Fiber Solution)

The Siemens 6GK5102-1GS00-2AC2 SCALANCE X102-1 is a professional-grade unmanaged industrial Ethernet media converter designed for reliable copper-to-fiber optic signal conversion in demanding industrial environments. Through advanced optical transmission technology and ruggedized construction, it enables seamless integration of fiber optic networks into existing copper-based Ethernet infrastructures, extending network reach up to 2 kilometers while maintaining signal integrity.

Ideal for manufacturing plants, process automation systems, power substations, and harsh industrial facilities where electromagnetic interference (EMI), electrical isolation, or long-distance connectivity is critical. This media converter addresses common challenges including limited copper cable distance (100m), susceptibility to electrical noise, ground loop issues, and the need for galvanic isolation between network segments.

Engineered with industrial-grade components and proven SCALANCE reliability, the X102-1 delivers plug-and-play operation, extended temperature tolerance (-40°C to +70°C), and maintenance-free performance. Suitable for system integrators, automation engineers, plant operators, and OEM equipment manufacturers requiring robust network infrastructure. Contact our technical team for application-specific configuration guidance and project quotations.

Core Features & Technical Advantages

Reliable Copper-to-Fiber Conversion
Converts 10/100 Mbps Ethernet signals from RJ45 copper to multimode fiber optic (SC connector), enabling distance extension up to 2km and eliminating copper cable length limitations in industrial networks.

Industrial-Grade Environmental Resistance
Operating temperature range of -40°C to +70°C ensures stable performance in extreme conditions including outdoor installations, unheated enclosures, and high-temperature process areas without additional climate control.

Electrical Isolation & EMI Immunity
Fiber optic transmission provides complete galvanic isolation between network segments, eliminating ground loops and protecting sensitive equipment from electrical surges, lightning strikes, and electromagnetic interference common in industrial settings.

Plug-and-Play Unmanaged Operation
Auto-negotiation and auto-MDI/MDIX functionality enable instant deployment without configuration, reducing installation time and eliminating the need for specialized networking expertise during commissioning.

Compact DIN-Rail Mounting Design
Space-efficient form factor with standard DIN-rail mounting clips allows easy integration into control cabinets, junction boxes, and distributed I/O enclosures alongside PLCs, drives, and other automation components.

Proven SCALANCE Reliability
Built to Siemens industrial networking standards with MTBF-rated components, redundant power input options (model-dependent), and comprehensive diagnostic LEDs for quick troubleshooting and predictive maintenance.

Typical Application Scenarios

The SCALANCE X102-1 media converter is engineered for industrial networks requiring distance extension, electrical isolation, or fiber backbone integration, particularly in:

Factory Automation & Manufacturing Lines
Connects remote machine control panels, robotic cells, and distributed I/O racks to central control systems across production floors, overcoming the 100-meter copper cable limitation while maintaining real-time communication for PROFINET, EtherNet/IP, and Modbus TCP protocols.

Process Control & SCADA Systems
Links field instrumentation, remote terminal units (RTUs), and process analyzers in chemical plants, oil & gas facilities, and water treatment systems where electrical isolation is mandatory for safety compliance and noise immunity is critical for measurement accuracy.

Power Substations & Utility Infrastructure
Provides galvanically isolated Ethernet connectivity for protective relays, intelligent electronic devices (IEDs), and substation automation equipment, meeting IEEE 1613 and IEC 61850 requirements for electrical isolation in high-voltage environments.

Building Automation & Infrastructure Networks
Extends BACnet/IP, LonWorks, and KNX networks across campus buildings, parking structures, and outdoor facilities using existing fiber optic infrastructure, reducing installation costs compared to new copper cable runs.

Transportation & Logistics Systems
Connects conveyor controllers, automated guided vehicles (AGVs), and warehouse management systems in distribution centers and logistics hubs where long cable runs and electrical noise from motor drives require fiber optic solutions.

Technical Specifications & Selection Guide

To ensure optimal performance and compatibility, the SCALANCE X102-1 offers the following standard specifications. Custom configurations and extended-range models are available for specialized applications.

Key Technical Parameters:

• Ethernet Ports: 1× RJ45 10/100BASE-TX (copper) + 1× SC 100BASE-FX (multimode fiber)
• Fiber Type: Multimode 50/125 µm or 62.5/125 µm
• Transmission Distance: Up to 2 km (multimode fiber, 850nm wavelength)
• Data Rate: 10/100 Mbps auto-negotiation
• Operating Voltage: 24 VDC (18-32 VDC range, model-dependent)
• Power Consumption: Typically < 5W
• Operating Temperature: -40°C to +70°C
• Protection Rating: IP20 (for cabinet installation)
• Mounting: Standard 35mm DIN rail
• Dimensions: Compact modular housing (approx. 40mm width)
• Certifications: CE, UL, cULus, ATEX/IECEx (zone-dependent models)

Selection Considerations:
When specifying the SCALANCE X102-1 for your project, consider the following factors: required transmission distance (2km standard, longer distances require single-mode fiber models), fiber type availability (multimode vs. single-mode infrastructure), power supply voltage (24 VDC standard), environmental conditions (temperature, vibration, humidity), and protocol requirements (transparent for all Ethernet-based protocols). For applications requiring redundant power inputs, managed features, or ring topology support, consult our SCALANCE X200 series alternatives.

For technical assistance with product selection, please provide: network topology diagram, required transmission distances, existing fiber infrastructure details (type, connector, strand count), environmental conditions, and protocol/application requirements. Our application engineers will recommend the optimal configuration and provide integration support.

Extended Capabilities & Integration Options

Network Topology Flexibility: Supports point-to-point fiber links, star topologies with fiber distribution, and integration into existing fiber backbones. Compatible with standard Ethernet switches, industrial managed switches (SCALANCE X200/X300), and IT networking equipment.

Protocol Transparency: Operates at Layer 1 (physical layer), ensuring full transparency for all Ethernet-based industrial protocols including PROFINET RT/IRT, EtherNet/IP, Modbus TCP, OPC UA, BACnet/IP, and standard TCP/IP applications without protocol conversion or latency.

Diagnostic & Monitoring: Front-panel LED indicators provide real-time status for power, link activity, and fault conditions. Supports integration with SNMP-managed networks when used with SCALANCE managed switches for centralized monitoring.

Redundancy & Availability: Can be deployed in redundant configurations using dual fiber paths and external network redundancy protocols (MRP, RSTP) when combined with managed SCALANCE switches, achieving high-availability network architectures for critical applications.

Delivery, Support & Quality Assurance

Lead Time: Standard catalog items typically ship within 3-5 business days from regional stock. Custom configurations or large-volume orders may require 2-4 weeks. Expedited delivery available for urgent projects.

Warranty & Service: Backed by Siemens standard 12-month manufacturer warranty covering defects in materials and workmanship. Extended warranty and service agreements available through authorized Siemens partners.

Technical Support: Comprehensive installation documentation including quick start guide, wiring diagrams, and DIN-rail mounting instructions provided with each unit. Remote technical assistance and on-site commissioning support available through Siemens Industry Services (region-dependent).

Documentation Package: Each shipment includes product datasheet, installation manual, electrical connection diagram, fiber optic cable specifications, and compliance certificates. CAD drawings and 3D models available for panel design integration.

Quality Standards: Manufactured in Siemens certified facilities under ISO 9001 quality management systems. All units undergo 100% functional testing including fiber optic link verification, temperature cycling, and vibration testing before shipment.

Frequently Asked Questions (FAQ)

Q: How do I connect the SCALANCE X102-1 media converter to my existing copper Ethernet network?
A: Simply connect your standard Ethernet cable (Cat5e/Cat6) to the RJ45 port on the converter, and connect the fiber optic cable (with SC connectors) to the fiber port. The converter auto-negotiates speed (10/100 Mbps) and polarity (auto-MDI/MDIX), requiring no configuration. Ensure your fiber cable matches the specifications (multimode, 2km max distance).

Q: What is the maximum transmission distance supported by this model?
A: The 6GK5102-1GS00-2AC2 supports up to 2 kilometers transmission distance using multimode fiber (50/125µm or 62.5/125µm) at 100 Mbps. For longer distances (up to 20km or more), consider single-mode fiber variants in the SCALANCE X100 series.

Q: Can this media converter be used in hazardous area (ATEX/IECEx) installations?
A: The standard X102-1 model is rated IP20 for cabinet installation in non-hazardous areas. For Zone 2/Division 2 hazardous locations, Siemens offers ATEX/IECEx certified variants. Consult the product selector or contact technical support for hazardous area applications.

Q: Does the converter require configuration or management software?
A: No. The SCALANCE X102-1 is an unmanaged device with plug-and-play operation. It transparently converts signals between copper and fiber without requiring IP addresses, configuration software, or network management. For managed features (SNMP, port mirroring, VLAN), consider the SCALANCE X200 managed switch series.

Q: What power supply voltage is required, and are redundant power inputs available?
A: The standard model operates on 24 VDC (typical range 18-32 VDC) with a single power input. Some SCALANCE X100 variants offer dual redundant power inputs for high-availability applications. Verify your specific model's datasheet or specify redundant power requirements when ordering.

Q: Is the converter compatible with PROFINET, EtherNet/IP, and other industrial protocols?
A: Yes. As a Layer 1 physical media converter, the X102-1 is fully transparent to all Ethernet-based protocols including PROFINET (RT and IRT), EtherNet/IP, Modbus TCP, OPC UA, BACnet/IP, and standard IT protocols. It does not inspect or modify data packets, ensuring protocol compatibility and deterministic timing.

Request Technical Support & Quotation

For detailed application engineering, custom configurations, or project quotations, please provide the following information to our technical team:

• Project name and application description
• Network topology and transmission distance requirements
• Existing fiber infrastructure details (type, connector, available strands)
• Quantity required and delivery timeline
• Environmental conditions (temperature range, IP rating, hazardous area classification)
• Industrial protocol requirements (PROFINET, EtherNet/IP, etc.)

Our application engineers will provide one-on-one selection guidance, integration recommendations, and competitive pricing for your industrial networking project.
