Emerson KJ3224X1-BA1 Thermocouple / mV Input Card

Verify the part, confirm the platform family, and move straight into quotation with the right commercial details.

SKU: KJ3224X1-BA1 DCS Distributed Control Systems EMERSON

RFQ Ready

Pricing by RFQ
Download Datasheet PDF

Use the local datasheet to verify specifications, compatibility, and selection notes before sending the RFQ.

How Buyers Usually Use This Page

  • Confirm the exact part number and platform family before sending the quote request.
  • Use direct email when quantity, condition, and destination are already defined internally.
  • Switch to the broader brand or category archive when you need alternates nearby.

Series Navigation

Move through the most common platform families behind this part.

General Information

Field

Description

Manufacturer

Emerson

Model/Part Number

KJ3224X1-BA1

Description

Thermocouple / mV Input Card


Power Specifications

Parameter

Value

Local Bus Power

12 VDC at 210 mA


Environmental Specifications

Parameter

Value

Ambient Temperature

-40 °C to +70 °C

Shock

10 g half-sine wave for 11 ms

Vibration

1 mm peak-to-peak (2-13.2 Hz); 0.7 g (13.2-150 Hz)

Airborne Contaminants

ISA-S71.04 1985, Class G3

Relative Humidity

5% to 95% Non-Condensing

Terminal Block Key Position

C1


Installation and Operation Notes

  • Hazardous Area Compliance:

    • Refer to Document 12P2046 (DeltaV Scalable Process System Zone 2 Installation Instructions)

    • Additional guidance in DeltaV S-series and CHARMs Hardware Installation manual

  • Removal and Insertion:

    • Do not insert/remove with system power energized

    • Field power must be removed from terminal or carrier prior to removal

    • I/O loop assessment required on energy-limited nodes

    • Rotary keying system ensures correct terminal block-to-card compatibility


Maintenance and Adjustment

  • No user-serviceable parts

  • Disassembly is not permitted

  • Calibration is not required

Product Series

DeltaV

Country of Origin

US

Reviews

There are no reviews yet.

Be the first to review “Emerson KJ3224X1-BA1 Thermocouple / mV Input Card”
