LOGO! 230RC Logic Module (Industrial-Grade Programmable Controller)

The Siemens 6ED1052-1FB00-0BA0 represents a breakthrough in compact automation technology, delivering enterprise-level control capabilities in a space-saving DIN rail package. This intelligent relay combines the simplicity of traditional control relays with the flexibility of programmable logic controllers, making it the ideal choice for facilities managers, system integrators, and automation engineers seeking reliable, cost-effective solutions.

Designed for professionals who demand precision without complexity, the LOGO! 230RC eliminates the steep learning curve associated with conventional PLCs. Whether you're upgrading legacy relay panels or deploying new automation infrastructure, this module provides immediate value through its intuitive programming interface and robust industrial construction. Target users include building automation specialists, OEM machine builders, water treatment operators, and maintenance teams managing distributed control systems.

What sets this controller apart is its unique combination of integrated display technology, real-time clock functionality, and high-capacity relay outputs—all in a single compact unit. Reduce panel space by up to 60% compared to discrete relay solutions while gaining advanced scheduling, counting, and timing capabilities that traditional components simply cannot match. The result: faster commissioning, lower installation costs, and enhanced system reliability.

Core Features & Benefits

✓ Wide-Range AC Power Supply (115/230V)
Adapts automatically to voltage fluctuations, ensuring stable operation across diverse electrical environments. Eliminates the need for voltage-specific inventory management.

✓ 8 Configurable Digital Inputs
Accepts both 115V and 230V AC signals directly, reducing wiring complexity and eliminating signal conditioning requirements. Supports sensors, switches, and control devices without additional interface modules.

✓ 4 High-Capacity Relay Outputs (10A Each)
Drives motors, contactors, solenoids, and lighting loads directly. Handles inductive loads up to 2400VA, removing the need for external power relays in most applications.

✓ Integrated Backlit LCD Display
Provides real-time system status, parameter values, and diagnostic information at a glance. Enables on-site adjustments without laptop or programming device, cutting troubleshooting time by 50%.

✓ Built-In Real-Time Clock
Executes time-based control sequences with astronomical clock functions for sunrise/sunset calculations. Ideal for energy-saving lighting schedules and HVAC optimization.

✓ LOGO! Soft Comfort Programming
Intuitive function block diagram software requires zero coding knowledge. Drag-and-drop interface accelerates program development—typical applications programmed in under 30 minutes.

Typical Application Scenarios

→ Commercial Building Lighting Control
Automate stairwell, parking garage, and perimeter lighting with occupancy sensors and time schedules. Reduces energy consumption by 40-70% while ensuring safety compliance. Eliminates manual switching and extends lamp life through soft-start capabilities.

→ Water & Wastewater Management
Sequence multiple pumps based on level sensors, runtime balancing, and alternation logic. Prevents pump wear, optimizes energy usage, and provides alarm notification for fault conditions. Handles duty/standby configurations with automatic switchover.

→ HVAC System Automation
Control ventilation fans, damper actuators, and heating elements based on temperature, humidity, and occupancy inputs. Implements night setback, morning warm-up, and demand-based ventilation strategies that cut HVAC costs by 25-35%.

→ Access Control & Security
Manage gate operators, door locks, and barrier systems with time-zone restrictions and holiday calendars. Integrates with card readers, keypads, and remote controls for comprehensive perimeter security.

→ Industrial Machine Control
Replace aging cam timers and mechanical sequencers in packaging equipment, conveyor systems, and material handling machinery. Provides precise timing, counting, and sequencing with easy program modifications for product changeovers.

Technical Parameters & Selection Guide

Selection Criteria: Choose the 230RC model when your application requires AC voltage inputs and high-current relay outputs for direct load switching. For DC-powered systems (12/24V), consider the LOGO! 12/24RC or 12/24RCE variants. If Ethernet connectivity is essential for remote monitoring or SCADA integration, upgrade to the 230RCE version with built-in Ethernet port. Expansion modules (DM8, DM16, AM2) can be added to any base unit when additional I/O points are needed beyond the standard configuration.

Extended Functions

Modular Expansion Capability: Connect up to three expansion modules to increase I/O capacity to 24 digital inputs, 20 digital outputs, or 8 analog inputs. Mix and match modules based on application requirements without changing the base program structure.

Communication Options: Add the LOGO! CMR2020 or CMR2040 communication module to enable Ethernet/IP connectivity, web server functionality, and email notifications. Access and modify programs remotely via LOGO! Web Editor from any browser-enabled device.

Data Logging: Record up to 7 analog values or digital states to internal memory or external SD card (with CMR module). Export trend data for energy audits, maintenance analysis, and compliance reporting.

Customization Services: Our engineering team provides custom programming, panel integration, and application-specific configuration services. Pre-programmed units available for common applications—specify requirements at time of order.

Delivery & Service Assurance

Standard Lead Time: In-stock items ship within 1-2 business days via express courier. Typical delivery to major cities: 3-5 business days domestic, 7-10 business days international.

Custom Configuration: Pre-programmed and tested units available with 5-7 business day lead time. Includes application-specific logic, parameter settings, and documentation.

Warranty Coverage: Comprehensive 12-month manufacturer warranty covers defects in materials and workmanship. Extended warranty options available for critical applications.

Technical Support: Unlimited phone and email support included. Our certified automation specialists provide programming assistance, troubleshooting guidance, and application consulting at no additional charge.

Documentation Package: Every unit ships with quick-start guide, wiring diagrams, and sample programs. Full technical manual and LOGO! Soft Comfort software available for free download.

Frequently Asked Questions

Q: How do I expand the input/output capacity of my LOGO! 230RC controller?
A: The base module supports up to three expansion modules connected via the built-in expansion bus. Add DM8 modules for 4 additional inputs + 4 outputs, DM16 modules for 8 inputs + 8 outputs, or AM2 modules for 2 analog inputs (0-10V or 4-20mA). Total system capacity: 24 digital inputs, 20 digital outputs, 8 analog inputs. Expansion modules hot-swap capable for easy maintenance.

Q: Can I monitor and control the LOGO! remotely over the internet?
A: Yes, by adding the LOGO! CMR2020 (Ethernet) or CMR2040 (Ethernet + cellular) communication module. This enables web-based access to real-time data, remote program modifications, email/SMS alarms, and integration with SCADA systems. The built-in web server requires no additional software—access via standard browser from PC, tablet, or smartphone.

Q: What is the maximum switching capacity for inductive loads like motors and contactors?
A: Each relay output handles up to 10A resistive or 2400VA inductive load at 250V AC. For motor loads, this translates to approximately 1.5 HP @ 230V single-phase or 2 HP @ 230V three-phase (when switching through a contactor). Use RC snubbers or varistors across inductive loads to maximize relay life—typically 100,000+ operations under rated conditions.

Q: How does the LOGO! 230RC compare to traditional timer relays for energy savings?
A: Unlike fixed-function timers, the LOGO! combines multiple timing functions (on-delay, off-delay, pulse, weekly schedules) with logic operations and astronomical clock calculations. This enables sophisticated energy management strategies: occupancy-based lighting with automatic shutoff, optimized HVAC start/stop based on outdoor temperature, and demand-limiting for peak shaving. Typical energy cost reduction: 30-50% versus conventional time-switch control.

Q: What programming skills are required to configure the LOGO! module?
A: Zero coding experience necessary. The LOGO! Soft Comfort software uses graphical function block programming—simply drag pre-built functions (timers, counters, logic gates) onto the workspace and connect them with virtual wires. Built-in simulation mode tests programs before download. Most users create functional programs within 1-2 hours of first use. Free online training videos and sample programs accelerate learning.

Q: Is the LOGO! 230RC suitable for outdoor installation or harsh environments?
A: The base module carries IP20 rating for indoor panel mounting. For outdoor or dusty environments, install in a NEMA 4X/IP65-rated enclosure with appropriate ventilation. Operating temperature range (0-55°C) suits most climate-controlled and semi-outdoor applications. For extreme conditions (-40°C to +70°C), consider the LOGO! 24o variant with extended temperature rating and conformal coating.

Ready to Streamline Your Automation Project?

Transform your control system with proven LOGO! technology trusted by over 15 million installations worldwide. Our automation specialists are standing by to answer technical questions, provide application guidance, and process your order with same-day shipping on in-stock items.

Contact our team today: Email sale@ninermas.com or call +0086 187 5021 5667 for immediate assistance. Request a custom quote for volume orders or pre-programmed solutions tailored to your specifications.
