The Raytek RAYMI310LTSCB3 is a fiber optic infrared temperature sensing head from the MI310 series, engineered for non-contact temperature measurement in demanding industrial environments. Designed for integration with the MI3100 digital controller, this sensing head delivers reliable, continuous process temperature data across metal processing, glass manufacturing, semiconductor fabrication, plastics extrusion, and energy generation facilities. When a RAYMI310LTSCB3 fails or degrades, the impact is immediate: process visibility is lost, quality control is compromised, and unplanned downtime begins to accumulate costs. Maintaining a service-ready spare in your parts inventory is the most effective strategy to protect continuous operation.

At NINERMAS, every RAYMI310LTSCB3 unit is sourced as an original Raytek component, pre-shipment tested for optical integrity and signal output, and backed by a 12-month warranty. Our global logistics network ensures fast dispatch to maintenance teams across Asia, Europe, the Middle East, and the Americas — minimizing the gap between failure and restoration.

Spare Maintenance Table

Maintenance Planning for Continuous Operation

Replacing the RAYMI310LTSCB3 sensing head is rarely an isolated task. In a well-maintained MI310 measurement loop, the sensing head works in concert with several interconnected components, and a failure event is the ideal moment to audit the entire measurement chain before returning the system to service.

Begin with the MI3100 digital controller — the signal processor that receives the infrared signal from the RAYMI310LTSCB3 via the fiber optic cable. Inspect the controller’s front panel display, analog output terminals, and internal calibration settings. If the controller has been in service for more than five years alongside the failed sensing head, consider stocking a spare MI3100 unit to eliminate the controller as a future single point of failure.

Next, examine the fiber optic extension cable connecting the sensing head to the controller. The CB3 designation on the RAYMI310LTSCB3 indicates a 3-meter integrated cable; if the installation requires a longer run, verify that any extension fiber is rated for the MI3 series and shows no signs of bending stress, contamination, or connector wear. A degraded fiber connection will produce erratic temperature readings even with a new sensing head installed.

Check the 24 VDC DIN rail power supply feeding the MI3100 controller. Voltage sags or ripple on the supply rail can cause measurement instability that mimics a failing sensing head. Use a multimeter to confirm supply voltage is within the MI3100’s specified input range before commissioning the replacement sensing head.

If the MI310 loop feeds a PLC or DCS via a 4–20 mA analog input card, verify the input channel calibration and confirm the loop resistance is within specification. A corroded terminal block or a loose wire ferrule at the I/O card can introduce offset errors that are difficult to distinguish from a sensor fault. Inspect all DIN rail terminal blocks in the control cabinet for signs of oxidation, overheating, or loose clamping.

Where the MI310 output is transmitted over longer distances or into a shared analog bus, a signal isolator is often installed between the MI3100 and the PLC input. Confirm the isolator’s output is clean and within range; aging isolators can introduce non-linearity that corrupts the temperature reading at the controller level.

For installations using the optional MI3COMM communication box, verify RS485 or RS232 communication integrity after the sensing head replacement. Re-run the MI3COMM configuration utility to confirm the new sensing head’s emissivity and temperature range settings are correctly loaded into the controller.

Finally, inspect the mechanical installation: the air purge collar (MI3-AP) and any cooling jacket fitted around the sensing head. Blocked air purge ports allow particulate contamination to accumulate on the fiber optic tip, accelerating the next failure cycle. Clean or replace the air purge assembly as part of every sensing head replacement procedure. If the ambient temperature at the sensing head location regularly exceeds the MI310 LTS head’s rated ambient limit, confirm the cooling jacket is functioning and that the cooling air or water supply is uninterrupted.

Site Replacement Workflow

Step 1 — Isolate and document. Before removing the failed RAYMI310LTSCB3, record the MI3100 controller’s current emissivity setting, temperature range configuration, and analog output calibration values. Take a photograph of the fiber optic routing and connector orientation. This documentation eliminates configuration errors during recommissioning and is essential for traceability in ISO-certified maintenance environments.

Step 2 — Remove the failed sensing head. Disconnect the fiber optic cable from the MI3100 controller input port. Loosen the sensing head mounting bracket and carefully extract the head from the process aperture. Inspect the fiber optic tip for contamination, physical damage, or discoloration. If the tip shows signs of thermal overexposure, review the installation geometry and cooling provisions before installing the replacement.

Step 3 — Install the RAYMI310LTSCB3 replacement. Route the 3-meter fiber optic cable to avoid sharp bends (observe the minimum bend radius specified in the MI310 installation guide). Reconnect the fiber optic connector to the MI3100 input port, ensuring the connector is fully seated and the locking mechanism is engaged. Reinstall the air purge collar and verify the purge air supply is active before exposing the sensing head to process conditions.

Step 4 — Restore controller configuration. Enter the emissivity, temperature range, and analog output settings recorded in Step 1. If the replacement sensing head has a different emissivity characteristic from the failed unit (possible with aged or non-original parts), recalibrate against a known reference before returning the loop to automatic control. Original Raytek RAYMI310LTSCB3 units from NINERMAS are factory-matched to MI310 series specifications, eliminating this recalibration risk.

Step 5 — Verify and recommission. Confirm the MI3100 display shows a stable, plausible temperature reading. Check the 4–20 mA output at the PLC or DCS input card. Log the replacement in the maintenance management system with the new unit’s serial number and the date of installation. Update the spare parts inventory to trigger a reorder for the next RAYMI310LTSCB3 unit.

Spare Parts Support FAQ

Q1: Is the RAYMI310LTSCB3 a direct drop-in replacement for older MI310 LTS sensing heads?
Yes. The RAYMI310LTSCB3 is designed as a direct replacement for MI310 LTS series sensing heads with a 3-meter fiber optic cable. It is fully compatible with the MI3100 digital controller and MI3 series signal processors without hardware modification. Confirm the emissivity setting in the MI3100 after installation, as individual sensing heads may have slightly different factory emissivity values documented on the calibration label.

Q2: How does NINERMAS verify the condition of RAYMI310LTSCB3 units before shipment?
Every unit undergoes a pre-shipment inspection that includes visual examination of the fiber optic tip and cable, connector integrity check, and where test equipment is available, a functional signal output verification. Units that do not meet original Raytek specifications are rejected. Each shipment is accompanied by a packing list and, upon request, a test report. All units are covered by NINERMAS’s standard 12-month warranty from the date of shipment.

Q3: What is the recommended spare parts strategy for MI310 series installations?
For facilities with one to three MI310 measurement points, maintain at least one RAYMI310LTSCB3 sensing head in local inventory at all times. For facilities with four or more measurement points, consider a two-unit buffer stock and a standing replenishment agreement with NINERMAS to ensure continuous availability. The MI3100 controller and MI3COMM communication box should also be included in the critical spare parts list for high-availability process lines.

Q4: Can NINERMAS support long-term supply of the RAYMI310LTSCB3 given that Raytek MI310 series products are approaching end-of-life?
Yes. NINERMAS specializes in sourcing and stocking spare parts for legacy and end-of-life industrial automation components. We maintain reserved inventory agreements with our supply network to ensure continued availability of MI310 series components including the RAYMI310LTSCB3, MI3100 controller, and associated accessories. Contact our team to discuss a long-term supply agreement tailored to your facility’s maintenance schedule and annual consumption.
