Siemens SCALANCE X005 Industrial Ethernet Switch | 5-Port Unmanaged DIN Rail Network Hub | 6GK5005-0BA00-1AB2

Siemens SCALANCE X005 Industrial Ethernet Switch (Unmanaged Network Solution for Automation Systems)

The Siemens 6GK5005-0BA00-1AB2 SCALANCE X005 is a compact, unmanaged industrial Ethernet switch designed for reliable network connectivity in factory automation, process control, and industrial IoT applications. Featuring 5x 10/100 Mbps RJ45 ports and robust DIN rail mounting, this switch delivers plug-and-play simplicity for connecting PLCs, HMIs, drives, sensors, and other industrial devices in harsh manufacturing environments.

Ideal for machine builders, system integrators, and plant engineers seeking cost-effective network expansion without complex configuration. The SCALANCE X005 ensures stable data transmission in production lines, packaging systems, material handling equipment, and building automation networks where downtime is not an option.

Engineered with industrial-grade components and IP20 protection, this switch withstands temperature extremes, vibration, and electromagnetic interference common in factory floors. Whether you're upgrading legacy systems or building new automation networks, the X005 provides proven Siemens quality with straightforward installation and long-term reliability. Contact our automation specialists for application guidance, technical drawings, and volume pricing.

Core Features & Technical Advantages

Plug-and-Play Unmanaged Operation
Zero configuration required—simply connect devices and power on. Auto-negotiation and auto-MDI/MDIX on all ports eliminate the need for crossover cables, reducing installation time by up to 40% compared to managed switches in simple topologies.

Industrial-Grade Reliability
Built to IEC 61850-3 and IEEE 802.3 standards with extended operating temperature range (-40°C to +70°C). Metal housing with efficient heat dissipation ensures continuous operation in dusty workshops, high-temperature furnace areas, and outdoor cabinets without active cooling.

Compact DIN Rail Design
Space-saving 30mm width fits standard 35mm DIN rails, allowing installation in crowded control panels alongside PLCs and I/O modules. Secure snap-on mounting with integrated cable management reduces wiring clutter and simplifies maintenance access.

Fast Ethernet Performance
Store-and-forward switching with 1 Mbps wire-speed throughput ensures deterministic communication for time-sensitive automation protocols like PROFINET, Modbus TCP, and EtherNet/IP. Low latency (<10μs) supports real-time control loops and high-frequency data acquisition.

Robust EMC & Surge Protection
Compliant with EN 61000-6-2/4 electromagnetic compatibility standards. Built-in surge protection on power and data lines guards against voltage spikes from motor drives, welding equipment, and lightning-induced transients, reducing unplanned downtime.

Flexible Power Supply Options
Accepts 24V DC nominal input (18-32V DC range), compatible with standard industrial power supplies. Low power consumption (<3W) enables operation from battery backup systems during grid outages, maintaining network connectivity for critical monitoring functions.

Typical Application Scenarios

This industrial Ethernet switch is engineered for environments demanding continuous uptime, environmental resilience, and seamless integration with automation ecosystems:

Manufacturing Production Lines & Assembly Cells
Connect multiple robots, vision systems, barcode scanners, and quality inspection stations to a central PLC network. The X005's unmanaged architecture eliminates configuration errors during line changeovers, while its compact size fits into machine-mounted junction boxes.

Process Control & SCADA Systems
Expand Ethernet networks in chemical plants, water treatment facilities, and oil & gas installations where devices are distributed across large areas. Rugged construction withstands corrosive atmospheres and temperature cycling in pump houses and outdoor enclosures.

Building Automation & HVAC Networks
Integrate chillers, air handlers, lighting controllers, and energy meters into BACnet/IP or Modbus TCP networks. DIN rail mounting simplifies retrofit installations in existing electrical rooms without requiring additional rack space.

Material Handling & Warehouse Automation
Link conveyor controllers, sortation systems, automated guided vehicles (AGVs), and warehouse management terminals. The switch's vibration resistance and wide temperature tolerance suit high-bay storage environments and loading dock areas.

Machine Tool & CNC Networks
Provide Ethernet connectivity for CNC machines, tool changers, coolant systems, and part measurement devices. Fast switching performance supports high-speed data transfer for CAM programs and real-time machining parameter adjustments.

Technical Specifications & Selection Guide

To ensure optimal performance and compatibility, review the following specifications when planning your network architecture:

Network Interface: 5x RJ45 ports, 10/100 Mbps auto-sensing, full/half-duplex auto-negotiation
Switching Method: Store-and-forward with 1K MAC address table
Data Throughput: 200 Mbps (full-duplex aggregate)
Power Supply: 24V DC (18-32V DC range), reverse polarity protection
Power Consumption: Typical 2.5W, maximum 3W
Operating Temperature: -40°C to +70°C (extended industrial range)
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% RH, non-condensing
Protection Rating: IP20 (suitable for enclosed control cabinets)
Mounting: 35mm DIN rail (EN 60715 TH35)
Dimensions (W×H×D): 30mm × 100mm × 125mm
Weight: Approximately 200g
Certifications: CE, UL, cUL, ATEX Zone 2 (optional), IEC 61850-3, IEEE 802.3

Selection Considerations:
When specifying the SCALANCE X005, evaluate your network's maximum device count (up to 5 endpoints per switch), required cable lengths (100m max per segment), and environmental conditions. For networks exceeding 5 nodes, consider daisy-chaining multiple X005 units or upgrading to managed switches with VLAN support for traffic segmentation. If fiber optic connectivity or redundant ring topologies are needed, explore SCALANCE X200 or X300 series alternatives.

For assistance with network design, cable specifications, or integration with existing Siemens TIA Portal projects, our application engineers can provide customized topology diagrams and bill-of-materials based on your facility layout and device inventory.

Advanced Integration Capabilities

PROFINET Compatibility: Fully transparent to PROFINET RT (Real-Time) traffic, enabling seamless integration into Siemens S7-1200/1500 PLC networks without protocol conversion.
Multi-Protocol Support: Simultaneously handles Modbus TCP, EtherNet/IP, OPC UA, and standard TCP/IP traffic, allowing mixed-vendor automation systems to coexist on the same physical network.
Diagnostic LEDs: Per-port link/activity indicators and power status LED simplify troubleshooting during commissioning and maintenance, reducing mean-time-to-repair (MTTR) by up to 30%.
Cable Compatibility: Supports Cat5e/Cat6 twisted-pair cabling with standard RJ45 connectors; no proprietary cables required, lowering spare parts inventory costs.

Delivery, Warranty & Technical Support

Lead Time: Standard stock items ship within 1-3 business days; custom configurations or bulk orders typically require 7-14 days depending on quantity and destination.
Warranty Coverage: 12-month manufacturer warranty covering defects in materials and workmanship under normal industrial operating conditions.
Installation Support: Comprehensive documentation package includes wiring diagrams, DIN rail mounting instructions, and quick-start guide in English. Remote technical assistance available via email and phone during business hours.
Technical Documentation: Full product manual, CAD drawings (STEP/DXF formats), and EPLAN macros provided upon request to streamline panel design and compliance documentation.
Compliance Certificates: CE Declaration of Conformity, UL certification files, and RoHS compliance statements available for download to support project approval and customs clearance.

Frequently Asked Questions (FAQ)

Q: How do I connect the SCALANCE X005 to my existing PLC network?
A: Simply plug Ethernet cables from your PLCs, HMIs, or other devices into any of the 5 RJ45 ports, and connect the switch to your 24V DC power supply. No software configuration is needed—the switch auto-detects connection speeds and cable types. Ensure your devices are on the same IP subnet for communication.

Q: Can this switch handle PROFINET traffic for Siemens S7-1500 PLCs?
A: Yes, the X005 is fully transparent to PROFINET RT (Real-Time) communication and supports the deterministic timing required for S7-1200/1500 networks. For PROFINET IRT (Isochronous Real-Time) applications requiring sub-millisecond cycle times, consider managed SCALANCE X200 switches with IRT support.

Q: What is the maximum network distance I can achieve with this switch?
A: Each Ethernet port supports up to 100 meters (328 feet) of Cat5e/Cat6 cable per segment. To extend beyond this distance, use fiber optic media converters or upgrade to SCALANCE switches with integrated fiber ports for multi-kilometer links.

Q: Is the switch suitable for outdoor installations or high-vibration environments?
A: The X005 is IP20-rated for enclosed cabinet use. For outdoor or washdown areas, install it inside a NEMA 4X/IP65-rated enclosure. The switch's fanless design and solid-state components tolerate vibration per IEC 60068-2-6 standards, making it suitable for mobile machinery and rail-mounted applications.

Q: Can I monitor network traffic or configure VLANs on this switch?
A: No, the X005 is an unmanaged switch without configuration interfaces or VLAN support. For network segmentation, traffic prioritization, or SNMP monitoring, explore managed SCALANCE X200/X300 series switches with web-based or TIA Portal integration.

Q: Does the switch support Power over Ethernet (PoE) for IP cameras or wireless access points?
A: The standard X005 model does not provide PoE. For powering PoE devices, consider SCALANCE XP005 variants or use external PoE injectors between the switch and powered devices.

Get Expert Selection Assistance

To ensure the SCALANCE X005 meets your specific automation requirements, please provide our engineering team with the following project details:

• Application Overview: Brief description of your system (e.g., packaging line, water treatment SCADA, CNC network)
• Device Count: Number and types of Ethernet devices to connect (PLCs, HMIs, drives, sensors)
• Network Topology: Linear, star, or daisy-chain configuration preference
• Environmental Conditions: Operating temperature range, enclosure type, vibration/shock levels
• Power Supply: Available DC voltage and current capacity
• Protocol Requirements: PROFINET, Modbus TCP, EtherNet/IP, or other industrial protocols in use
• Future Expansion: Anticipated network growth over the next 2-3 years

Our application specialists will respond within 24 hours with a tailored recommendation, including alternative models if your requirements exceed the X005's capabilities, detailed pricing for single units or volume orders, and technical documentation to support your design review.
