Allen-Bradley 1790D-T0B16 CompactBlock LDX Digital Output Module (Industrial-Grade DeviceNet I/O Solution)

The Allen-Bradley 1790D-T0B16 is a high-performance 16-point digital output module designed for DeviceNet distributed I/O applications. Through advanced solid-state switching technology and modular architecture, it delivers precise output control, real-time diagnostics, and seamless integration with Rockwell Automation control platforms.

Ideal for manufacturing automation, process control systems, material handling equipment, packaging machinery, and industrial assembly lines. This module addresses critical challenges including limited I/O expansion capacity, complex wiring requirements, slow fault detection, and inflexible system scalability in distributed control environments.

Featuring standardized DeviceNet connectivity with customizable configuration options, the 1790D-T0B16 offers reliable performance, simplified installation, easy maintenance, and broad compatibility with existing automation infrastructure. Perfect for system integrators, control panel builders, OEM equipment manufacturers, and plant maintenance teams. Contact our automation specialists for application-specific configuration guidance and technical quotations.

Core Features and Advantages

High-Density Digital Output Control
Provides 16 independent solid-state output channels with individual point diagnostics, enabling precise control of solenoids, indicators, relays, and actuators while minimizing cabinet space requirements and reducing installation complexity.

DeviceNet Network Integration
Native DeviceNet communication protocol ensures deterministic data exchange, reduced wiring costs compared to traditional hardwired I/O, and simplified network configuration through standard EDS files and RSNetWorx software tools.

Enhanced Diagnostic Capabilities
Built-in channel-level fault detection identifies short circuits, open loads, and overcurrent conditions in real-time, with visual LED indicators and network-accessible status information that accelerates troubleshooting and minimizes unplanned downtime.

Modular and Scalable Architecture
Compact DIN-rail mountable design allows flexible system expansion, hot-swappable module replacement without disrupting adjacent I/O points, and mixed I/O configurations to match specific application requirements while maintaining consistent footprint.

Industrial-Grade Reliability
Engineered with conformal-coated circuitry, wide operating temperature range (-20°C to 60°C), and robust EMI/RFI immunity to withstand harsh factory environments including vibration, electrical noise, and temperature fluctuations common in industrial settings.

Simplified Configuration and Maintenance
Pre-configured output parameters stored in module memory enable rapid replacement without reprogramming, while compatibility with RSLogix programming software and Studio 5000 environment streamlines commissioning and ongoing system modifications.

Typical Application Scenarios

This module is engineered for applications demanding reliable output control, distributed architecture, and comprehensive diagnostics, particularly in:

Automated Manufacturing and Assembly Systems
Controls pneumatic actuators, conveyor motors, part ejectors, and quality inspection gates in automotive assembly, electronics manufacturing, and consumer goods production lines where coordinated multi-point control and rapid cycle times are essential.

Process Control and Batch Operations
Manages valve actuators, pump starters, mixer controls, and alarm indicators in chemical processing, food and beverage production, pharmaceutical manufacturing, and water treatment facilities requiring precise sequencing and regulatory compliance documentation.

Material Handling and Logistics Automation
Operates sortation diverters, gate controls, label applicators, and status indicators in distribution centers, warehouse automation systems, and airport baggage handling where reliable operation and quick fault identification minimize operational disruptions.

Packaging and Labeling Equipment
Drives cutting mechanisms, sealing bars, print heads, and reject mechanisms in high-speed packaging machinery, cartoning systems, and labeling applicators where synchronized output timing and minimal downtime directly impact production throughput.

Machine Tool and Metalworking Systems
Controls coolant pumps, chip conveyors, tool changers, and safety interlocks in CNC machining centers, grinding equipment, and fabrication machinery where harsh environments and electrical noise require industrial-hardened I/O solutions.

Technical Specifications and Selection Guide

To facilitate design and procurement decisions, we provide comprehensive technical parameters for the 1790D-T0B16 module, with custom configuration support available for specialized requirements.

Key Technical Parameters:

• Output Points: 16 channels, individually isolated solid-state outputs
• Output Type: Sourcing (PNP) or Sinking (NPN) configuration, field-selectable per 8-point group
• Voltage Range: 10-30 VDC nominal operating voltage
• Current Rating: 0.5A continuous per point, 8A maximum per common group
• Network Protocol: DeviceNet, Group 2 Only Server, supports polled and change-of-state messaging
• Power Consumption: 150mA typical at 24 VDC from DeviceNet bus, plus field power for outputs
• Diagnostic Features: Per-point short circuit detection, open load detection, module fault indication
• Environmental Rating: Operating temperature -20°C to 60°C, 5% to 95% RH non-condensing
• Mounting: 35mm DIN rail, removable terminal blocks for simplified wiring
• Certifications: UL Listed, CE marked, RoHS compliant
• Dimensions: Approximately 35mm (W) × 118mm (H) × 114mm (D)

Selection Considerations:
When specifying the 1790D-T0B16, evaluate total output point requirements, load current per channel, field power supply voltage, DeviceNet network topology, environmental conditions, and cabinet space constraints. For applications requiring input modules, analog I/O, or specialty functions, consider companion 1790 series modules for integrated system design. Our application engineers can recommend optimal configurations based on your control architecture, I/O count, and performance requirements.

Advanced Integration Capabilities

Seamless Rockwell Automation Ecosystem Compatibility
Full integration with CompactLogix, ControlLogix, FlexLogix, and SLC 500 controllers via DeviceNet scanner modules, with native support in RSLogix 500, RSLogix 5000, and Studio 5000 programming environments for unified development experience.

Flexible Network Topologies
Supports trunk-line/drop-line, daisy-chain, and star network configurations with standard DeviceNet cabling, enabling optimized layouts for machine-mounted I/O, remote I/O racks, and distributed control panels while maintaining network performance.

Redundancy and Fault Tolerance Options
Compatible with DeviceNet redundant media and dual-port scanner configurations for mission-critical applications, with automatic failover capabilities and continuous operation during network maintenance or component replacement procedures.

Third-Party Device Interoperability
Conforms to ODVA DeviceNet specifications ensuring compatibility with drives, sensors, HMIs, and other vendor devices on the same network, facilitating best-of-breed system design and protecting long-term automation investments.

Delivery, Service, and Quality Assurance

Lead Time and Availability: Factory-sealed units typically ship within 3-5 business days from stock; custom-configured or large-quantity orders may require 7-14 days. Expedited shipping options available for urgent project requirements.

Warranty Coverage: Backed by manufacturer's standard warranty (minimum 1 year from date of shipment) covering defects in materials and workmanship under normal use and service conditions, with extended warranty programs available for critical applications.

Technical Support: Comprehensive pre-sales application assistance, post-sales commissioning guidance, and ongoing technical support via phone, email, and remote diagnostics. On-site startup services and training available in select regions (subject to location and scope).

Documentation Package: Each module ships with complete technical documentation including product specifications, installation instructions, wiring diagrams, DeviceNet EDS file, and quick-start guide. Additional resources including application notes, sample code, and integration guides available through technical support portal.

Quality Certifications: Manufactured in ISO 9001-certified facilities with rigorous quality control processes, 100% functional testing, and compliance with international safety and EMC standards ensuring reliable performance in demanding industrial environments.

Frequently Asked Questions (FAQ)

Q: How does the 1790D-T0B16 DeviceNet output module integrate with existing PLC systems?
A: The module connects to your controller via a DeviceNet scanner card or embedded scanner port. Configuration is performed using RSNetWorx for DeviceNet software, which automatically discovers the module, loads its EDS file, and maps I/O points to your controller's data table. Wiring requires only DeviceNet trunk cable connection and field power supply for outputs.

Q: What is the maximum number of output modules supported on a single DeviceNet network?
A: DeviceNet supports up to 64 nodes per network segment. The actual number of 1790D-T0B16 modules depends on network bandwidth allocation, scan rates, and other devices present. Typical installations support 20-30 I/O modules with standard polling configurations; consult DeviceNet network planning tools for precise capacity calculations.

Q: Can this module control both AC and DC loads, and what are the current limitations?
A: The 1790D-T0B16 is designed exclusively for DC loads (10-30 VDC range). Each output channel supports up to 0.5A continuous current, with 8A maximum per common group (8 points). For AC load control, consider using the module to drive intermediate relay coils or solid-state relay inputs rated for AC switching.

Q: What environmental protection does the module offer for harsh industrial settings?
A: The module features conformal-coated circuit boards for moisture and contaminant resistance, operates reliably from -20°C to 60°C ambient temperature, and meets industrial EMI/RFI immunity standards. While suitable for typical factory environments, it requires installation in an enclosure rated IP20 minimum; for washdown or outdoor applications, specify appropriate NEMA-rated enclosures.

Q: Does the 1790D-T0B16 support remote monitoring and predictive maintenance capabilities?
A: Yes, the module provides comprehensive diagnostic data accessible through the DeviceNet network, including per-channel fault status, module health indicators, and operational statistics. This data can be monitored via HMI systems, logged to SCADA platforms, or integrated with predictive maintenance software using standard Rockwell Automation communication protocols including EtherNet/IP bridging.

Q: What is the recommended spare parts strategy for this module?
A: For critical applications, we recommend maintaining one spare module per 10-15 installed units, or minimum one spare for systems with fewer modules. The hot-swappable design and stored configuration enable rapid replacement (typically under 5 minutes) without reprogramming. Consider our advance replacement program for mission-critical installations requiring guaranteed response times.

Request Technical Consultation and Quotation

To receive detailed application recommendations, system configuration proposals, or pricing information, please provide the following details: project name and industry, specific application requirements, total I/O point count and types, controller platform and DeviceNet scanner model, environmental conditions and enclosure specifications, required delivery timeline, and installation location. Our automation specialists will respond within one business day with tailored solutions and comprehensive technical support.
