193-EC3PB E3 Plus Overload Relay (Industrial-Grade Motor Safeguard)

The 193-EC3PB represents next-generation motor protection technology, combining solid-state precision with field-proven reliability. This E3 Plus electronic overload relay monitors motor current in real time, delivering adaptive thermal modeling that prevents costly downtime while eliminating nuisance trips common in traditional bimetal designs.

Engineered for industrial facilities demanding uninterrupted operation, the 193-EC3PB addresses critical challenges: phase imbalance detection, ground fault isolation, and jam condition recognition. Maintenance teams gain instant fault diagnostics through integrated LED indicators, while the 9-45A adjustable range accommodates diverse motor loads without inventory complexity.

Whether protecting conveyor drives in distribution centers, pump motors in water treatment plants, or compressor units in manufacturing, this relay delivers consistent performance across -25°C to +60°C ambient conditions. Direct compatibility with Allen-Bradley 100-C contactors ensures plug-and-play integration into existing motor control architectures.

Core Features & Benefits

→ Adaptive Current Sensing (9-45A Range)
Electronic measurement windows eliminate external CT requirements while providing ±1.5% accuracy across the full operating range—critical for variable torque applications and energy-efficient motor profiles.

→ Tri-Class Trip Response (10/20/30)
Field-selectable trip curves match protection to load characteristics: Class 10 for rapid response on critical processes, Class 20 for standard induction motors, Class 30 for high-inertia fans and centrifugal equipment.

→ Multi-Fault Detection Architecture
Simultaneous monitoring of phase loss, voltage unbalance (>15%), ground fault leakage, and locked-rotor conditions provides comprehensive protection beyond simple thermal overload—reducing unplanned maintenance by up to 40%.

✓ Dual Reset Modes
Switch between manual reset (operator verification required) and automatic reset (unmanned operations) without rewiring—ideal for remote pump stations and after-hours production lines.

✓ Diagnostic LED Array
Color-coded indicators differentiate between overload trips, phase faults, and ground conditions, cutting troubleshooting time from hours to minutes during emergency callouts.

✓ Wide Voltage Compatibility
100-240V AC control circuit acceptance (50/60 Hz) simplifies global deployment and reduces spare parts inventory for multi-site operations.

Application Scenarios

Water & Wastewater Treatment
Protects submersible pump motors against single-phasing and voltage sag during utility switching events. The relay's moisture-resistant enclosure and extended temperature rating ensure reliable operation in humid pump rooms and outdoor lift stations.

Material Handling Systems
Conveyor drive motors benefit from jam detection algorithms that distinguish between temporary overloads (product accumulation) and mechanical failures, preventing false shutdowns during peak throughput periods.

HVAC & Building Systems
Chiller compressor and air handler motors gain protection against phase rotation errors during maintenance reconnections, while automatic reset capability maintains comfort conditions without operator intervention.

Food & Beverage Processing
Mixer and agitator motors operating under variable viscosity loads receive adaptive thermal protection that accounts for duty cycle variations, supporting both CIP cycles and production runs.

Petrochemical & Refining
Critical pump and compressor applications leverage the relay's UL 508 and IEC 60947-4-1 certifications for hazardous location installations when paired with appropriate enclosures.

Technical Parameters & Selection Guide

Selection Criteria: Calculate motor full-load amperage (FLA) from nameplate data. Select relay range where FLA falls within 60-100% of maximum rating for optimal thermal modeling accuracy. For motors with service factor >1.15, consider next higher range to prevent nuisance trips during sustained overload conditions.

Extended Functionality

Communication-Ready Platform: Optional 193-ECOM Ethernet/IP module enables integration with FactoryTalk View HMI systems and PlantPAx DCS architectures. Access real-time current readings, trip history logs, and predictive maintenance alerts without additional I/O hardware.

Advanced Diagnostics: Built-in trip memory stores last fault type and timestamp, supporting root cause analysis during post-incident reviews. Ground fault sensitivity adjustment (10-50% FLA) accommodates varying cable lengths and motor winding configurations.

Customization Options: Factory-configured current ranges and trip class presets available for OEM panel builders requiring consistent settings across multiple installations. Custom labeling and serialization services support asset management programs.

Delivery & Service Assurance

Lead Time: Stock units ship within 24-48 hours via expedited carriers. Custom configurations require 7-10 business days for factory programming and testing.

Warranty Coverage: Comprehensive 12-month protection against manufacturing defects, including no-cost replacement and return shipping. Extended warranty programs available for critical infrastructure applications.

Technical Support: Direct access to application engineers with motor control expertise. Pre-sales sizing assistance, installation guidance, and troubleshooting support via phone, email, and remote desktop sessions.

Documentation Package: Each relay includes quick-start guide, wiring diagrams, trip curve charts, and dimensional drawings. Full instruction manual and CAD files available for download at product support portal.

Frequently Asked Questions

How does the 193-EC3PB interface with existing motor starters?
The relay mounts directly to Allen-Bradley 100-C09 through 100-C43 contactors using integrated mounting clips—no additional hardware required. For other contactor brands, use the included DIN rail adapter and wire auxiliary contacts to the starter control circuit.

What current capacity should I choose for a 30 HP motor at 460V?
A 30 HP three-phase motor at 460V draws approximately 34A FLA. The 193-EC3PB (9-45A range) provides ideal coverage, allowing adjustment to 34A with headroom for service factor operation up to 39A without nuisance trips.

Can this relay reduce energy consumption in motor circuits?
While the relay itself doesn't reduce motor energy use, its precise phase unbalance detection identifies supply issues causing efficiency losses. Correcting detected imbalances (>3%) can improve motor efficiency by 2-5% and extend winding life by 30-50%.

What installation clearances are required for proper cooling?
Maintain 50mm (2 inches) vertical spacing above and below the relay when mounting multiple units in enclosed panels. Side-by-side mounting requires no additional clearance due to the relay's low heat dissipation (<5W).

Does the relay support remote monitoring without additional modules?
The base 193-EC3PB provides local LED diagnostics only. For remote monitoring, add the 193-ECOM communication module to access current readings, trip logs, and fault alerts via Ethernet/IP networks and SCADA systems.

How do I verify proper operation after installation?
After wiring and power-up, the green LED should illuminate steadily. Press the test button to simulate an overload trip—the relay should open auxiliary contacts and display a red trip indicator. Reset functionality confirms proper installation before energizing the motor.

Get Your Motor Protection Solution Today

Protect your critical motor assets with proven E3 Plus technology. Contact our application specialists for sizing assistance, volume pricing, or technical specifications tailored to your facility requirements. Stock availability and same-day shipping ensure minimal project delays.
