Allen-Bradley 1747-SN/B DH+ Network Interface | SLC 500 Module
Verify the part, confirm the platform family, and move straight into quotation with the right commercial details.
RFQ Ready
- SKU1747-SN/B
- CategoryPLC & Industrial Automation Modules
- BrandAllen-Bradley (Rockwell)
- SupportAvailability, lead time, condition, and shipping coordination
How Buyers Usually Use This Page
- Confirm the exact part number and platform family before sending the quote request.
- Use direct email when quantity, condition, and destination are already defined internally.
- Switch to the broader brand or category archive when you need alternates nearby.
Series Navigation
Move through the most common platform families behind this part.
Product RFQ
Send this part directly for quotation.
Include quantity, required condition, destination country, and target delivery timing. Current reference: Allen-Bradley 1747-SN/B DH+ Network Interface | SLC 500 Module with SKU 1747-SN/B.
Allen-Bradley 1747-SN/B SLC 500 DH+ Network Interface Module
The Allen-Bradley 1747-SN/B is a high-performance DH+ (Data Highway Plus) network interface module engineered for seamless integration with SLC 500 modular controller systems. This genuine Rockwell Automation component enables robust peer-to-peer communication across distributed control architectures, delivering deterministic data exchange at speeds up to 230.4 Kbps.
Technical Specifications
- Catalog Number: 1747-SN/B
- Series: B Revision
- Network Protocol: DH+ (Data Highway Plus)
- Communication Speed: 57.6, 115.2, or 230.4 Kbps (selectable)
- Maximum Network Nodes: 64 devices per segment
- Backplane Current Draw: 200 mA @ 5V DC, 50 mA @ 24V DC
- Operating Temperature: 0 to 60 °C (32 to 140 °F)
- Mounting: Standard SLC 500 chassis slot
- Certifications: UL Listed, C-UL, CE compliant
Key Applications
This network interface module excels in multi-controller environments requiring coordinated process control, including manufacturing assembly lines, material handling systems, batch processing operations, and SCADA integration projects. It supports MSG instruction-based data sharing between up to 64 SLC processors, PanelView terminals, and RSLogix programming workstations on a single DH+ trunk.
Integration & Compatibility
The 1747-SN/B installs directly into any available slot within SLC 500 chassis (1746 series), automatically recognized by the processor upon power-up. It maintains full compatibility with RSLinx Classic gateway software and integrates with FactoryTalk View SE/ME for real-time HMI data visualization. The module supports both polled and unsolicited messaging modes for flexible system architecture design.
Common Questions
Q: Can I mix different baud rates on the same DH+ network?
A: No, all devices on a DH+ segment must operate at the same communication speed. Configure all nodes to match via rotary switches or software settings.
Q: What cable type is required for DH+ connections?
A: Use Belden 9463 or equivalent twin-axial shielded cable with 1747-C series connectors. Maximum segment length is 10,000 feet at 57.6 Kbps.
Q: Does this module support remote I/O communication?
A: No, the 1747-SN is designed exclusively for DH+ peer-to-peer messaging. For remote I/O, use the 1747-SDN scanner or 1746-ASB adapter modules.
Warranty & Support
Every 1747-SN/B module is backed by our comprehensive 12-month warranty covering manufacturing defects and functional failures. Our technical support team provides configuration assistance, troubleshooting guidance, and replacement coordination to minimize downtime in critical automation environments.
Related Products
| Product | Description | Link |
|---|---|---|
| 1747-BSN BACnet Adapter | BACnet communication interface for building automation integration | View Product |
| 1747-DCM Direct Module | Direct communication module for RS-232/RS-422/RS-485 serial protocols | View Product |
| 1747-ASB DH Adapter | Remote I/O adapter for distributed chassis communication | View Product |
