Siemens SCALANCE X005 Industrial Ethernet Switch | 5-Port Unmanaged Network Hub for Automation

SCALANCE X005 Industrial Ethernet Switch – Reliable Network Foundation for Automation Systems

The Siemens SCALANCE X005 (6GK5005-0BA00-1AA3) is an unmanaged industrial Ethernet switch engineered for seamless connectivity in factory automation, process control, and industrial IoT environments. Featuring 5 × RJ45 10/100 Mbps ports with auto-negotiation and auto-crossover (Auto-MDI/MDIX), this compact switch delivers plug-and-play networking for PLCs, HMIs, drives, sensors, and SCADA systems without requiring configuration.

Designed for manufacturing plants, production lines, machine builders, and system integrators, the X005 addresses common challenges such as unreliable consumer-grade switches in harsh environments, limited mounting space in control cabinets, and the need for maintenance-free operation. Its industrial-grade construction ensures stable data transmission even under temperature fluctuations, vibration, and electromagnetic interference.

With DIN-rail mounting, fanless operation, and wide temperature tolerance (-40°C to +70°C), the SCALANCE X005 offers proven reliability, easy installation, and long service life. Ideal for design engineers, automation contractors, OEMs, and plant maintenance teams seeking cost-effective, standards-compliant Ethernet infrastructure. Contact our application engineers for network topology design, compatibility verification, and quotation assistance.

Core Features & Technical Advantages

Plug-and-Play Simplicity
Unmanaged design with auto-negotiation (10/100 Mbps) and Auto-MDI/MDIX eliminates manual configuration. Connect devices with straight-through or crossover cables—the switch adapts automatically, reducing installation time and wiring errors.

Industrial-Grade Durability
Operating temperature range of -40°C to +70°C, IP20 protection, and compliance with IEC 61850-3 / IEEE 1613 standards ensure reliable performance in factory floors, outdoor enclosures, and mobile machinery applications.

Compact & Space-Saving Design
Ultra-slim 30 mm width fits standard 35 mm DIN rails, ideal for crowded control cabinets. Fanless convection cooling eliminates noise and moving parts, reducing maintenance requirements and extending MTBF (Mean Time Between Failures).

Fast & Stable Data Transmission
Store-and-forward switching with wire-speed forwarding rate minimizes latency. Supports full-duplex communication on all ports, delivering aggregate bandwidth of 1 Gbps for simultaneous multi-device communication without packet loss.

Seamless SIMATIC Integration
Native compatibility with Siemens S7-1200/1500 PLCs, SIMATIC HMI panels, and TIA Portal engineering software. Supports PROFINET, Modbus TCP, and standard Ethernet/IP protocols for multi-vendor system integration.

Redundancy-Ready Architecture
While the X005 itself is unmanaged, it integrates smoothly into ring topologies when paired with managed SCALANCE switches (e.g., X200 series with MRP/RSTP), providing network redundancy for mission-critical applications.

Typical Application Scenarios

The SCALANCE X005 is engineered for environments demanding continuous uptime, deterministic communication, and resistance to industrial stressors:

Discrete Manufacturing & Assembly Lines
Connect robotic arms, vision systems, barcode scanners, and conveyor controllers in automotive, electronics, and consumer goods production. Ensures real-time coordination between workstations with minimal jitter.

Process Industries & Continuous Production
Link distributed I/O modules, flow meters, temperature transmitters, and actuators in chemical plants, oil & gas facilities, and food processing lines. Withstands exposure to dust, humidity, and temperature swings.

Machine Building & OEM Equipment
Embedded networking for packaging machines, CNC systems, textile looms, and printing presses. Compact footprint and global certifications (CE, UL, cULus) simplify compliance for equipment export.

Building Automation & Infrastructure
Integrate HVAC controllers, lighting systems, access control panels, and energy meters in smart buildings and data centers. Reliable 24/7 operation with minimal power consumption (< 5W).

Mobile & Transportation Systems
Onboard networking for rail vehicles, port cranes, AGVs (Automated Guided Vehicles), and mining equipment. Vibration-resistant design and conformal-coated PCBs ensure operation in mobile environments.

Technical Specifications & Selection Guide

To facilitate system design and procurement, key parameters are summarized below. For custom configurations or multi-switch topologies, consult our engineering team with your network diagram and device list.

Electrical & Performance

• Ports: 5 × RJ45 (10/100BASE-TX, Auto-MDI/MDIX)
• Switching Method: Store-and-Forward
• MAC Address Table: 1024 entries
• Forwarding Rate: 148,800 pps (100 Mbps full-duplex per port)
• Power Supply: 24 VDC ±20% (18–32 VDC), < 5W consumption
• Redundant Power Input: Not available (single DC input)

Environmental & Mechanical

• Operating Temperature: -40°C to +70°C (extended range)
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% RH (non-condensing)
• Protection Class: IP20 (for cabinet installation)
• Mounting: 35 mm DIN rail (IEC 60715)
• Dimensions (W × H × D): 30 mm × 100 mm × 125 mm
• Weight: Approx. 0.2 kg

Standards & Certifications

• EMC: IEC 61000-6-2 (Immunity), IEC 61000-6-4 (Emissions)
• Safety: IEC 61010-2-201, UL 61010-2-201, cULus Listed
• Industrial: IEC 61850-3, IEEE 1613 (Substation Automation)
• Shock & Vibration: IEC 60068-2-6 / IEC 60068-2-27

Selection Considerations

• Number of Devices: X005 supports up to 5 devices. For larger networks, consider daisy-chaining multiple X005 units or upgrading to X200/X300 managed switches.
• Power Budget: Verify 24 VDC supply capacity if powering multiple switches. Each X005 draws < 5W; a 60W supply can support 10+ units.
• Cable Length: Maximum 100 meters per Ethernet segment (Cat5e/Cat6 recommended). Use fiber-optic media converters for longer distances.
• Redundancy Needs: For ring topologies with < 200 ms failover, pair with SCALANCE X200 managed switches supporting MRP (Media Redundancy Protocol).
• Harsh Environments: For IP65/67 outdoor or washdown applications, specify SCALANCE X100 series with M12 connectors and conformal coating.

Need assistance with network sizing or protocol compatibility? Share your device list, cabinet layout, and environmental conditions—our engineers will recommend the optimal switch configuration and provide CAD drawings for panel design.

Extended Capabilities & System Integration

Protocol Support
Transparent forwarding of PROFINET RT (Real-Time), Modbus TCP, EtherNet/IP, OPC UA, and standard TCP/IP traffic. Supports VLANs when used downstream of managed switches (VLAN-transparent forwarding).

Diagnostics & Monitoring
LED indicators for power, link/activity per port, and fault status. While unmanaged, the switch can be monitored via SNMP when integrated into a managed network infrastructure using SCALANCE X200/X300 as core switches.

Cybersecurity Baseline
Physical security via DIN-rail locking clips. For advanced security (port authentication, ACLs, firewall), deploy managed SCALANCE switches at network boundaries and use X005 for edge device connectivity.

Firmware & Lifecycle
No firmware updates required (hardware-based switching). Siemens guarantees 10+ years product availability and spare parts support, ensuring long-term investment protection for capital equipment projects.

Delivery, Service & Documentation

Lead Time & Packaging
Standard SKU 6GK5005-0BA00-1AA3 typically ships within 3–7 business days from regional stock (subject to availability). Custom orders (e.g., bulk quantities, pre-configured kits) require 2–4 weeks. Each unit includes DIN-rail mounting clip, quick start guide, and conformity declarations.

Warranty & Support
Backed by Siemens' standard 24-month warranty covering manufacturing defects. Extended warranties and service contracts available through authorized distributors. Technical support includes remote troubleshooting, replacement RMA processing, and access to TIA Portal integration guides.

Technical Documentation
Complete package includes:

• Product Manual (EN/DE/CN) with wiring diagrams and LED status tables
• Dimensional drawings (DXF/PDF) for cabinet layout planning
• Electrical schematics and terminal assignments
• Compliance certificates (CE, UL, EAC, CCC as applicable)
• Integration examples for TIA Portal and STEP 7

Installation & Commissioning
On-site installation support and network commissioning services available in select regions. Remote assistance via video call for cable routing, grounding verification, and initial power-up. Training workshops for maintenance teams upon request.

Frequently Asked Questions (FAQ)

Q: How do I connect the SCALANCE X005 to existing Siemens PLCs and HMIs?
A: Use standard Cat5e/Cat6 Ethernet cables with RJ45 connectors. Connect PLC CPU Ethernet port, HMI panel, and other devices to any of the 5 switch ports—no configuration needed. Ensure all devices are on the same IP subnet (e.g., 192.168.0.x with 255.255.255.0 mask).

Q: What is the maximum number of devices I can connect to one X005 switch?
A: Directly, up to 5 devices (one per port). To expand, connect additional X005 or X200 switches in a star or daisy-chain topology. For networks exceeding 20 devices, consider a managed switch as the core with X005 units at edge segments.

Q: Does the X005 support Power over Ethernet (PoE) for IP cameras or wireless access points?
A: No, the X005 does not provide PoE (IEEE 802.3af/at). For PoE requirements, use Siemens SCALANCE XP or third-party industrial PoE switches, then connect the X005 downstream for non-PoE devices.

Q: Can the switch operate in extreme temperatures like -40°C or outdoor enclosures?
A: Yes, the X005 is rated for -40°C to +70°C ambient temperature, suitable for unheated cabinets, cold storage, and outdoor kiosks (when installed in IP65-rated enclosures). For direct outdoor exposure, consider SCALANCE X100 series with IP65/67 housing.

Q: Is the X005 compatible with non-Siemens devices like Allen-Bradley PLCs or Schneider HMIs?
A: Absolutely. As a standard IEEE 802.3 Ethernet switch, the X005 works with any device supporting 10/100 Mbps Ethernet—regardless of manufacturer. It transparently forwards EtherNet/IP, Modbus TCP, and other industrial protocols.

Q: How do I achieve network redundancy with unmanaged switches like the X005?
A: The X005 itself does not support ring protocols (MRP/RSTP). For redundancy, use it as an edge switch connected to a redundant ring built with SCALANCE X200 managed switches. The X005 benefits from the ring's failover without requiring management features.

Q: What is the typical lifespan and MTBF of the SCALANCE X005?
A: With fanless design and no moving parts, the X005 has an MTBF exceeding 500,000 hours (per SN 29500 calculation). Expected service life is 10–15 years under normal industrial conditions, with Siemens guaranteeing spare parts availability for the product lifecycle.

Q: Can I monitor the switch status remotely or receive alerts for port failures?
A: The X005 is unmanaged and does not support SNMP or remote monitoring. For diagnostics, observe the front-panel LEDs (power, link, activity). If remote monitoring is required, deploy managed SCALANCE X200/X300 switches with SNMP/email alerts.

Request a Quotation & Engineering Support

To receive a detailed selection proposal, pricing, or technical consultation, please provide the following project information:

• Project Name & Application: (e.g., "Automotive Assembly Line Network Upgrade")
• Number of Devices & Types: (e.g., 3 PLCs, 2 HMIs, 5 I/O modules, 1 SCADA server)
• Network Topology: Star, daisy-chain, or ring? Redundancy required?
• Environmental Conditions: Temperature range, IP rating, vibration/shock levels
• Power Supply: Available DC voltage (24V standard or other?)
• Cable Distances: Maximum length between devices
• Quantity & Delivery Timeline: Units needed and project commissioning date

Our application engineers will respond within 24 hours with a customized network diagram, bill of materials (BOM), and competitive pricing. We also offer pre-sale protocol testing, post-sale commissioning assistance, and training for your maintenance team.
