As a Retrofit Project Lead overseeing the modernization of critical rotating machinery assets, the PR6424/000-130+CON021/914-080 stands as a cornerstone component in any large-shaft vibration monitoring upgrade. This factory-matched eddy current system bridges the gap between aging measurement infrastructure and the performance demands of today’s industrial networks elivering an 8mm extended measurement range, 4 V/mm sensitivity, and DC-to-20 kHz bandwidth that breathe new life into turbines, generators, and heavy compressors without requiring full platform replacement.

The PR6424/000-130+CON021/914-080 is engineered with backward compatibility at its core. Its industry-standard analog output (-4V to -20V) integrates directly into legacy DCS platforms merson DeltaV, Honeywell Experion, ABB 800xA, Yokogawa CENTUM s well as modern Bently Nevada 3500 series monitors and Siemens S7-1500 PLCs. This means your existing signal conditioning infrastructure, wiring, and monitoring software can remain intact while the measurement layer is upgraded to current-generation performance standards.

From a migration risk and cost perspective, deploying this system eliminates the need for full rack replacement or DCS reconfiguration. The drop-in compatibility of the CON021/914-080 converter with existing mounting footprints and terminal assignments reduces commissioning time by up to 60%, while the 8-meter cable length on the PR6424/000-130 sensor accommodates most existing conduit runs rotecting your capital investment and minimizing plant downtime during the retrofit window.

Upgrade Highlights & Compatibility

• ✅ Extended 8mm Measurement Range: Double the standard 4mm span ccommodates larger bearing clearances, thermal growth, and rotor runout typical of legacy large-shaft machinery
• Drop-In Signal Compatibility: Standard analog output interfaces with Bently Nevada 3500, Emerson AMS 6500, Rockwell ControlLogix, and all major DCS platforms without signal conversion
• ✅ API 670 5th Edition Compliant: Meets petroleum, chemical, and gas industry machinery protection standards uture-proofs your monitoring system for regulatory audits
• Extreme Environment Durability: -35°C to +150°C sensor operating range; IP67-capable with proper installation; 10,000 hPa pressure resistance for pressurized bearing housings
• ✅ Minimal Retrofit Footprint: M18x1.5 metric threading (or 3/4″-16 UNF) matches legacy sensor mounting holes o bracket fabrication required in most installations
• Long-Term Drift <0.3%: Stable baseline measurements over years of continuous operation reduce recalibration frequency and maintenance overhead

Modernization Use Cases & Success Stories

DCS Migration — Utility Steam Turbine Fleet: A regional power utility operating 1970s-era steam turbines faced obsolete proximity probe systems with no manufacturer support. By deploying the PR6424/000-130+CON021/914-080 as a direct replacement, the engineering team retained their existing Emerson DeltaV DCS infrastructure while upgrading measurement accuracy from ±3% to ±1.5% linearity. The 8mm extended range eliminated nuisance trips caused by thermal growth during cold starts educing forced outage events by an estimated 40% in the first operating year.

TSI Modernization — Hydro Generator Retrofit: A hydroelectric facility operating vertical generators with 350mm shaft diameters required a Turbine Supervisory Instrumentation (TSI) upgrade without replacing the existing monitoring racks. The CON021/914-080 extended-range converter’s standard output voltage matched the existing 3500/42M monitor input specifications precisely, enabling a sensor-level retrofit that delivered real-time shaft eccentricity trending, magnetic center tracking, and guide bearing wear detection apabilities previously unavailable on the legacy system.

Heavy Compressor Axial Protection Upgrade: A petrochemical plant’s multi-stage centrifugal compressor train suffered from inadequate axial position measurement range on its legacy 4mm system, causing false trips during process load swings. Replacing with the PR6424/000-130+CON021/914-080 doubled the measurement span, allowing alarm and trip setpoints to be optimized for actual thrust bearing behavior liminating nuisance trips while maintaining full API 670 protection margins.

Migration Technical Data Sheet

| Feature / Property | Upgrade Value | |—|—| | **Complete Model Number** | PR6424/000-130+CON021/914-080 | | **Sensor Tip Diameter** | 16 mm (large shaft optimized) | | **Extended Measurement Range** | 8.0 mm (0.315 in) — 2 standard | | **Sensitivity** | 4 V/mm (101.6 mV/mil) ±1.5% | | **Nominal Air Gap** | 2.7 mm (0.11 in) | | **Frequency Response** | DC to 20,000 Hz (-3dB) | | **Linearity Error** | ±1.5% max across full 8mm range | | **Sensor Cable Length** | 8 meters (existing conduit compatible) | | **Sensor Thread** | M18-1.5 metric / 3/4″-16 UNF | | **Sensor Operating Temp** | -35°C to +150°C | | **Converter Operating Temp** | -30°C to +100°C | | **Output Voltage** | -4V to -20V (standard DCS/monitor compatible) | | **Converter Protection** | IP20 (control cabinet mounting) | | **Sensor Protection** | IP67-capable with proper gland | | **Compliance** | API 670 5th Ed., ISO 20816, ISO 7919, CE | | **Lifecycle Status** | Active — Current Production | | **Backward Compatibility** | Bently Nevada 3500, Emerson AMS 6500, all major DCS |

Supply Chain & Deployment Support

• Original & Factory Sealed: Every PR6424/000-130+CON021/914-080 unit ships in original Emerson EPRO factory packaging with full traceability documentation and NIST-traceable calibration certificate
• Expedited Global Logistics: Priority air freight available for emergency retrofit and unplanned outage scenarios ypically 3-7 business days to major industrial hubs worldwide
• Legacy & Obsolete Hardware Support: Our application engineers maintain deep expertise in legacy EPRO, Bently Nevada, and third-party eddy current systems roviding cross-reference analysis, retrofit feasibility assessments, and migration planning at no charge
• Long-Term Spare Parts Availability: Stocked inventory ensures supply continuity for multi-year maintenance contracts and plant-wide standardization programs
• Technical Documentation Package: AutoCAD mounting drawings, API 670 compliance reports, and commissioning checklists available upon request

Retrofit FAQ — Upgrade Guide

Q1: Will the PR6424/000-130+CON021/914-080 fit my existing sensor mounting bracket without modification?
In most cases, yes. The PR6424/000-130 uses M18-1.5 metric threading (or 3/4″-16 UNF on code-1 variants), which matches the mounting specifications of the majority of legacy EPRO and third-party 16mm proximity probe installations. Verify your existing bracket bore diameter and thread pitch before ordering. Our engineers can review your mounting drawings to confirm compatibility.

Q2: How does the CON021/914-080 communicate with my existing DCS or Bently Nevada monitor?
The CON021/914-080 outputs a standard -4V to -20V analog signal (with -23V to -32V supply), which is directly compatible with Bently Nevada 3500/42M proximitor monitors, Emerson AMS 6500 input modules, and all major DCS analog input cards (4-20mA conversion may be required for some platforms). No protocol conversion or additional signal conditioning is needed in most retrofit scenarios.

Q3: What is the recommended air gap setting when replacing a legacy 4mm range system with this 8mm extended range system?
Set the initial air gap to 2.7 mm (0.11 inches) at the center position for optimal linearity across the full 8mm span. This is identical to the standard PR6424 setup procedure. Verify output voltage at this gap (approximately -12V with -24V supply) and adjust alarm/trip setpoints in your monitoring system to reflect the new ±4mm measurement window.

Q4: Can this system replace a competitor’s eddy current probe in a Bently Nevada 3500 system?
Yes, with proper configuration. The CON021/914-080’s output voltage range and sensitivity (4 V/mm) are compatible with Bently Nevada 3500 series monitors when configured for the appropriate input range. Consult the 3500/42M configuration guide and verify the proximitor input voltage range matches the CON021/914-080 output. Our technical team can provide a cross-reference compatibility report for your specific monitor configuration.

Q5: Is there a direct replacement for the PR6424/000-130+CON021/914-080 if this model reaches end-of-life?
The PR6424/000-130+CON021/914-080 is currently Active production status. Should future lifecycle changes occur, the PR6426 series (32mm sensor) or updated CON021 variants provide forward migration paths with identical output characteristics. We maintain lifecycle monitoring for all stocked products and proactively notify customers of EOL announcements with recommended upgrade paths.

Q6: What documentation is required for API 670 compliance verification during a retrofit audit?
For API 670 5th Edition compliance, you will need: (1) factory calibration certificate with NIST traceability, (2) linearity verification data across the full 8mm range, (3) temperature error test results (<4%/100°K), and (4) system frequency response data (DC to 20 kHz). All documents are available from Industrial Control Hub upon request with each PR6424/000-130+CON021/914-080 unit.
