GE 750-P5-G5-S5-LO-A20-R-B Multilin SR750 Feeder Protection Relay (Industrial-Grade Distribution Control)

The GE 750-P5-G5-S5-LO-A20-R-B represents a proven solution in electrical distribution protection, combining precision overcurrent detection with comprehensive metering capabilities. Designed for demanding industrial environments, this Multilin SR750 series relay delivers dependable feeder management across manufacturing plants, commercial facilities, and utility infrastructure.

Built to address the critical challenges of electrical distribution—unplanned downtime, coordination complexity, and system visibility gaps—this relay serves protection engineers, facility managers, and system integrators who demand both reliability and operational intelligence. Whether safeguarding a single feeder or coordinating protection across an entire distribution network, the 750-P5-G5-S5-LO-A20-R-B provides the technical foundation for resilient power systems.

Key advantages include multi-element protection schemes that adapt to varying load conditions, integrated communication for real-time monitoring, and field-proven reliability backed by GE's engineering heritage. The relay's modular design simplifies commissioning while its comprehensive event recording accelerates troubleshooting and root cause analysis.

Core Features & Technical Advantages

→ Multi-Function Protection Architecture
Integrates phase overcurrent, ground fault, voltage monitoring, and frequency protection in a single platform, reducing panel space requirements while improving coordination accuracy. Definite-time and inverse-time curves ensure selective operation across diverse fault scenarios.

→ P5 Current Input Configuration
Accepts standard 5A CT secondaries common in North American installations, eliminating the need for auxiliary transducers. Wide dynamic range accommodates both low-level monitoring and high-magnitude fault detection without saturation.

→ G5 Voltage Sensing Flexibility
Configurable for wye or delta voltage connections, supporting three-phase and single-phase applications. Precision voltage measurement enables power quality analysis and load profiling beyond basic protection functions.

→ S5 Output Relay Package
Provides six Form-C contact outputs for trip commands, alarm signaling, and auxiliary control functions. High-capacity contacts rated for direct breaker tripping reduce external interface requirements and improve system reliability.

✓ Enhanced Communication Capability (A20 Option)
Dual serial ports support simultaneous Modbus RTU and DNP3.0 connectivity, enabling integration with SCADA systems, building management platforms, and remote monitoring services. Protocol flexibility ensures compatibility with legacy and modern control architectures.

✓ Wide-Range Power Supply (LO Configuration)
Operates across 85-300V AC/DC input range, accommodating voltage variations during system disturbances and simplifying multi-voltage installations. Universal power input reduces spare parts inventory and installation complexity.

Application Scenarios & Industry Solutions

Manufacturing & Process Industries
Protects motor control centers, distribution switchgear, and process equipment feeders where production continuity depends on selective fault isolation. The relay's programmable logic enables custom interlocking schemes that prevent equipment damage during abnormal operating conditions. Typical deployment: 480V distribution systems feeding variable frequency drives, process controllers, and automated production lines.

Commercial Infrastructure & Critical Facilities
Safeguards main and sub-feeders in hospitals, data centers, and high-rise buildings where power reliability directly impacts occupant safety and business operations. Integrated metering provides energy consumption data for tenant billing and efficiency initiatives. Addresses the challenge of coordinating protection across complex distribution hierarchies with multiple voltage levels.

Utility Distribution Networks
Manages distribution circuits in substations and switching stations, providing both protection and operational data for grid management. DNP3.0 communication enables seamless integration with utility SCADA systems for remote monitoring and control. Delivers value through reduced site visits and faster fault location identification.

Renewable Energy Installations
Controls feeder circuits in solar farms and wind generation facilities, where bidirectional power flow and variable generation patterns require adaptive protection settings. The relay's programmable elements accommodate the unique characteristics of distributed generation while maintaining grid code compliance.

Mining & Heavy Industry
Withstands harsh environmental conditions in mining operations, cement plants, and steel mills where temperature extremes, vibration, and electrical noise challenge conventional protection equipment. Extended temperature rating (-40°C to +85°C) ensures reliable operation in uncontrolled environments.

Technical Parameters & Selection Criteria

Selection Guidelines: Choose the P5 current input variant for systems using 5A CT secondaries (standard in North America). The G5 voltage configuration suits three-phase applications requiring both phase and ground fault detection. Select the S5 output package when six independent trip/alarm circuits are needed. The LO power supply option provides maximum flexibility for installations with varying auxiliary voltage availability. The A20 communication upgrade is essential for SCADA integration and remote monitoring requirements.

Extended Functionality & Integration Options

Programmable Logic Engine: The relay includes a built-in logic processor supporting custom protection schemes, sequential control, and interlocking functions without external PLCs. Users can implement load shedding, automatic transfer schemes, and equipment sequencing through the configuration software.

Advanced Metering & Power Quality: Beyond basic protection, the relay continuously monitors voltage, current, power factor, harmonics, and energy consumption. Trend data and min/max recording support predictive maintenance and energy management initiatives.

Event & Fault Recording: Comprehensive event logs capture protection operations, alarm conditions, and system disturbances with millisecond time-stamping. Oscillography records waveform data during faults, accelerating post-event analysis and system optimization.

Cybersecurity Features: Password-protected access controls, encrypted communication options, and audit logging address industrial cybersecurity requirements. Role-based permissions prevent unauthorized setting changes while maintaining operational visibility.

Customization & Factory Services: GE offers factory configuration services, custom firmware adaptations, and application-specific testing for projects requiring specialized functionality or accelerated deployment schedules.

Delivery Timeline & Service Commitments

Standard Lead Time: 3-5 business days for in-stock units; expedited same-day shipping available for urgent requirements. Custom-configured relays typically ship within 10-15 business days following order confirmation.

Warranty Coverage: 12-month manufacturer warranty covering materials and workmanship defects. Extended warranty programs available for critical applications requiring long-term protection.

Technical Support: Application engineering assistance provided during specification, commissioning support available remotely or on-site, and lifetime access to firmware updates and configuration software.

Documentation Package: Each relay ships with installation manual, quick-start guide, settings calculation worksheets, and CAD drawings for panel integration. Comprehensive instruction manuals and application notes available for download.

Frequently Asked Questions

How does the SR750 relay integrate with existing SCADA infrastructure?
The A20 communication option provides dual RS-485 serial ports supporting both Modbus RTU and DNP3.0 protocols simultaneously. This allows connection to legacy Modbus systems while enabling DNP3.0 integration with modern SCADA platforms. Communication parameters are fully configurable through the EnerVista setup software, and the relay supports standard DNP3.0 point mapping for seamless integration.

What configuration software is required for relay programming?
GE's EnerVista SR750 Setup software provides comprehensive configuration, testing, and monitoring capabilities. The software is available as a free download and runs on Windows operating systems. Basic parameter adjustments can also be performed via the front-panel interface for field modifications without a laptop.

Can this relay coordinate with upstream circuit breakers and downstream motor starters?
Yes, the SR750 offers extensive coordination capabilities through its flexible time-current curve library. The relay supports definite-time, inverse-time (IEC and IEEE curves), and programmable curves that can be precisely coordinated with upstream protective devices and downstream equipment. The configuration software includes coordination plotting tools to verify selective operation.

What are the differences between the various SR750 model configurations?
The model number encodes specific hardware options: P5 indicates 5A current inputs (P1 for 1A), G5 specifies three-phase voltage inputs with wye/delta flexibility, S5 denotes six output relays, LO represents the wide-range power supply, A20 adds enhanced dual-port communication, and the R-B suffix indicates specific regional certifications and packaging.

Is the relay suitable for applications requiring arc flash reduction?
While the SR750 provides fast overcurrent protection that reduces incident energy during arc flash events, dedicated arc flash mitigation requires integration with light/pressure sensors and specialized tripping logic. The relay's high-speed output contacts and programmable logic can interface with arc flash detection systems for coordinated protection schemes.

How does the relay perform in high-vibration or extreme-temperature environments?
The SR750 is designed for industrial environments with an operating temperature range of -40°C to +85°C and vibration resistance per IEC 60255-21-1 standards. The solid-state design eliminates moving parts susceptible to mechanical failure, and conformal coating options are available for installations in corrosive atmospheres or high-humidity conditions.

Ready to Enhance Your Distribution Protection?

Contact our technical team to discuss your specific feeder protection requirements, receive application engineering support, or request a detailed quotation. We provide comprehensive pre-sales consultation to ensure optimal relay selection and configuration for your electrical distribution system.
