3TK2821-2CB30 Industrial-Grade Safety Relay for Critical Machine Protection

Engineered for fail-safe operation in high-risk industrial environments, the 3TK2821-2CB30 safety relay delivers certified protection for emergency stop systems, safety gate monitoring, light curtain integration, and two-hand control applications. This compact 22.5mm DIN-rail module combines German precision engineering with universal 24V AC/DC compatibility, providing reliable personnel and equipment safeguarding across manufacturing, packaging, and metalworking operations.

Designed for system integrators and safety engineers who demand compliance with EN ISO 13849-1 Category 4 (PLe) and IEC 61508 SIL 3 standards, this relay eliminates the complexity of safety circuit design through built-in self-monitoring, cross-circuit fault detection, and automatic diagnostic capabilities. The spring-type terminal design ensures vibration-resistant connections without ferrules, reducing installation time while maintaining long-term reliability in demanding production environments.

Whether you're upgrading legacy safety systems or designing new machine control architectures, the 3TK2821-2CB30 offers flexible start mode selection (automatic/manual reset), redundant contact monitoring, and compatibility with series or parallel safety device configurations—delivering comprehensive protection that meets global safety regulations.

Core Features & Industrial Benefits

✓ Universal Voltage Compatibility: Single relay accepts both 24V AC and 24V DC control inputs, eliminating the need for separate inventory and simplifying multi-voltage installations across diverse equipment fleets.

✓ Rapid Safety Response: ≤30ms reaction time ensures immediate circuit interruption when hazardous conditions are detected, minimizing exposure risk during emergency stop activation or guard door opening.

✓ Dual-Channel Redundancy: 3NO + 1NC contact configuration with cross-monitoring detects single-point failures, contact welding, and wiring errors—automatically preventing dangerous machine restart conditions.

✓ Tool-Free Installation: Spring-type screw terminals accept solid or stranded conductors without ferrules, reducing assembly time by 40% while maintaining IP20-rated protection and vibration resistance.

✓ Certified Safety Performance: Meets EN ISO 13849-1 (Cat. 4, PLe) and IEC 61508 (SIL 3) requirements with TÜV certification, ensuring compliance for CE marking and global machinery safety directives.

✓ Compact Space-Saving Design: 22.5mm mounting width fits standard DIN rails, allowing high-density panel layouts—ideal for retrofitting existing control cabinets without expansion.

Application Scenarios Across Industries

→ Automated Assembly & Robotics: Safeguard collaborative robot cells and automated assembly stations by integrating with emergency stop buttons and safety mats. When operators enter hazardous zones, the relay instantly de-energizes robot drives and pneumatic actuators, preventing collision injuries while maintaining production uptime through quick manual reset capability.

→ High-Speed Packaging Lines: Monitor hinged safety guards and access panels on form-fill-seal machines, cartoning equipment, and palletizers. The relay's automatic start mode enables seamless production resumption after brief maintenance access, while manual mode enforces deliberate operator verification for extended service interventions.

→ Metal Fabrication & Press Brake Operations: Connect to two-hand control stations and Type 4 light curtains for press brake, stamping press, and shear applications. Dual-channel monitoring ensures that both safety inputs must be active before enabling machine motion, meeting OSHA 1910.217 requirements for mechanical power press safeguarding.

→ Conveyor & Material Handling Systems: Implement emergency stop pull-cord switches along conveyor runs exceeding 15 meters. Series connection of multiple e-stop devices through a single relay simplifies wiring while maintaining individual station identification through auxiliary contact monitoring.

→ Food & Beverage Processing: Deploy in washdown-adjacent control panels (IP20 housing suitable for protected enclosures) to monitor safety interlocks on mixers, slicers, and filling equipment. Wide -25°C to +60°C operating range accommodates cold storage and thermal processing environments.

Technical Parameters & Selection Guide

Selection Criteria: Choose automatic start mode for applications requiring immediate production resumption after transient faults (e.g., light curtain interruptions). Select manual start mode for high-risk operations where deliberate operator verification is required before re-energization (e.g., press brake maintenance). For applications requiring more than 6 safety input devices, consider expandable modular safety systems with additional input modules.

Extended Functionality & Integration Options

PLC Integration: The semiconductor diagnostic output provides real-time relay status to SIMATIC S7, Allen-Bradley, or Modicon PLCs, enabling centralized safety monitoring dashboards and predictive maintenance alerts based on contact cycle counting.

Cascaded Safety Zones: Multiple 3TK2821-2CB30 relays can be interconnected to create hierarchical safety zones—allowing selective machine section shutdown while maintaining operation in non-affected areas, optimizing production continuity during localized maintenance.

Customization for OEMs: Available with custom terminal labeling and pre-configured start mode settings for machine builders requiring consistent safety architectures across equipment lines. Consult factory for minimum order quantities and lead times.

Delivery Timeline & Service Guarantee

Standard Delivery: In-stock units ship within 2-3 business days via express courier with tracking. Typical transit time to major industrial hubs: 5-7 business days.

Custom Configuration: Factory-programmed units with specific start modes or terminal labeling require 3-4 weeks lead time. Contact our technical sales team for project-specific requirements.

Warranty Coverage: 12-month manufacturer warranty against defects in materials and workmanship. Warranty includes free replacement and covers return shipping costs.

Technical Support: Complimentary application engineering assistance includes wiring diagram review, safety category calculations, and compliance documentation preparation. Phone and email support available during business hours (GMT+8).

Documentation Package: Each relay ships with installation manual, wiring diagrams, CE declaration of conformity, and TÜV test certificates—ready for machinery technical file compilation.

Frequently Asked Questions

How do I wire multiple emergency stop buttons to this safety relay?
Connect emergency stop normally-closed contacts in series to the relay's safety input terminals (S11-S12 and S21-S22). The relay monitors both channels simultaneously—if any e-stop is activated, both channels open and the relay de-energizes. Up to 6 e-stop devices can be series-connected without additional components.

What's the maximum load current for the safety contacts?
Each normally-open (NO) contact is rated for 6A at 250V AC or 6A at 24V DC. For inductive loads like contactor coils, use appropriate RC snubbers (AC) or flyback diodes (DC) to prevent contact arcing and extend relay life beyond 100,000 switching cycles.

Can this relay monitor both safety gates and emergency stops simultaneously?
Yes—connect emergency stop devices in series on one safety input channel and safety gate switches in series on the second channel. Both channels must be closed for the relay to energize, providing dual-path monitoring that meets Category 4 redundancy requirements.

Does the relay require external monitoring relays for SIL 3 compliance?
No external monitoring is needed. The 3TK2821-2CB30 includes built-in cross-circuit fault detection and automatic self-testing that continuously verifies internal relay function, contact status, and wiring integrity—meeting SIL 3 requirements as a standalone device.

What happens if the control voltage drops below 24V during operation?
The relay incorporates under-voltage protection that automatically de-energizes safety contacts when supply voltage falls below 19.2V (80% of nominal). This prevents undefined states during power fluctuations and ensures fail-safe operation during brownout conditions.

Is this relay suitable for outdoor or washdown environments?
The IP20 housing is designed for installation inside protected control enclosures. For outdoor or washdown applications, mount the relay in a NEMA 4X or IP65-rated panel with appropriate environmental sealing. The relay's -25°C to +60°C operating range accommodates most climate-controlled and extreme-temperature installations.
