1606-XL240DR Industrial DIN Rail Power Supply (240-Watt Switched-Mode Design)

The 1606-XL240DR represents a robust switched-mode power solution engineered for mission-critical industrial control applications. This 240-watt unit converts universal AC input into stable 24VDC output, powering ControlLogix platforms, distributed I/O networks, and automation peripherals across manufacturing, process control, and machine automation sectors.

Designed for system integrators and plant engineers who demand reliability in harsh environments, this power supply addresses voltage fluctuation challenges, thermal stress concerns, and space constraints common in industrial panels. Its auto-ranging input eliminates manual voltage selection, while convection cooling extends operational lifespan in high-temperature enclosures.

With DIN rail mounting, comprehensive protection circuits, and global safety certifications, the 1606-XL240DR delivers consistent performance for automation systems requiring uninterrupted 24VDC power delivery.

Core Features & Benefits

→ Auto-Sensing Universal Input (100-240VAC)
Eliminates voltage selector switches and simplifies global deployments. Automatically adapts to regional power standards, reducing installation errors and inventory complexity across multi-site operations.

→ High-Efficiency Switched-Mode Topology (>89%)
Minimizes heat generation and energy waste compared to linear supplies. Reduces cooling requirements and lowers operational costs in large-scale installations with multiple power supplies.

→ Extended Temperature Range (-25°C to +70°C)
Maintains stable output across extreme ambient conditions. Enables deployment in outdoor enclosures, foundries, cold storage facilities, and other challenging thermal environments without derating concerns.

✓ Comprehensive Protection Suite
Integrated overload, short-circuit, and over-temperature safeguards prevent cascading failures. Automatically recovers from fault conditions, minimizing downtime and protecting downstream equipment investments.

✓ Compact DIN Rail Form Factor (35mm Standard)
Maximizes panel density and simplifies wire management. Snap-on mounting accelerates installation while maintaining secure mechanical retention during vibration and shock events.

✓ Adjustable Output Voltage (24-28VDC)
Compensates for voltage drop in long cable runs or high-current applications. Fine-tune output to match specific equipment requirements without external regulators or boosters.

Application Scenarios

Manufacturing Automation Lines
Powers ControlLogix chassis, servo drives, and HMI panels in automotive assembly, packaging machinery, and material handling systems. Addresses the challenge of coordinating multiple 24VDC loads with varying current demands while maintaining voltage stability during motor start-up transients.

Process Control Installations
Supplies reliable power for distributed I/O modules, field transmitters, and valve actuators in chemical processing, water treatment, and pharmaceutical production. Solves the problem of maintaining control system integrity during utility power fluctuations or brownout conditions.

Machine Control Panels
Energizes PLC systems, safety relays, and sensor networks in CNC machines, injection molding equipment, and robotic work cells. Eliminates concerns about inrush current coordination with circuit breakers during simultaneous equipment startup.

Building Automation Systems
Drives HVAC controllers, access control hardware, and lighting management modules in commercial facilities. Provides the voltage regulation needed for mixed-load environments where inductive and capacitive devices share common power rails.

Renewable Energy Installations
Supports monitoring equipment and control systems in solar farms, wind turbines, and battery storage facilities. Withstands temperature extremes and voltage variations typical of outdoor electrical enclosures in remote locations.

Technical Parameters & Selection Guide

Selection Criteria: Calculate total current draw of all connected 24VDC loads, including startup surge requirements. Add 20-30% safety margin for future expansion and thermal derating. For applications requiring >8A continuous at elevated temperatures (>60°C), consider the next higher wattage model or implement forced-air cooling. Verify input circuit breaker coordination using the 30A inrush specification.

Extended Functions

Redundancy Configuration Support: When paired with the 1606-XLERED redundancy module (sold separately), enables N+1 backup power architectures. Two or more units operate in parallel with automatic load sharing and seamless failover, ensuring continuous operation during maintenance or component failure.

Remote Monitoring Integration: DC OK relay output provides dry contact status signal for integration with SCADA systems, building management platforms, or remote monitoring solutions. Enables predictive maintenance strategies by tracking power supply health metrics.

Custom Voltage Configurations: Factory customization available for non-standard output voltages (12VDC, 48VDC) or specialized input requirements. Contact technical sales for minimum order quantities and lead times for modified units.

Delivery & Service Assurance

Standard Delivery: 3-5 business days for in-stock units via express courier. Expedited same-day shipping available for critical downtime situations (additional fees apply).

Custom Orders: 10-15 business days for non-standard configurations or bulk quantities requiring factory allocation.

Warranty Coverage: Comprehensive 12-month warranty against manufacturing defects and component failures. Covers parts, labor, and return shipping for warranty-eligible repairs or replacements.

Technical Support: Access to application engineers for installation guidance, troubleshooting assistance, and system integration consultation. Email and phone support available during business hours (GMT+8).

Documentation Package: Includes installation manual, wiring diagrams, derating curves, dimensional drawings, and compliance certificates. Digital downloads available immediately upon order confirmation.

Frequently Asked Questions

What is the recommended circuit breaker rating for this 240-watt power supply?
Use a 10A Type C or D circuit breaker on the AC input side to accommodate the 30A inrush current during cold starts. This prevents nuisance tripping while providing adequate overcurrent protection for the input wiring.

Can I parallel multiple units without the redundancy module for higher current capacity?
No, direct paralleling without the 1606-XLERED module is not recommended. The units lack active current-sharing circuitry, which can result in unbalanced loading and premature failure. Use the redundancy module or select a higher-wattage single unit.

How much energy savings can I expect compared to a linear power supply?
At full 240W load, this switched-mode design dissipates approximately 30W as heat (>89% efficiency). An equivalent linear supply would dissipate 120-150W, reducing cooling costs by 75-80% and lowering panel temperature by 15-20°C in typical installations.

Does this unit require periodic maintenance or calibration?
No scheduled maintenance is required. The electrolytic capacitors are rated for 10+ years at maximum operating temperature. Verify output voltage annually using a calibrated multimeter, and inspect terminal connections for tightness during routine panel inspections.

Is the output isolated from the input for safety compliance?
Yes, the unit provides 4kVAC input-to-output isolation per UL/CE requirements. This galvanic isolation prevents ground loops and protects sensitive control equipment from AC line transients and noise.

What wire gauge should I use for the 24VDC output connections?
For 10A maximum current, use minimum 14 AWG (2.5mm²) copper wire for runs up to 10 meters. For longer distances or to minimize voltage drop, upgrade to 12 AWG (4mm²). Ensure terminal torque does not exceed 0.8 Nm to prevent damage.

Take the Next Step

Ready to upgrade your control panel power infrastructure? Add the 1606-XL240DR to your cart now for fast delivery, or contact our technical sales team at sale@ninermas.com for volume pricing, custom configurations, or application-specific recommendations. Our engineers are standing by to help you select the optimal power solution for your automation project.
