1771-OWNA High-Density Relay Output Module (Industrial-Grade PLC-5 Interface)

The 1771-OWNA represents a proven solution for high-voltage switching applications within Allen-Bradley PLC-5 architectures. This 32-channel relay output module bridges programmable logic control with real-world actuators, delivering galvanic isolation and robust contact switching for mission-critical industrial processes.

Designed for environments where electromagnetic interference, voltage transients, and harsh operating conditions demand reliable performance, the 1771-OWNA addresses the challenge of controlling diverse AC/DC loads from a single compact module. Manufacturing facilities, process plants, and infrastructure systems rely on this module to manage motor starters, solenoid valves, heating circuits, and alarm systems with precision timing and electrical isolation.

With certification for Class I, Division 2 hazardous locations and compatibility across the 1771 I/O chassis family, this module integrates seamlessly into existing automation frameworks while providing the flexibility to scale control density without expanding cabinet footprint. Each output delivers independent switching capability with 1500V isolation, ensuring system integrity even under fault conditions.

Core Capabilities & Technical Advantages

✓ High-Density Output Architecture
32 independent relay outputs organized in four isolated groups of eight channels each, maximizing control points per chassis slot while maintaining electrical separation between load circuits. Ideal for applications requiring numerous discrete control signals within limited panel space.

✓ Universal Voltage Compatibility
Handles both AC (24-138V RMS) and DC (24-125V) loads through the same contact structure, eliminating the need for separate modules when controlling mixed voltage systems. Simplifies inventory management and reduces engineering complexity in multi-voltage installations.

✓ Robust Current Handling
Each contact rated for 1A continuous current with 30W resistive load capacity, while group-level current management (4A per group, 12A module total) prevents thermal overload. Engineered for long-term reliability in continuous-duty applications.

→ Galvanic Isolation Protection
1500V isolation between control logic and field wiring protects sensitive PLC circuitry from voltage spikes, ground loops, and electrical noise common in industrial power distribution systems. Critical for maintaining system uptime in electrically noisy environments.

→ Predictable Response Timing
Typical operate/release time of 5ms (±1ms) enables precise coordination with mechanical processes and sequential control logic. Consistent timing characteristics support deterministic control strategies in automated production lines.

→ Extended Interconnect Distance
Supports field wiring runs up to 1000 feet (304.8 meters) from I/O chassis to load devices, providing installation flexibility in large facilities and distributed control applications without signal degradation or additional amplification.

Industrial Application Scenarios

Manufacturing Process Control
In automated assembly lines and packaging systems, the 1771-OWNA controls pneumatic actuators, conveyor motors, and part ejection mechanisms. The module's grouped output structure allows logical organization of machine zones, while isolation prevents electrical faults in one section from cascading to others. Typical deployment controls 32 discrete stations within a single production cell.

Building Automation & HVAC Systems
Facility management applications leverage the module's AC voltage capability to switch damper motors, pump contactors, and zone heating elements. The 10Hz maximum switching frequency accommodates modulating control strategies, while the module's temperature rating (0-60°C) suits mechanical room installations without additional cooling.

Water & Wastewater Treatment
Municipal treatment plants deploy the 1771-OWNA for valve sequencing, chemical feed pump control, and alarm annunciation. Hazardous location certification (Class I, Division 2) permits installation in areas with potential methane accumulation, while the module's isolation protects control systems from ground potential differences common in large outdoor installations.

Material Handling & Warehousing
Distribution centers use the module to coordinate sortation systems, automated storage/retrieval equipment, and loading dock controls. The ability to handle both DC (for low-voltage safety circuits) and AC (for industrial equipment) from a single module reduces wiring complexity and panel space requirements.

Energy & Utilities Infrastructure
Power generation facilities and substations employ the 1771-OWNA for breaker control, transfer switch operation, and auxiliary system management. The module's 1500V isolation meets utility-grade electrical separation requirements, while CSA/UL certification satisfies regulatory compliance for critical infrastructure applications.

Technical Specifications & Selection Criteria

Selection Guidelines: Choose the 1771-OWNA when your application requires isolated relay switching for mixed AC/DC loads in a PLC-5 system. For faster switching (>10Hz), consider solid-state output modules. For loads exceeding 1A per point, use external contactors driven by the module's relay contacts. When controlling only DC loads <50V, evaluate transistor output modules for extended life and faster response.

Advanced Integration & Customization Options

Load Suppression Enhancement: For inductive loads (motors, solenoids, transformers), install RC snubbers or MOV suppressors across contacts to extend relay life and reduce electrical noise. Suppression components should be rated for 150% of load voltage with energy absorption capacity matching load inductance.

Diagnostic Monitoring: Integrate with PLC-5 diagnostic routines to track output state mismatches, overcurrent conditions, and module health status. Implement predictive maintenance algorithms based on switching cycle counts and thermal monitoring to schedule replacement before failure.

Redundancy Configuration: Deploy dual 1771-OWNA modules with external OR-ing diodes for critical control points requiring fault tolerance. Program PLC logic to automatically transfer control to backup outputs upon primary contact failure detection.

Remote I/O Extension: Combine with 1771-ASB remote I/O adapter to distribute control points across facility using RIO network, reducing long cable runs and centralizing PLC processing while maintaining local output switching.

Delivery Timeline & Service Commitment

Standard Delivery: In-stock units ship within 1-2 business days via expedited carrier. Typical transit time 3-5 days for domestic destinations, 7-12 days for international shipments. All modules undergo final inspection and functional testing before dispatch.

Custom Configuration: Pre-wired assemblies with 1771-WN wiring arms and terminal blocks available with 5-7 business day lead time. Specify wire gauge, ferrule type, and labeling requirements at order placement.

Warranty Coverage: 12-month comprehensive warranty covers manufacturing defects, component failures, and performance deviations from published specifications. Warranty includes advance replacement service to minimize downtime.

Technical Support: Unlimited access to application engineers for installation guidance, troubleshooting assistance, and integration consulting. Support includes wiring diagram review, load calculation verification, and PLC program optimization recommendations.

Documentation Package: Each module ships with installation instructions, wiring diagrams, technical specifications sheet, and certification documents. Digital resources include CAD drawings, 3D STEP models, and sample ladder logic routines.

Common Technical Questions

What is the recommended wire size for field connections to the 1771-OWNA module?
Use 14 AWG (2.0mm²) stranded copper wire with insulation thickness not exceeding 3/64 inch (1.2mm). The 1771-WN wiring arm accepts this gauge with proper termination. For runs exceeding 500 feet or high-current applications, consider 12 AWG to minimize voltage drop. Always torque terminal screws to 7-9 inch-pounds to ensure reliable contact.

Can the module switch both AC and DC loads simultaneously on different outputs?
Yes, each relay contact is independent and can switch either AC or DC within the rated voltage range. For example, outputs 0-7 could control 120V AC solenoids while outputs 8-15 switch 24V DC indicator lamps. Ensure total current per group and per module stays within limits (4A per group, 12A module total).

How does the 1771-OWNA handle inductive load switching and what is the expected relay life?
The module is rated for 100,000 mechanical cycles with resistive loads. Inductive loads (motors, solenoids, contactors) generate back-EMF that accelerates contact wear. Install suppression devices (RC snubbers for AC, flyback diodes for DC) across inductive loads to extend life. With proper suppression, expect 50,000-75,000 cycles. Limit switching frequency to 10Hz maximum to prevent thermal stress.

What is the maximum cable length between the module and controlled devices?
The 1771-OWNA supports field wiring up to 1000 feet (304.8 meters) from the I/O chassis to load devices. This distance assumes proper wire gauge (14 AWG minimum) and acceptable voltage drop for the application. For critical timing applications or low-voltage DC loads, limit runs to 500 feet to maintain signal integrity and minimize resistance-induced voltage loss.

Is the 1771-OWNA compatible with modern ControlLogix or CompactLogix systems?
No, the 1771-OWNA is designed exclusively for PLC-5 systems using 1771 I/O chassis. For ControlLogix platforms, use 1756-series output modules. For CompactLogix, use 1769-series modules. If migrating from PLC-5 to newer platforms, plan for complete I/O system replacement as the backplane architectures are incompatible.

What certifications does the module hold for hazardous location installations?
The 1771-OWNA is certified for Class I, Division 2, Groups A, B, C, D hazardous locations per NEC Article 500. It also carries UL listing, CSA certification, and CE marking for European compliance. These certifications permit installation in areas where flammable gases or vapors may be present under abnormal conditions, such as chemical plants, refineries, and paint spray booths.

Ready to Optimize Your Control System?

Contact our automation specialists to discuss your specific application requirements, verify compatibility with your existing PLC-5 infrastructure, and receive a detailed quotation. We provide technical consultation to ensure proper module selection, load calculation review, and integration planning for successful deployment.

Request a quote today: Email sale@ninermas.com or call +0086 187 5021 5667 to speak with an application engineer. Bulk pricing available for multi-module projects and system integrators.
