Siemens 6ES7134-6JD00-0CA1 Analog Input Module ET 200SP New Original Ready to ship

RFQ Ready

Request pricing & availability

SKU6ES7134-6JD00-0CA1
CategoryPLC & Industrial Automation Modules
BrandSiemens
SupportAvailability, lead time, condition, and shipping coordination

How Buyers Usually Use This Page

Confirm the exact part number and platform family before sending the quote request.
Use direct email when quantity, condition, and destination are already defined internally.
Switch to the broader brand or category archive when you need alternates nearby.

Series Navigation

Move through the most common platform families behind this part.

Simatic S5 Simatic S7-400 Moore APACS+

6ES7134-6JD00-0CA1 — Siemens ET 200SP High-Feature Analog Input Module | 100% Original Spare Parts

The 6ES7134-6JD00-0CA1 is a factory-sealed, 100% Brand New and Factory Sealed analog input module manufactured by Siemens for the SIMATIC ET 200SP distributed I/O platform. Engineered to deliver 16-bit measurement resolution across 4 independent channels, this module supports RTD and thermocouple (TC) signal types — making it a cornerstone component in precision-driven Industrial Automation and PLC System architectures. As a certified Original New Spare Part, the 6ES7134-6JD00-0CA1 is sourced directly from authorized supply chains, ensuring full compatibility with SIMATIC S7-1200, S7-1500, and ET 200SP BaseUnit configurations.

Procurement teams and site engineers working in process-critical environments — including Oil & Gas, Power Plants, Pharmaceuticals, and Food & Beverage — consistently rely on this Control Module to maintain measurement integrity under harsh operating conditions. Its extended temperature range (-40°C to +70°C), channel-to-channel isolation, and built-in wire-break diagnostics address the most demanding uptime requirements in modern industrial facilities.

Whether you are replacing an end-of-life component or expanding an existing ET 200SP rack, this module ships fast and arrives ready to install. Contact our team today for pricing, lead time, and datasheet access.

Typical Application Scenarios

From the perspective of a Senior Engineer, the 6ES7134-6JD00-0CA1 solves real-world measurement challenges across multiple verticals:

✅ Oil & Gas: Continuous RTD-based temperature monitoring in pipeline and refinery control loops where sensor drift causes costly shutdowns.
Power Plants: Thermocouple integration for turbine exhaust and boiler temperature feedback within DCS and SIS architectures.
✅ Pharmaceutical Manufacturing: FDA-compliant temperature logging in cleanroom environments requiring ±0.1% measurement accuracy.
✅ Food & Beverage: Pasteurization and sterilization process control where precise thermal management is a regulatory requirement.
✅ Heavy Industry & Drives: Integration with variable frequency drives and motor control centers for thermal protection feedback loops.

Technical Specifications & Selection Guide

Specification	Value
Part Number / SKU	6ES7134-6JD00-0CA1
Manufacturer	Siemens
Product Family	SIMATIC ET 200SP
Module Type	High-Feature Analog Input
Number of Channels	4
Signal Types Supported	RTD (Pt100, Pt200, Pt500, Pt1000, Ni100, Ni1000) / TC (Type B, E, J, K, L, N, R, S, T, U)
Resolution	16-bit
Measurement Accuracy	±0.1% of full scale
Operating Temperature	-40°C to +70°C
Isolation	Channel-to-channel & channel-to-backplane
Diagnostics	Wire-break detection, sensor fault monitoring
Module Width	15 mm
Mounting	ET 200SP BaseUnit (DIN rail)
Engineering Software	TIA Portal V13 SP1 and above
Communication Interface	PROFINET via ET 200SP head module
Condition	100% Original and Brand New

Selection Tip: If your application requires HART-enabled analog inputs, consider the Siemens 6ES7134-6TD00-0CA1 as an alternative. For standard ±10V / 0-20mA voltage/current inputs, the 6ES7134-6GD00-0CA1 is the recommended variant.

Core Features & Technical Advantages

Robust 16-Bit Resolution: Delivers high-precision analog-to-digital conversion, minimizing quantization error in temperature-sensitive control loops.
Heavy-Duty Operating Range: Rated for -40°C to +70°C ambient — engineered for outdoor substations, cold storage facilities, and high-heat industrial zones.
Precision Multi-Sensor Support: Each channel independently configurable for RTD or TC input types, eliminating the need for separate modules per sensor technology.
Advanced Diagnostics: Real-time wire-break detection and sensor fault alarms reduce mean time to repair (MTTR) in critical PLC System environments.
Hot-Swap Capability: Replace the module without powering down the ET 200SP station — a critical advantage for 24/7 production environments.
Compact 15mm Footprint: Maximizes cabinet density in space-constrained control panels without sacrificing channel count or performance.

Logistics & Professional Service

Condition: 100% Original and Brand New — factory sealed with full Siemens traceability documentation available upon request.
✅ Shipping: 2-Day Express Shipping available to major global destinations; standard air freight typically 5-7 business days worldwide.
✅ Warranty: 1-Year Warranty covering manufacturing defects and functional failures under normal operating conditions.
✅ EOL & Legacy Support: We maintain stock of discontinued and hard-to-find Siemens ET 200SP modules to support legacy PLC System upgrades and emergency replacements.
✅ Documentation: Official Siemens datasheet, CE declaration of conformity, and country-of-origin certificate available upon request.
✅ Global Coverage: Serving customers in North America, Europe, Southeast Asia, Middle East, and Africa.

FAQ — Frequently Asked Questions

Q1: What is the price of the 6ES7134-6JD00-0CA1?
A: Pricing for the 6ES7134-6JD00-0CA1 varies based on order quantity, destination, and current market availability. We offer competitive pricing for both single-unit emergency orders and bulk procurement contracts. Please contact us at sale@ninermas.com or submit an inquiry for a formal quotation within 24 hours.

Q2: What is the lead time for this module?
A: In-stock units ship within 1-2 business days. For high-volume orders or specific batch requirements, lead time is typically 3-7 business days. We maintain safety stock of popular Siemens ET 200SP modules to support urgent industrial automation projects.

Q3: Can you provide the official Siemens datasheet for the 6ES7134-6JD00-0CA1?
A: Yes. The official Siemens product manual and datasheet are available upon request. Contact our technical team and we will provide the documentation package including wiring diagrams, parameter lists, and TIA Portal configuration guides.

Q4: Is this module 100% original from Siemens?
A: Absolutely. All units are 100% Original and Brand New, sourced from authorized Siemens distribution channels. We can provide certificates of origin, packing lists, and traceability documentation to satisfy your quality assurance requirements.

Q5: Is the 6ES7134-6JD00-0CA1 compatible with TIA Portal V15 and V16?
A: Yes. This module is fully supported in TIA Portal V13 SP1 and all subsequent versions including V15, V16, and V17. The hardware catalog entry is available in the standard TIA Portal installation.

Q6: Do you support customers replacing obsolete or end-of-life Siemens modules?
A: Yes. We specialize in sourcing Original New Spare Parts for legacy and EOL industrial automation systems. Whether you need a single Control Module or a full system refresh, our team can assist with cross-referencing, compatibility verification, and expedited delivery.
