3BHL000359P0003 ABB Capacitor Filter 3×80µF 2750V Industrial Grade

ABB 3BHL000359P0003 Capacitor Filter – Industrial-Grade Power Filtering Solution

The ABB 3BHL000359P0003 is a high-performance capacitor filter engineered for demanding industrial automation environments. This triple-capacitor configuration (3×80µF) rated at 2750V delivers superior harmonic filtering and power quality enhancement for drive systems, motor control applications, and industrial power electronics.

Technical Specifications

• Model Number: 3BHL000359P0003
• Capacitance: 3 x 80µF
• Voltage Rating: 2750V DC
• Weight: 59 kg
• Origin: Czech Republic
• Condition: Brand New, Factory Sealed
• Manufacturer: ABB

Application Scenarios

This capacitor filter excels in multiple industrial contexts:

• Variable Frequency Drives (VFD): Reduces harmonic distortion in AC drive systems, protecting sensitive equipment downstream
• DC Link Filtering: Smooths voltage ripple in rectifier circuits and DC bus applications
• Motor Control Centers: Enhances power factor correction and reduces electromagnetic interference
• Industrial Automation Systems: Integrates seamlessly with ABB S800 I/O platforms and AC800M controllers
• Renewable Energy Systems: Stabilizes power conversion in solar inverters and wind turbine converters

Engineering Solutions & Benefits

Harmonic Mitigation: The 3×80µF configuration effectively attenuates 5th, 7th, and 11th harmonics, ensuring IEEE 519 compliance in industrial power systems.

Thermal Management: Robust construction with high-temperature dielectric materials ensures reliable operation in ambient temperatures up to 55°C, critical for enclosed panel installations.

System Integration: Compatible with ABB’s ecosystem including ACS800 drives, IRC5 robot controllers, and distributed control systems (DCS).

Related ABB Components

Enhance your automation system with these compatible products:

• ABB 3AUA0000030736 ACS800 Capacitor Insulating Sparepart Kit – Maintenance kit for ACS800 drives
• ABB CI801 PROFIBUS FCI S800 Interface 3BSE022366R1 – S800 I/O communication module
• ABB RXFILTER P4RX Receive Filter Module 1KHL001356R0001 – Signal filtering solution

Frequently Asked Questions

Q: Is this capacitor filter suitable for retrofit applications?
A: Yes, the 3BHL000359P0003 is designed for both new installations and retrofit projects. Its standard mounting configuration allows easy integration into existing ABB drive cabinets and control panels.

Q: What is the expected service life?
A: Under normal operating conditions (rated voltage, ambient temperature ≤40°C), the capacitor filter offers a design life exceeding 100,000 hours. Regular inspection every 24 months is recommended.

Q: Does this unit require special installation considerations?
A: Installation should follow ABB’s technical guidelines. Ensure adequate ventilation (minimum 100mm clearance), proper grounding, and torque specifications for terminal connections (8-10 Nm). Consult installation manual 3BHL000359P0003-IM for detailed procedures.

Q: Can this filter handle voltage transients?
A: The unit is rated for 2750V continuous operation with transient capability up to 3000V for short durations (≤1 second), providing robust protection against voltage spikes common in industrial environments.

Warranty & Support

All units include a comprehensive 12-month manufacturer warranty covering defects in materials and workmanship. Technical support and application engineering assistance available through Industrial Control Hub’s expert team.

Quality Assurance

Every 3BHL000359P0003 capacitor filter undergoes rigorous factory testing including dielectric strength verification, capacitance tolerance measurement (±5%), and insulation resistance testing (>1000MΩ). Supplied with original ABB packaging and certification documentation.
