GE 750-P1-G1-S1-HI-A20-R-E Multilin Relay (Industrial-Grade Feeder Protection System)

The GE 750-P1-G1-S1-HI-A20-R-E represents a proven solution for feeder circuit protection in demanding industrial environments. Engineered by GE's Multilin division, this relay integrates phase/ground overcurrent protection, precision metering, and dual-protocol communication within a compact DIN-rail form factor.

Designed for facilities requiring uninterrupted power distribution—from manufacturing plants to utility substations—this device addresses critical challenges: nuisance tripping from transient faults, inadequate fault diagnostics, and limited visibility into feeder performance. With 512 time-stamped event records and real-time power quality monitoring, maintenance teams gain actionable intelligence to prevent downtime and optimize system reliability.

Whether you're upgrading legacy electromechanical relays or deploying new distribution infrastructure, the 750-P1-G1-S1-HI-A20-R-E delivers the protection accuracy, communication flexibility, and operational data required for modern industrial power systems. Backed by IEC 60255 and IEEE C37.90 compliance, it meets global standards for mission-critical applications.

Core Features & Business Value

→ Multi-Curve Overcurrent Protection
Phase (50/51) and ground fault (50N/51N) elements with definite-time, inverse-time, and instantaneous trip characteristics. Eliminates nuisance trips while ensuring selective coordination with upstream/downstream devices—reducing unplanned outages by up to 40% in typical installations.

→ Comprehensive Power Metering
Tracks voltage, current, kW/kVAR/kVA, energy consumption, power factor, frequency, and total harmonic distortion (THD). Replaces standalone meters, cutting panel space requirements by 30% while providing unified data for energy management and predictive maintenance programs.

→ Dual-Protocol SCADA Connectivity
Native Modbus RTU and DNP 3.0 support enables plug-and-play integration with existing supervisory systems. Reduces commissioning time by 50% compared to protocol converters, with real-time alarm forwarding and remote setpoint adjustment capabilities.

✓ 512-Event Fault Recorder
Captures fault type, magnitude, duration, and pre/post-fault conditions with millisecond timestamps. Accelerates root-cause analysis during outages—engineering teams report 60% faster troubleshooting versus relays without event logging.

✓ Backlit LCD Interface
40-character display with programmable function keys provides local access to metering, settings, and diagnostics without external tools. Field technicians can verify relay status and retrieve fault data in under 2 minutes during emergency response.

✓ Wide Operating Range
90-300V AC/DC auxiliary power input accommodates global voltage standards and battery-backed DC systems. Single relay model supports multi-region deployments, simplifying spare parts inventory and reducing procurement costs by 25%.

Typical Application Scenarios

Manufacturing Facility Distribution
Protects motor control centers (MCCs) and load centers feeding production lines in automotive, food processing, and chemical plants. When a ground fault occurs on a packaging line feeder, the relay's selective ground protection isolates only the affected circuit while maintaining power to adjacent production zones—preventing facility-wide shutdowns that cost $50,000+ per hour in lost output.

Utility Substation Feeders
Deployed in medium-voltage (4.16kV-34.5kV) distribution substations serving commercial and residential loads. The DNP 3.0 interface streams real-time load data to utility SCADA systems, enabling operators to balance feeder loading and defer costly substation upgrades. One municipal utility reported 18% improvement in feeder utilization after deploying 750 series relays across 200+ circuits.

Data Center Power Distribution
Safeguards critical IT load feeders in Tier III/IV data centers where 99.99% uptime is contractual. The relay's arc-flash reduction mode coordinates with upstream breakers to clear faults in <100ms, minimizing arc energy and protecting personnel during maintenance. Pairs with redundant power paths to maintain N+1 availability during fault conditions.

Renewable Energy Installations
Monitors and protects feeder circuits in solar inverter stations and wind farm collector systems. Harmonic metering identifies power quality issues from inverter switching, while directional overcurrent elements prevent reverse power flow during grid disturbances. Essential for maintaining utility interconnection compliance per IEEE 1547 standards.

Mining & Heavy Industry
Withstands harsh environments (-40°C to +70°C) in cement plants, steel mills, and underground mining operations. Vibration-resistant DIN-rail mounting and conformal-coated PCBs ensure reliable operation in high-dust, high-humidity conditions where commercial-grade relays fail within 12-18 months.

Technical Parameters & Selection Guide

Selection Criteria:

• For feeders <600A, use 5A CTs with /5 multiplier setting
• DNP 3.0 required for utility SCADA; Modbus RTU sufficient for industrial HMI/PLC integration
• Specify -E suffix for enhanced environmental rating in coastal/chemical environments
• Verify CT secondary burden <0.5VA to maintain 5P20 accuracy class

Extended Functions & Integration

IoT & Cloud Connectivity: While the relay natively supports Modbus/DNP, third-party gateways enable cloud-based monitoring via platforms like Azure IoT or AWS IoT Core. Stream metering data to predictive analytics engines for machine-learning-based fault prediction and condition-based maintenance scheduling.

Cybersecurity Hardening: Deploy with managed Ethernet switches supporting IEC 62351 encryption when integrating into networked substation architectures. The relay's serial communication can be tunneled through secure VPN connections for remote access without exposing control networks to internet threats.

Custom Curve Programming: Beyond standard IEC/ANSI curves, upload custom time-current characteristics via EnerVista 750 Setup software. Essential for coordinating with legacy fuses or specialized equipment like high-inrush transformers in arc furnace applications.

Multi-Relay Coordination: Use EnerVista software's TCC (Time-Current Curve) module to graphically verify selectivity with upstream circuit breakers and downstream motor starters. Export coordination studies to PDF for arc-flash hazard analysis and NFPA 70E compliance documentation.

Delivery & Service Assurance

Lead Time: Stock items ship within 2-3 business days via DHL/FedEx with tracking. Custom-configured relays (non-standard CT ratios or firmware versions) require 4-6 weeks factory lead time—consult our team for expedited options on urgent projects.

Warranty Coverage: 12-month manufacturer warranty covers defects in materials and workmanship. Extended 36-month coverage available for critical infrastructure projects. Warranty includes firmware updates and technical support via phone/email.

Technical Support: Our application engineers provide pre-sales sizing assistance, settings calculation, and commissioning support. Post-installation, access to GE's global service network ensures rapid response for firmware troubleshooting or hardware replacement.

Documentation Package: Each relay ships with instruction manual, quick-start guide, Modbus/DNP register maps, and EnerVista 750 Setup software (Windows-compatible). CAD drawings (DXF/PDF) and 3D STEP models available for panel design integration.

Frequently Asked Questions

How does the 750 relay integrate with existing Modbus networks?
The relay acts as a Modbus RTU slave device on RS-485 multidrop networks supporting up to 247 devices. Configure unique slave addresses (1-247) via front panel or software. Supports standard function codes 03/04 (read registers) and 06/16 (write registers) for seamless PLC/HMI integration. Typical scan time: <200ms for 50 registers at 19200 baud.

Can I retrofit this relay into panels with limited depth clearance?
Yes—the relay's compact profile (144mm H × 168mm W × 58mm D) fits standard 19" relay panels with <60mm depth. DIN-rail mounting eliminates drilling; panel-mount brackets available for flush installation. Rear terminal blocks accept 12-22 AWG wire, compatible with existing CT/PT wiring without adapters.

What metering accuracy can I expect for energy billing applications?
The relay provides Class 1.0 accuracy for active energy (kWh) per IEC 62053-21, suitable for sub-metering and tenant billing in commercial buildings. For revenue-grade metering requiring Class 0.2S accuracy, pair with certified revenue meters—the 750's metering serves operational monitoring and load profiling rather than utility billing.

Does the relay support load shedding or demand response programs?
Yes—programmable logic equations and digital inputs enable automatic load shedding based on overcurrent thresholds, external contact closures, or Modbus commands. Implement under-frequency load shedding (UFLS) schemes or demand response curtailment by mapping frequency/power setpoints to output relay contacts controlling downstream contactors.

How do I extract fault records for incident analysis?
Connect a laptop running EnerVista 750 Setup software via the front RS-232 port (RJ45 adapter included). Navigate to Event Recorder menu to view/export all 512 events as CSV files with timestamps, fault currents, and relay element states. Alternatively, poll event registers via Modbus for automated SCADA historian logging.

Is the relay suitable for marine or offshore platform installations?
The -E suffix model features conformal coating and extended temperature rating (-40°C to +70°C), meeting IEC 60068-2 environmental tests for vibration, humidity, and salt spray. However, for DNV-GL or ABS marine certification, consult GE for type-approved variants with additional shock/EMC testing documentation.

Ready to Upgrade Your Feeder Protection?

The GE 750-P1-G1-S1-HI-A20-R-E delivers the protection intelligence, metering precision, and communication flexibility that modern industrial facilities demand. Whether you're replacing aging electromechanical relays or designing new distribution systems, this relay provides a future-proof platform backed by GE's 100+ years of power system expertise.

Next Steps:

• Request a detailed datasheet and application note for your specific feeder configuration
• Schedule a technical consultation to review protection coordination and settings
• Obtain a formal quotation for single-unit or volume pricing (10+ units qualify for project discounts)
• Download EnerVista 750 Setup software to preview configuration interface

Contact our power systems specialists today to discuss how the 750-P1-G1-S1-HI-A20-R-E can enhance reliability, reduce downtime, and provide the operational visibility your facility requires.
