Siemens 6ES7307-1EA00-0AA0 PS307 Power Supply | 24V DC 2A for S7-300 PLC | Industrial Automation

Siemens PS307 Power Supply – Industrial-Grade 24V DC Solution for S7-300 PLC Systems

The Siemens 6ES7307-1EA00-0AA0 PS307 is a regulated power supply module designed specifically for SIMATIC S7-300 programmable logic controller (PLC) systems. Through precision voltage regulation and wide input range compatibility, it delivers stable 24V DC power to ensure reliable operation of automation control systems in demanding industrial environments.

This power module is widely deployed in manufacturing automation, process control, building management systems, water treatment facilities, and energy management applications. It addresses critical challenges including voltage fluctuations, power instability, system downtime risks, and inadequate protection against electrical faults that can compromise production continuity.

Featuring standardized DIN rail mounting and modular design, the PS307 offers excellent compatibility with S7-300 CPU modules and I/O expansion units. It provides robust protection mechanisms, efficient thermal management, and straightforward installation procedures, making it the preferred choice for system integrators, control panel builders, OEM manufacturers, and plant maintenance teams. Contact our engineering team for application-specific configuration guidance and technical specifications.

Core Features & Technical Advantages

Precision Voltage Regulation
Advanced switching-mode power supply (SMPS) technology maintains stable 24V DC output with ±3% tolerance, protecting sensitive PLC components from voltage variations and ensuring consistent logic-level signals across the control system.

Wide Input Voltage Range
Accepts AC input from 120V to 230V (±15%), eliminating the need for voltage-specific models and simplifying global deployment across facilities with different power standards, reducing inventory complexity and procurement costs.

High Efficiency & Low Heat Generation
Achieves up to 88% conversion efficiency, minimizing energy waste and reducing cooling requirements. Lower operating temperatures extend component lifespan and enable installation in compact control cabinets without additional ventilation.

Comprehensive Protection Functions
Integrated safeguards include overload protection, short-circuit protection, overvoltage protection, and thermal shutdown. These features prevent cascading failures, reduce maintenance interventions, and protect downstream equipment investments.

Diagnostic LED Indicators
Front-panel status LEDs provide instant visual confirmation of power output and fault conditions, enabling rapid troubleshooting and reducing mean time to repair (MTTR) during commissioning and operational phases.

Modular DIN Rail Design
Standard 35mm DIN rail mounting with snap-on installation allows seamless integration into existing S7-300 configurations. Compact 40mm width optimizes panel space utilization in multi-module control systems.

Typical Application Scenarios

The PS307 power supply is engineered for industrial environments requiring high reliability and continuous operation, particularly in:

Manufacturing Automation & Assembly Lines
Powers PLC control systems managing conveyor systems, robotic work cells, material handling equipment, and quality inspection stations. Ensures uninterrupted production cycles in automotive, electronics, food processing, and pharmaceutical manufacturing facilities.

Process Control & SCADA Systems
Provides stable power for distributed control systems (DCS) in chemical processing, oil & gas refineries, water treatment plants, and power generation facilities where process stability and safety interlocks are mission-critical.

Building Automation & HVAC Control
Supports building management systems controlling HVAC equipment, lighting systems, access control, and energy monitoring in commercial buildings, hospitals, data centers, and institutional facilities requiring 24/7 operation.

Infrastructure & Utilities
Deployed in pump control stations, wastewater treatment facilities, traffic management systems, and renewable energy installations where environmental conditions demand industrial-grade reliability and extended temperature range operation.

Technical Specifications & Selection Guide

To facilitate system design and component selection, key electrical and mechanical parameters are provided below:

Electrical Characteristics:

• Input Voltage: AC 120-230V (±15%), 50/60 Hz
• Output Voltage: DC 24V (±3%)
• Output Current: 2A rated, 2.5A peak (5 seconds)
• Power Rating: 48W continuous
• Efficiency: ≥88% at nominal load
• Isolation: 1500V AC input-to-output

Mechanical & Environmental:

• Mounting: 35mm DIN rail (EN 60715)
• Dimensions: 40mm (W) × 125mm (H) × 120mm (D)
• Operating Temperature: -25°C to +60°C
• Storage Temperature: -40°C to +70°C
• Protection Rating: IP20
• Certifications: CE, UL, cUL, FM approved

Selection Considerations:
When specifying the PS307, evaluate total current consumption of all connected S7-300 modules (CPU, signal modules, communication processors). Allow 20-30% margin for system expansion and inrush current during startup. For systems exceeding 2A total load, consider parallel operation with additional PS307 units or upgrade to higher-capacity PS models. Our application engineers can review your I/O configuration and recommend optimal power architecture.

Extended Capabilities & System Integration

Redundant Power Configuration
Supports parallel operation with secondary PS307 units for N+1 redundancy in critical applications. Automatic load sharing and seamless failover ensure continuous operation during maintenance or component failure scenarios.

Remote Monitoring Integration
When paired with S7-300 CPUs featuring communication modules, power supply status can be monitored via SCADA systems, enabling predictive maintenance strategies and centralized facility management through Profibus, Profinet, or Ethernet/IP networks.

Global Compliance & Safety Standards
Meets international safety standards including IEC 61131-2, UL 508, and CSA C22.2 for industrial control equipment. RoHS compliant and manufactured under ISO 9001 quality management systems, ensuring consistent product quality and regulatory compliance across global installations.

Delivery, Service & Technical Support

Standard catalog items ship from regional distribution centers with typical lead times of 3-5 business days for stock items. Custom configurations or volume orders may require 2-3 weeks depending on specifications and quantity. All units include a minimum 24-month manufacturer warranty covering defects in materials and workmanship.

Comprehensive technical documentation accompanies each shipment, including installation manuals, wiring diagrams, dimensional drawings, and compliance certificates. Remote technical consultation is available during installation and commissioning phases. On-site startup assistance and training services can be arranged for complex multi-cabinet installations (availability varies by region).

Our engineering team maintains extensive application experience across diverse industries and can provide system-level design review, load calculation verification, and integration guidance for both new installations and retrofit projects.

Frequently Asked Questions (FAQ)

Q: How do I calculate if the PS307 power supply is sufficient for my S7-300 configuration?
A: Sum the current consumption specifications from datasheets of all installed modules (CPU, digital I/O, analog I/O, communication processors). Add 20-30% safety margin. If total exceeds 1.6A continuous, consider redundant PS307 units or higher-capacity models like PS305 (5A) or PS307 (10A variants).

Q: Can the PS307 operate with input voltages outside the 120-230V range?
A: The specified input range is 120-230V AC ±15%, meaning it tolerates 102-264V AC. Operation outside this range may trigger undervoltage/overvoltage protection or cause output voltage deviation. For non-standard supply voltages, consult factory for alternative models or external voltage conditioning solutions.

Q: What is the typical efficiency and heat dissipation of this power supply?
A: At nominal 24V/2A output (48W), efficiency is approximately 88%, resulting in ~6.5W heat dissipation. Adequate ventilation within the control cabinet is recommended. Maintain minimum 25mm clearance above and below the module for convection cooling. Forced air cooling is generally not required for single-unit installations.

Q: Does the PS307 support hot-swapping or replacement without system shutdown?
A: Hot-swap capability depends on system configuration. In redundant power setups with load-sharing diodes, one PS307 can be replaced while the backup maintains system power. For single-supply configurations, controlled shutdown is required. Always follow lockout/tagout procedures and verify output voltage before reconnecting loads.

Q: What protection rating does the PS307 provide, and can it be used in harsh environments?
A: The module is rated IP20, suitable for installation inside enclosed control cabinets. It is not designed for direct exposure to dust, moisture, or corrosive atmospheres. For harsh environments, install within NEMA 4/4X or IP65-rated enclosures with appropriate environmental sealing and climate control.

Q: Is remote monitoring and diagnostics possible with the PS307 power supply?
A: The PS307 provides local LED status indication. For remote monitoring, integrate with S7-300 CPUs equipped with communication modules (CP343, CP343-1, etc.) and use PLC program logic to monitor voltage levels via analog input modules. Advanced diagnostics require supplementary monitoring hardware or upgrade to newer SITOP PSE200U series with built-in communication interfaces.

Request Technical Consultation & Quotation

For detailed application engineering support, custom configuration recommendations, or project-specific pricing, please provide the following information to our technical sales team:

• Project name and application description
• Complete S7-300 hardware configuration (CPU model, I/O module list with part numbers)
• Total estimated current consumption and future expansion plans
• Input power specifications (voltage, frequency, phase)
• Environmental conditions (ambient temperature range, enclosure type)
• Quantity requirements and delivery timeline
• Compliance or certification requirements specific to your industry/region

Our application engineers will respond within one business day with tailored recommendations, technical validation, and commercial quotation.
