1771-OW16 Industrial Relay Output Module (16-Channel Isolated Control)

The 1771-OW16 is a professional-grade relay contact output module designed for Allen-Bradley PLC-5 automation platforms. Featuring 16 independently isolated relay channels, this module provides versatile switching capability for controlling solenoids, contactors, pilot lights, and motor starters in demanding industrial environments. Each output delivers robust 2A switching capacity across a wide voltage spectrum, making it the preferred choice for mixed-voltage control applications.

Engineered for manufacturing facilities, process plants, and material handling systems, the 1771-OW16 addresses the critical challenge of interfacing low-voltage logic signals with high-power field devices. Its relay-based architecture ensures complete galvanic isolation between control circuits and load circuits, protecting sensitive PLC components from voltage transients and ground loop interference.

With factory-verified calibration, hot-swap capability, and proven reliability in 24/7 operations, this output module minimizes commissioning time while maximizing system uptime. The module integrates seamlessly into existing PLC-5 chassis configurations, supporting both greenfield installations and legacy system upgrades.

Core Features & Benefits

✓ 16 Isolated Relay Outputs – Independent contact closure for each channel eliminates cross-talk and enables simultaneous control of diverse load types without electrical interference.

✓ Universal Voltage Compatibility – Switches AC loads from 24-250V and DC loads from 24-150V, reducing inventory requirements and simplifying panel design for multi-voltage systems.

✓ 1500V Optical Isolation – Protects PLC backplane from field-side faults, voltage spikes, and ground potential differences, extending controller lifespan and reducing downtime.

✓ 2A Per-Point Current Rating – Directly drives inductive loads including solenoid valves, relay coils, and small contactors without external amplification or buffer circuits.

✓ Hot-Swappable Design – Replace modules during operation without system shutdown, maintaining production continuity during preventive maintenance or emergency repairs.

✓ 10ms Response Time – Fast switching speed supports time-critical sequencing operations in high-speed packaging, assembly, and sorting applications.

Typical Application Scenarios

→ Automotive Assembly Lines
Controls pneumatic clamps, part ejectors, and conveyor diverters in body-in-white welding stations. The module's isolated outputs prevent electrical noise from welding equipment from corrupting control signals, while its 2A rating directly drives 24V DC solenoid manifolds without intermediate relays.

→ Chemical Batch Processing
Manages motorized valve actuators, agitator starters, and alarm annunciators in reactor control panels. Relay isolation protects the PLC from hazardous area voltage fluctuations, and the wide AC voltage range accommodates legacy 120V control circuits alongside modern 24V systems.

→ Water Treatment Facilities
Operates pump contactors, chlorination system valves, and level alarm lights across multiple treatment stages. The module's robust relay contacts withstand the high inrush currents of motor starters, while optical isolation prevents ground loops in distributed control architectures.

→ Food & Beverage Packaging
Sequences filling nozzles, capping heads, and labeling applicators in bottling lines. Fast 10ms response enables precise timing coordination, and the hot-swap feature allows module replacement during scheduled sanitation shutdowns without reprogramming.

→ Material Handling Systems
Drives sortation gates, diverter arms, and indicator beacons in distribution center conveyors. The module's ability to switch both AC pilot lights and DC solenoids from a single chassis simplifies wiring and reduces panel footprint.

Technical Parameters & Selection Guide

Selection Criteria: Choose the 1771-OW16 when your application requires electrical isolation between control and field circuits, needs to switch both AC and DC loads within a single system, or involves inductive loads that benefit from relay contact arc suppression. For applications exceeding 100 switching cycles per minute, consider solid-state output modules to extend service life. Verify that your PLC-5 chassis power supply can support the 150mA backplane current requirement when fully populated with I/O modules.

Extended Functions

Diagnostic Integration: The module supports PLC-5 diagnostic routines that monitor output status and detect open-circuit or short-circuit faults. Integrate these diagnostics with SCADA systems via Ethernet/IP or DH+ networks for centralized alarm management and predictive maintenance scheduling.

Load Suppression Compatibility: While relay contacts inherently suppress arcing on inductive loads, external RC snubbers or MOV suppressors can be added for applications with highly inductive coils (solenoids >50W) to maximize contact life and reduce electrical noise.

Customization Options: Field wiring terminals accept 14-22 AWG wire for flexible installation. Removable terminal blocks (RTBs) are available as accessories to simplify module replacement during maintenance without disturbing field wiring.

Delivery & Service Assurance

Standard Lead Time: In-stock units ship within 1-2 business days via express courier. Custom configurations or bulk orders (10+ units) typically require 5-7 business days for preparation and testing.

Warranty Coverage: 12-month manufacturer warranty covers defects in materials and workmanship. Warranty includes free replacement and return shipping for confirmed manufacturing defects.

Technical Support: Access to application engineers for wiring diagrams, troubleshooting guidance, and integration assistance. Support available via email, phone, and remote desktop sessions during business hours (GMT+8).

Documentation Package: Each module ships with installation quick-start guide, wiring diagrams, and digital access to full technical manual (PDF). Ladder logic examples and DeviceNet EDS files available for download from support portal.

Frequently Asked Questions

Q: What is the maximum wire size for field wiring connections on the 1771-OW16 module?
A: The terminal blocks accept 14-22 AWG copper wire (solid or stranded). Use ferrules for stranded wire to ensure reliable contact pressure and prevent strand breakage during tightening.

Q: Can I control 480V AC motor starters directly with this relay output module?
A: No, the 1771-OW16 is rated for maximum 250V AC. For 480V applications, use the relay outputs to drive intermediate control relays or contactors rated for the higher voltage.

Q: How do I calculate the expected relay contact lifespan in my application?
A: Contact life depends on load type and current. At rated 2A resistive load, expect 100,000 cycles. Inductive loads (solenoids, relay coils) reduce life by 50-70%. Use the formula: Expected Life = 100,000 × (Rated Current / Actual Current)² for resistive loads.

Q: Does the 1771-OW16 require external power supply for the relay coils?
A: No, relay coil power is drawn from the PLC-5 chassis backplane (150mA @ 5V DC). Ensure your chassis power supply has sufficient capacity when adding multiple I/O modules.

Q: Is remote monitoring of output status possible with this module?
A: Yes, output states are readable via PLC-5 ladder logic and can be transmitted to HMI/SCADA systems through the controller's network interface (Ethernet/IP, DH+, or ControlNet).

Q: What installation clearances are required for proper heat dissipation?
A: Maintain minimum 50mm (2 inches) clearance above and below the module when mounted in enclosed panels. Ensure ambient temperature does not exceed 60°C and provide forced ventilation if panel temperature approaches this limit.

Take the Next Step

Ready to integrate the 1771-OW16 into your control system? Contact our application specialists for technical consultation, custom configuration assistance, or volume pricing. Request a detailed quotation with your specific requirements, and we'll respond within 4 business hours with tailored recommendations and delivery options.
