The Siemens 3TF49 22-OXMO is a high-current AC contactor from the SIRIUS 3TF series, engineered for demanding industrial switching applications in motor control centers, control cabinets, and legacy automation panels. As Siemens progressively transitions its contactor portfolio toward the SIRIUS 3RT2 platform, the 3TF49 22-OXMO remains a critical retrofit and replacement component for facilities operating aging control infrastructure that cannot be immediately migrated to newer platforms. NINERMAS maintains verified stock of the 3TF49 22-OXMO to support planned and emergency replacement programs, with each unit pre-shipment tested and covered by a 12-month warranty.

The 3TF49 22-OXMO is rated for high-load motor switching duties and is commonly found in legacy motor control centers (MCCs), pump control panels, compressor drive cabinets, and conveyor line starters. Its coil voltage designation (OXMO) indicates a specific control voltage configuration that must be confirmed against the existing panel wiring before installation. Engineers undertaking a retrofit must verify the coil voltage, auxiliary contact arrangement (2NO+2NC standard on this variant), main terminal torque specifications, and the physical mounting footprint against the existing contactor position in the control cabinet. The 3TF49 22-OXMO mounts on standard DIN rail or panel-mount configurations compatible with the broader 3TF4x frame size.

Upgrade Compatibility Table

Retrofit Planning for Existing Automation Systems

When integrating the 3TF49 22-OXMO into an existing automation retrofit, the scope of work typically extends well beyond the contactor itself. In a typical legacy motor control center upgrade, the 3TF49 22-OXMO works alongside a Siemens 3VU13 or 3RV2 motor circuit breaker for upstream overcurrent protection. The motor circuit breaker must be sized to match the contactor’s rated operational current (Ie) and the motor’s full-load amperage. Engineers should also inspect the existing 3TF series overload relay — commonly a 3UA or 3RB2 bimetallic or electronic overload relay — to confirm it remains compatible with the replacement contactor’s terminal layout and current range.

For control cabinet upgrades involving SIMATIC S7-300 or S7-400 PLCs, the digital output modules (such as the SM 322 DO 16×DC24V or SM 322 DO 8×AC120V) that drive the contactor coil must be verified for output current capacity. If the existing DO module cannot source sufficient current for the 3TF49 22-OXMO coil, an intermediate relay — such as the Siemens 3TX7 or a Phoenix Contact PLC-RSC series — should be inserted between the PLC output and the contactor coil circuit. This is a common oversight during rapid retrofit projects that leads to premature DO module failure.

In applications where the legacy system uses a Siemens OP7, OP17, or TP177 HMI panel, the contactor status feedback — typically wired through the 2NC auxiliary contact to a digital input module such as the SM 321 DI 16×DC24V — must be re-verified after replacement. HMI screen tags referencing contactor feedback bits should be tested in simulation mode before live commissioning to avoid false fault alarms. If the control program resides on a Siemens S7-300 CPU 315-2DP or similar, a full I/O force table test is recommended post-installation.

For facilities migrating from hardwired relay logic to PLC-based control, the 3TF49 22-OXMO can serve as a transitional component, maintaining the existing power circuit while the control logic is progressively migrated. In such projects, the contactor is often paired with a Siemens 3RH2 contactor relay for auxiliary switching duties and a 3RT2 series contactor for the new PLC-controlled circuits running in parallel during the cutover phase. Power supply integrity — typically provided by a Siemens SITOP PSU100S or PSU200M 24VDC power supply — must be confirmed to support both legacy and new control circuits simultaneously during the transition period.

Terminal wiring adaptation is another critical step. The 3TF49 22-OXMO uses screw-type main terminals; if the existing installation uses ring-lug or ferrule terminations, the terminal torque values specified in the Siemens installation manual must be strictly observed to prevent loose connections under thermal cycling. Weidmüller or Phoenix Contact terminal blocks adjacent to the contactor in the control cabinet should be inspected and re-torqued as part of the retrofit procedure.

Downtime Control During System Migration

Minimizing production downtime during a contactor replacement or control system migration requires disciplined pre-staging and a structured cutover plan. For the 3TF49 22-OXMO, the recommended approach is to pre-wire the replacement contactor on a sub-panel or DIN rail section outside the live cabinet, verify coil energization and auxiliary contact continuity on the bench, and then execute a hot-swap during a scheduled maintenance window.

Before de-energizing the existing contactor, the control program logic should be placed in manual override or the affected motor circuit isolated at the motor circuit breaker. The existing wiring should be photographed and labeled — particularly the auxiliary contact wiring, which varies between installations. If the system uses a Siemens SIMATIC ET 200S or ET 200M distributed I/O rack in the field panel, the rack’s power supply module should be confirmed as stable before and after the contactor swap to prevent spurious I/O faults from propagating to the main PLC CPU.

Post-installation, a structured commissioning sequence should include: coil voltage measurement at the contactor terminals under load, contact resistance measurement across main contacts (typically <1mΩ for a new contactor), auxiliary contact continuity test, interlock logic verification in the PLC program, and a full-load motor start test. Documenting these results protects the maintenance team and provides a baseline for future predictive maintenance intervals. NINERMAS provides pre-shipment test reports for each 3TF49 22-OXMO unit upon request, reducing on-site commissioning time.

Retrofit Support FAQ

Q1: Is the Siemens 3TF49 22-OXMO a direct drop-in replacement for other 3TF4x variants?
The 3TF49 22-OXMO shares the 3TF4x frame size and main terminal layout with other 3TF49 variants, but the coil voltage (OXMO designation) and auxiliary contact configuration (2NO+2NC) must match the existing installation exactly. Always cross-reference the full part number from the panel wiring diagram before ordering. NINERMAS technical support can assist with cross-referencing if the original part number is partially legible.

Q2: What pre-shipment testing does NINERMAS perform on the 3TF49 22-OXMO?
Each unit undergoes coil energization testing at rated voltage, main contact resistance measurement, auxiliary contact continuity verification, and insulation resistance testing. A test report is available upon request. All units are covered by a 12-month warranty from the date of shipment.

Q3: Can the 3TF49 22-OXMO be used with a Siemens SIMATIC S7 PLC digital output module directly?
This depends on the coil current draw of the specific OXMO voltage variant and the output current rating of the DO module. For 24VDC coil variants, most S7-300 SM 322 DO modules can drive the coil directly. For AC coil variants, an intermediate relay is typically required. Confirm the coil current specification against your DO module datasheet before wiring.

Q4: What is the lead time and inventory availability for the 3TF49 22-OXMO?
NINERMAS maintains stock of the 3TF49 22-OXMO to support urgent replacement and planned maintenance programs. Standard orders ship within 3–5 business days. For bulk or long-term supply commitments supporting lifecycle extension programs, contact our sales team to discuss fixed-price supply agreements and reserved inventory arrangements.
